Summary of Contents for cleanAIR 0723-10
- Page 1 212 N. Woodwork Lane Palatine, IL 60067 800-223-3977 Heated Sample Line Part #0723-10, 0723-25, 0723-50, 0723-100 Part # 0723-100HD (triple insulation) User Manual Questions? Contact us at 800-223-3977 or online at http://www.cleanair.com/equipment/Express/main.html Heated Sample Line...
-
Page 2: Table Of Contents
Table of Contents IMPORTANT!!! ......................... 2 Customer Feedback ......................3 Safety .......................... 4 Temperature ......................4 Electrical Shock ....................4 Principles of Operation ....................5 Lengths, Voltages, Watts ..................5 System Components.................... 5 System Operation ....................6 Maintenance and Inspection ..................7 External maintenance .................. -
Page 3: Important
HIGHLY recommended that one of Clean Air Express’s digital temperature controllers (0725RNT, 0725PM, 0725R) be used with this product. See http://www.cleanair.com or call (800) 223-3977 for more information Maintenance and repairs should be performed by one of Clean Air Express’s trained technicians. -
Page 4: Customer Feedback
A customer feedback form is available online at http://www.cleanair.com/About/feedback.html. To emphasize our commitment to quality products and complete customer satisfaction, Clean Air Engineering’s manufacturing division, CAE Express, offers what we feel is the best and most comprehensive warranty in the environmental industry. -
Page 5: Safety
Safety 1 Safety Safety should always be considered first, and proper safety procedures should be followed. Temperature Clean Air Express’s temperature controllers are capable of heating lines to very high temperatures. Exercise caution around the exterior of the box, lines, and probes as they can all become very hot when the assembly is on. -
Page 6: Principles Of Operation
The Heated Sample Line helps to ensure the accuracy of gas samples by providing a heated route for the gas in order to help prevent scrubbing. Lengths, Voltages, Watts Part Number Voltage Watts Length 0723-10 0723-25 0723-50 1500 0723-100 2500 0723-100HD* 3000... -
Page 7: System Operation
Principles of Operation System Operation See below for pictures. Insert one of the thermocouples Figure into the corresponding input on the temperature controller; the second is simply a spare. It is unnecessary to plug the second thermocouple into anything. Connect the calibration gas line the sample line (1). -
Page 8: Maintenance And Inspection
For any other maintenance issues, concerns, or questions, please contact Clean Air Express at (800)-223-3977. Clean Air Express can also be reached by mail at 212 N. Woodwork Lane Palatine, IL 60067; by fax at (847)-991-8924 or on the web at http://www.cleanair.com/equipment/Express/main.html Heated Sample Line... -
Page 9: Troubleshooting
Troubleshooting 4 Troubleshooting Heated Sample Line Controller not heating the sample lines There is no easy way to repair/replace a burned-out probe heater or heated sample line in the field. However, often the source of failure is not a burned-out heater, but a bad connector. Check the connectors for a broken or bent pin, and repair/replace as necessary. - Page 10 Cross Sectional View Electrical (Thermo- couples, Power cord) Sample Line Calibra- tion Line Heated Sample Line...
- Page 11 Parts List CLEAN AIR ENGINEERING PARTS LIST HEATED SAMPLE LINE May 22, 2008 Parent Part #: 0723-* Type: F *dependent on length COMPONENT DESCRIPTION UM TYPE ------------------- --------------------- ------- ----- -------- 0723G HEATED SAMPLE LINE GUARD SAFETY YELLOW 9801100 HEATED SAMPLE LINE 100' 0419SRU UNION 3/8"T-1/4"T S.S.
- Page 12 Our Guarantee Our Guarantee Clean Air Engineering warrants products to be free from defects and workmanship for a period of one year after delivery date. The sole and exclusive remedy for defective goods shall be repair or replacement of defective parts or payment price of the goods for which damages are claimed, at Clean Air Engineering’s option.
