- Page 1 ® R&S RTB2000 Oscilloscope Getting Started (=Q@52) 1333160502 Version 08...
- Page 2 ® This manual describes the following R&S RTB2000 models: ● R&S ® RTB2002 (1333.1005K02) ● R&S ® RTB2004 (1333.1005K04) © 2021 Rohde & Schwarz GmbH & Co. KG Mühldorfstr. 15, 81671 München, Germany Phone: +49 89 41 29 - 0 Email: info@rohde-schwarz.com Internet:...
-
Page 3: Table Of Contents
® Contents R&S RTB2000 Contents 1 Safety and regulatory information........5 1.1 Safety instructions................5 1.2 Labels on the product.................11 1.3 Warning messages in the documentation........12 1.4 CE declaration of conformity.............13 1.5 UKCA declaration of conformity............14 1.6 Korea certification class A..............15 2 Documentation overview............ - Page 4 ® Contents R&S RTB2000 4.1 Front panel..................25 4.1.1 Input connectors................... 26 4.1.2 Other connectors on the front panel............. 27 4.2 Rear panel....................27 5 Contacting customer support..........29 Getting Started 1333.1605.02 ─ 08...
-
Page 5: Safety And Regulatory Information
® Safety and regulatory information R&S RTB2000 Safety instructions Safety and regulatory information The product documentation helps you to use the product safely and efficiently. Follow the instructions provided here and in the Chapter 1.1, "Safety instructions", on page 5. Intended use The R&S RTB2000 oscilloscope is designed for measurements on circuits that are only indirectly connected to the mains or not connected at all. - Page 6 ® Safety and regulatory information R&S RTB2000 Safety instructions Using the product requires specialists or specially trained personnel. These users also need sound knowledge of at least one of the languages in which the user interfaces and the product documentation are available. Never open the casing of the product.
- Page 7 ® Safety and regulatory information R&S RTB2000 Safety instructions Setting up the product Always place the product on a stable, flat and level surface with the bottom of the product facing down. If the product is designed for different positions, secure the product so that it cannot fall over.
- Page 8 ® Safety and regulatory information R&S RTB2000 Safety instructions ● Only use intact cables and route them carefully so that they cannot be dam- aged. Check the power cables regularly to ensure that they are undamaged. Also ensure that nobody can trip over loose cables. ●...
- Page 9 ® Safety and regulatory information R&S RTB2000 Safety instructions tweezers or pliers to avoid injuries. When transporting the accessories, always use the box supplied with the probe. ● Prevent the probe from receiving mechanical shock. Avoid putting excessive strain on the probe cable or exposing it to sharp bends. Touching a broken cable during measurements can cause injuries.
- Page 10 ® Safety and regulatory information R&S RTB2000 Safety instructions ● The following effects can cause burns and fire or damage to the measurement site: – Eddy current loss can cause heating of the sensor head. – Dielectric heating can cause heating of cord insulation and other materials. Measurement categories IEC 61010-2-030 defines measurement categories that rate instruments on their ability to resist short transient overvoltages that occur in addition to the working...
-
Page 11: Labels On The Product
® Safety and regulatory information R&S RTB2000 Labels on the product Cleaning the product Use a dry, lint-free cloth to clean the product. When cleaning, keep in mind that the casing is not waterproof. Do not use liquid cleaning agents. Meaning of safety labels Safety labels on the product warn against potential hazards. -
Page 12: Warning Messages In The Documentation
® Safety and regulatory information R&S RTB2000 Warning messages in the documentation Warning messages in the documentation A warning message points out a risk or danger that you need to be aware of. The signal word indicates the severity of the safety hazard and how likely it will occur if you do not follow the safety precautions. -
Page 13: Ce Declaration Of Conformity
® Safety and regulatory information R&S RTB2000 CE declaration of conformity CE declaration of conformity Getting Started 1333.1605.02 ─ 08... -
Page 14: Ukca Declaration Of Conformity
® Safety and regulatory information R&S RTB2000 UKCA declaration of conformity UKCA declaration of conformity Getting Started 1333.1605.02 ─ 08... -
Page 15: Korea Certification Class A
® Safety and regulatory information R&S RTB2000 Korea certification class A Korea certification class A 이 기기는 업무용(A급) 전자파 적합기기로서 판매자 또는 사용자는 이 점을 주의하 시기 바라며, 가정외의 지역에서 사용하는 것을 목적으로 합니다. Getting Started 1333.1605.02 ─ 08... -
Page 16: Documentation Overview
