Wireless Switch/Receiver
Installation and Operation Instructions
To avoid electric shock while installing the Receiver, please disconnect the mains
voltage (switch off circuit breaker) before installation. Failure to observe the
installation instructions can cause fire or other hazards. Do not attempt to service or
repair the product yourself. Leave any and all service work to qualified Electricians.
Do not continue to operate the product if it becomes visibly damaged.
*Work on 230 V mains supply shall only be carried out by Licensed Electricians.
www.cleverlife.com.au
Advertisement
Summary of Contents for Clever Life CL-L-S - 114REC
- Page 1 CERTIFICATE INSPECTED Wireless Switch/Receiver Installation and Operation Instructions To avoid electric shock while installing the Receiver, please disconnect the mains voltage (switch off circuit breaker) before installation. Failure to observe the installation instructions can cause fire or other hazards. Do not attempt to service or repair the product yourself.
-
Page 2: Product Features
Wireless Receiving Controller Switch Technical Parameters Receiver Technical Parameters ◼ Work type: Reciprocating work by 86 type lever ◼ Model: CL-L-S - 114REC ◼ Power Mode: Power generation by mechanical force ◼ Input: 110 - 260VAC 50/60HZ ◼ Working frequency : 433MHZ ◼... - Page 3 Installation method of stainless steel fixed plate ◼ Apply to any flat surface ◼ Fix the stainless steel fixing plate to the wall with the self-tapping screws ◼ The groove behind the main body is aligned to the buckle position of the stainless steel fixing plate and pressed downward (as indicated by the arrow) Installation method of Double –sided adhesive tape ◼...
- Page 4 Installation method of receiver ◼ The wireless receiver should be connected to the luminaire and be used in conjunction with the 114 series switch. ◼ Connect Line supply to L & N input terminal (AC110-260V) ◼ Connect Load (Lamp) to L & N output terminal ◼...
- Page 5 Code matching ◼ Ensure the receiver controller is connected to 110-260VAC and power is ‘on’ ◼ Press the function button for 3~5 seconds, (the indicator light will flicker slowly) then release the button, enter the coding mode ◼ Press the "wireless switch" to be coded, the indicator flashes 2 times and emits the "beep" two times, at this time the indicator lights out, indicating the coding success ◼...
- Page 6 Pairing Receiver to APP Press button for 10 seconds to enter ◼ discoverable mode Download the CleverLife Home App from the Apple app store or the Google Play store. ◼ Start the CleverLife Home App ◼ If you’re using it for the first time, you’ll have to register and create a new account. If you already have an account, log in using your login details.
