- Page 1 Diesel Heater 30KW DH30KW Owner’s Manual & Safety Instructions Read this manual before using this product. Failure to do so can result in serious injury. SAVE THIS MANUAL.
-
Page 2: Table Of Contents
30KW Diesel Heater DH30KW INDEX Work Area Safety Electrical Safety Personal Safety Symbols & Technical Assembly Installation Application & Maintenance Maintenance Wiring & Troubleshoot Declaration... -
Page 3: Work Area Safety
30KW Diesel Heater DH30KW General Safety Warnings: Read all safety warnings, instructions, illustrations and specifications provided with this appliance. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. -
Page 4: Personal Safety
30KW Diesel Heater DH30KW 3) Personal safety a) Stay alert, watch what you are doing and use common sense when operating the appliance. b) Ensure the switch is in the OFF-position before disconnecting and picking up or carrying the appliance. -
Page 5: Symbols & Technical
30KW Diesel Heater DH30KW SYMBOL DESCRIPTION Read the manual before set-up and/or use. Do not dispose with house-hold waste. Conforms to relevant safety standards. Technical Data: .03. -
Page 6: Assembly
30KW Diesel Heater DH30KW Assembling: Assembling Instructions Extract the heater from its carton. If the unit is anyhow damaged, do not use it and contact your dealer. To assemble the heater, proceed as follows (see Fig. 2): 1、Insert the wheel shaft J to the corresponding hole of feet pipe E，insert the cotter K to the corresponding holes;... -
Page 7: Installation
30KW Diesel Heater DH30KW Installation Instructions: Position the heater on a flat, level, non-flammable, solid surface. Direct-fired heaters are intended for use in outdoor open areas or in indoor well ventilated areas. For indoor use, provide permanent ventilation openings of at least 25 cm²/kW, equally distributed between floor and high level, with a minimum of 250 cm². -
Page 8: Application & Maintenance
30KW Diesel Heater DH30KW Application use: 6.1. Start-up Fill tank with clean fuel. Only use Diesel or Kerosene. The fuel gauge on top of the tank allows to check fuel level Connect the power cord plug to a 230 V 50 Hz earthed electrical supply system. - Page 9 30KW Diesel Heater DH30KW Nozzle Carefully unscrew nozzle from nozzle fitting. Blow compressed air through nozzle orifice to free it from dirt. Replace nozzle if necessary. Air Filters Clean air filters. Remove filter end cover (11), wash air intake filter (10) using a light detergent and dry it thoroughly before re-installing.
-
Page 10: Wiring & Troubleshoot
30KW Diesel Heater DH30KW Wiring Diagram: .08. -
Page 11: Declaration
30KW Diesel Heater DH30KW Seller Details: .09. - Page 12 TOOLSAVE UNIT C MANDERS INDUSTRIAL ESTATE WOLVERHAMPTON WV1 2RP...