® Documentation overview R&S RTB2000 Manuals and instrument help Documentation overview This section provides an overview of the R&S RTB2000 user documentation. Manuals and instrument help You find the manuals on the product page at: www.rohde-schwarz.com/manual/rtb2000 Getting started manual Introduces the R&S RTB2000 and describes how to set up the product. A printed English version is included in the delivery. -
Page 17: Data Sheet And Brochure
® Documentation overview R&S RTB2000 Release notes and open source acknowledgment Service manual Describes the performance test for checking the rated specifications, module replacement and repair, firmware update, troubleshooting and fault elimination, and contains mechanical drawings and spare part lists. The service manual is available for registered users on the global Rohde &... -
Page 18: Preparing For Use
® Preparing for use R&S RTB2000 Unpacking and checking Preparing for use Here, you can find basic information about setting up the instrument for the first time or when changing the operating site. Lifting and carrying See: "Lifting and carrying the instrument" on page 6. -
Page 19: Choosing The Operating Site
® Preparing for use R&S RTB2000 Setting up the product Choosing the operating site Specific operating conditions ensure proper operation and avoid damage to the product and connected devices. For information on environmental conditions such as ambient temperature and humidity, see the data sheet. See also "Choosing the operating site"... -
Page 20: Mounting The Product In A Rack
® Preparing for use R&S RTB2000 Setting up the product To place the product on a bench top 1. Place the product on a stable, flat and level surface. Ensure that the surface can support the weight of the product. For information on the weight, see the data sheet. -
Page 21: Considerations For Test Setup
® Preparing for use R&S RTB2000 Considerations for test setup Design and implement an efficient ventilation concept for the rack. To mount the R&S RTB2000 in a rack 1. Use an adapter kit that fits the dimensions of the R&S RTB2000 to prepare the instrument for rack mounting. -
Page 22: Connecting To Power
® Preparing for use R&S RTB2000 Connecting to power Measuring accessories Use only probes and measuring accessories that comply with IEC 61010-031. Signal input and output levels Information on signal levels is provided in the data sheet. Keep the signal levels within the specified ranges to avoid damage to the product and connected devi- ces. -
Page 23: Switching On Or Off
® Preparing for use R&S RTB2000 Switching on or off 1. Plug the AC power cable into the AC power connector on the rear panel of the product. Only use the AC power cable delivered with the product. 2. Plug the AC power cable into a power outlet with ground contact. The required ratings are listed next to the AC power connector and in the data sheet. -
Page 24: Changing Fuses
® Preparing for use R&S RTB2000 Changing fuses All current settings are saved, and the software shuts down. The [Standby] key turns yellow. The standby power supplies only the power switch circuits. To disconnect from power The product is in the standby state. 1. -
Page 25: Instrument Tour
® Instrument tour R&S RTB2000 Front panel Instrument tour Front panel Figure 4-1 shows the front panel of the R&S RTB2000. The function keys are grouped in functional blocks to the right of the display. Figure 4-1: Front panel of R&S RTB2004 with 4 input channels 1 = Display 2 = Horizontal and vertical setup controls 3 = Trigger settings, action and analysis controls... -
Page 26: Input Connectors
® Instrument tour R&S RTB2000 Front panel 4.1.1 Input connectors BNC inputs (4 and 5) The R&S RTB2000 has two or four channel inputs (4) to connect the input sig- nals. The external trigger input (5) is used to control the measurement by an external signal. -
Page 27: Other Connectors On The Front Panel
® Instrument tour R&S RTB2000 Rear panel 4.1.2 Other connectors on the front panel [Pattern Generator] (7) Connectors for the pattern generator P0, P1, P2, P3. The "Demo 1" signal is intended for demonstration purposes. [Probe Comp.] (7) Probe compensation terminal to support adjustment of passive probes to the oscilloscope channel. - Page 28 ® Instrument tour R&S RTB2000 Rear panel Figure 4-2: Rear panel view of R&S RTB2000 1 = LAN connector 2 = USB connector, type B 3 = AC power supply connector and main power switch 4 = Kensington lock slot to secure the instrument against theft 5 = Loop for lock to secure the instrument against theft 6 = not used [LAN] (1)
-
Page 29: Contacting Customer Support
® Contacting customer support R&S RTB2000 Contacting customer support Technical support – where and when you need it For quick, expert help with any Rohde & Schwarz product, contact our customer support center. A team of highly qualified engineers provides support and works with you to find a solution to your query on any aspect of the operation, program- ming or applications of Rohde &...
