SoundRanger COMPACT4 User Manual

Soundranger
COMPACT4
Portable Address System
User Guide
Introduction
The Soundranger COMPACT4 is a compact and easy to use system for you to talk to an audience
almost anywhere.
Because it uses radio, and runs from an on-board rechargeable battery, there are no wires
or cables to get in the way.
You don't need to plug the COMPACT4 in to the mains but you can - and when it is
plugged into the mains more output power is available.
You can use the radio microphone(s) up to 30 metres away from the receiver/amplifier and
even have the amplifier in another room.
If you need more volume or wider distribution, you can link together as many COMPACT4
receiver/amplifiers as you like.
The sound quality is crisp and clear, speech intelligibility is excellent.
Because the system is DTI approved (to EN300 422), you don't need a licence and can use
it anywhere, inside or outside .
Quick Start
1) Position the COMPACT4 anywhere suitable, at head height or higher.
2) Set the controls on the rear panel as follows:
Radio Microphone Channel 1
Radio Microphone Channel 2
Speech Clarity:
Bass:
Switch the Power switch to 'ON'
3)
Switch the microphone(s) 'ON'
4)
5) Talk directly into the microphone
Yes, it's as simple as that, but to get the best from the system please read the instructions.
If you need any advice or assistance - contact Connevans Ltd on 01737 247571
Volume No 3
Volume No 3
(if fitted)
Mid-way
Mid-way
