Tekonsha PRODIGY iD 90920 Instructions And Operating Manual

Electronic Brake Control with EDGE
For 2, 4, 6 and 8 brake (or 1–4 axles) applications
READ THIS FIRST:
Read and follow all instructions
carefully before installing or
operating the PRODIGY iD. Keep
these instructions with the Brake
Control for future Reference.
Table of Contents
Components of PRODIGY iD . . . . . . . . . . . . . . . . . . . . . . . . 4 en
Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 en - 17 en
Tekonsha Edge App Instructions . . . . . . . . . . . . . . . . . . . 18 en
™
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 en - 39 en
Appendix, Patent Information, Drill Template . . . . . . . . . 40 en - 43 en
BRAKE CONTROL
Instruction and Operating Manual
™
Scan QR Code For French or
Spanish Language Instructions
and Enter Part Number 90920.
- 2 en -
90920
Important Facts to Remember
1. WARNING The PRODIGY iD may be operated with reduced
performance if the Dash Module is removed or disconnected
while the trailer is in use.
2. Do not mount or activate RF generating items (such as two-way
radios) near (less than 12in to the Dash Module or Power Module).
3. The PRODIGY iD employs an internal sensor. It senses deceleration
and generates an output that is based on deceleration, thus the
term "Proportional Braking".
4. The PRODIGY iD will "HOLD" your trailer with 25% of power
setting while you are at a standstill with brake pedal applied for
longer than 5-7 seconds.
5. The PRODIGY iD will brake proportionally in reverse. It will apply
the appropriate brake voltage based on deceleration.
6. WARNING The Gross Combined Weight Rating (GCWR) must
never exceed the vehicle manufacturers' recommendation.
7. WARNING
Follow all installation and mounting instructions
to allow the inertial sensor to operate properly.
8. For Technical Assistance and Warranty Information call:
1-800-632-3290 or www.tekonsha.com
9. Tekonsha EDGE App is not required for use, but adds additional
™
features.
ENGLISH
