Items Not Included - lynx System Developers FinishLynx Assembly Instructions Manual

FinishLynx Scholastic System
Verify that your FinishLynx Scholastic System contains the components pictured here. If something is missing, or you have questions
regarding your system, call: 1-800-989-LYNX or send an email to
Item
Carrying case
EtherLynx Vision
Scholastic high
sensitivity camera
CS Mount 2.8-10mm P-
Iris Lens
Scholastic-level Timer
enable option
Not pictured
embedded in camera
Geared head
Camera tripod
Lynx USB Flash Drive
with FinishLynx LITE &
LynxPad
Be sure to keep your USB flash drive safe. It includes your Serial Numbers, Software, & Quick-Start Guides.
To access the files, insert the flash drive in your computer and navigate to the folders.

Items Not Included

•
Computer (laptop recommended) running Microsoft Windows. Your computer needs: one available USB port or a
serial port (a 9-pin connection found on the back), and one available Ethernet port.
•
Plumb bob and string. The plumb bob is available at your local hardware store, and you can use virtually any type of
string or twine, as long as it is at least the width of your track (optional).
•
Printer (optional).
Introduction
In this quick start guide, you will learn how to set up and configure the FinishLynx LITE network, set up the EtherLynx
Scholastic camera and align it with the finish line, capture, evaluate, and print a FinishLynx LITE image and results, and
import a start list created in LynxPad.
For more detailed or advanced instructions, consult the online FinishLynx Operator's Manual (help.finishlynx.com) or the
technical support section of our website: www.finishlynx.com/support/.
FinishLynx Scholastic System Quick Start Guide
Part
Description
Number
1A210
5L510
CS2810P
5LTE
BG3275
5LTP10
5LSWL
and
9LSW01
support@finishynx.com.
Item Description
Normally closed start
sensor with light
500 ft. start sensor
cable
DB15 to XLR
Connection cable
25 ft. Ethernet cables
(x2)
Capture button and
USB/Serial adapter
Power Injector for
Power Over Ethernet
Part Number
3L400
3A100
451-S
C10BT-25
1A205U
IDL-PoE
