Summary of Contents for SHUMATECH DRO-550
- Page 1 OpenDRO User’s Guide (rev. 2) HUMA DRO-550 Software Upgrade Guide...
- Page 2 0.3.2, then you should download the file named opendro-dro550-base-x.y.z.bin where x.y.z are the the release numbers. If you have an LCD-200 attached to your DRO-550, then you should download opendro-dro550-lcd-x.y.z.bin. Note the "base" and "lcd" keywords in the file...
- Page 3 Step 2. Install BOSSA BOSSA is used to transfer the OpenDRO binary image to the DRO-550 from your PC via the USB or RS-232 connections. BOSSA is available in both Windows and Linux versions for 32- bit and 64-bit systems.
- Page 4 OpenDRO User’s Guide (rev. 2) During the installation process, Windows may ask if you want the setup program to make changes to your system which you should answer Yes to. Windows will also warn you that you are installing an unsigned driver or that the publisher can't be verified. You should allow the driver installation to proceed otherwise the USB CDC driver that BOSSA depends on will not be installed.
- Page 5 If you already have OpenDRO installed on the DRO-550, then plug power into your DRO-550 and enter the main menu by pressing the FUNC key. Press the Y key until you reach the system menu ("sys" on the display). Press the Z key until you reach the update selection.
- Page 6 OpenDRO User’s Guide (rev. 2) Click on the the Auto-Scan button in the Serial Port group box to find your DRO-550. If no DRO-550 is found, then you should open your Windows Device Manager and look at the entries under the Ports (COM & LPT) list. You should see an entry for "BOSSA Program Port" (or possibly "GPS Camera Detect"...
- Page 7 OpenDRO User’s Guide (rev. 2) You will see a progress window followed by a dialog box telling you the result of the write operation.
- Page 8 OpenDRO User’s Guide (rev. 2) Step 7. Verify the OpenDRO Image After the write completes successfully, click on the Verify button to verify the contents of the DRO-550 flash memory. You should see a progress window followed by a dialog box.
