2-695-065-12(1)

Wireless Speaker

System
Operating Instructions
SRS-BTM30
©2006 Sony Corporation

Advertisement

loading

  Related Manuals for Sony SRS-BTM30

  Summary of Contents for Sony SRS-BTM30

  • Page 1: Wireless Speaker

    2-695-065-12(1) Wireless Speaker System Operating Instructions SRS-BTM30 ©2006 Sony Corporation...
  • Page 2 AC outlet. Should you notice an abnormality in the AC power adaptor, disconnect it from the AC outlet immediately. Hereby, Sony Corp., declares that this equipment is in compliance with the essential requirements and other relevant provisions of Directive 1999/ 5/EC.
  • Page 3: Table Of Contents

    Table Of Contents Features ... 4 Using the BLUETOOTH connection .. 5 Unpacking ... 6 Location and Function of Parts ... 7 Power Sources ... 8 Using on the mains ... 8 Using with batteries ... 8 Installing the Speaker ... 9 Using the BLUETOOTH Connection ...
  • Page 4: Features

    Features This unit is a wireless speaker system that uses BLUETOOTH™ wireless technology. You can enjoy listening to the sound wirelessly with your mobile phone, personal computer, portable music player or other BLUETOOTH supported device.* * BLUETOOTH devices to be connected with this unit are required to support A2DP (Advanced Audio Distribution Profile).
  • Page 5: Using The Bluetooth Connection

    Using the BLUETOOTH connection In the example below, we explain how to receive the sound played on a BLUETOOTH mobile phone with the sound playback function and listen to the sound on this unit. Pairing Enables a BLUETOOTH mobile phone and this unit to recognize one another. BLUETOOTH mobile phone BLUETOOTH connection...
  • Page 6: Unpacking

    GETTING STARTED Unpacking Check that you have the following items: • Wireless Speaker System (1) • AC power adaptor (1) • Mains lead (1) • Operating Instructions (1)
  • Page 7: Location And Function Of Parts

    Location and Function of Parts 1 1 (power) button/indicator Press to turn on the unit. Press and hold to turn off the unit. The 1 icon in the button lights up, flashes, or goes off. (See page 10.) 2 ID SET (pairing) button For pairing with other BLUETOOTH device.
  • Page 8: Power Sources

    Power Sources Using on the mains to wall outlet When the AC power adaptor is connected to the system, internal batteries are automatically disconnected. Note When connecting or disconnecting the AC power adaptor, turn off the system beforehand. Otherwise, it may cause malfunction.
  • Page 9: Installing The Speaker

    In such a case, replace all the batteries with new ones. Battery life Battery type Sony alkaline battery LR6 (SG) Sony manganese battery R6 * Usage time stated above may vary according to the temperature or conditions of use.
  • Page 10: Using The Bluetooth Connection

    OPERATING THE UNIT Using the BLUETOOTH Connection By using the BLUETOOTH connection, you can listen to the sound from a BLUETOOTH stereo audio source device with this unit wirelessly. Example BLUETOOTH mobile phone or other BLUETOOTH stereo audio source device Note For details on how to operate the device to be connected, refer to the operating instructions supplied with the device.
  • Page 11: Pairing With A Source Device

    Pairing with a source device Check the following before operating the unit. – This unit is connected to a power source and the 1 indicator (green) goes off. Press and hold the ID SET button for 7 seconds or more. When the 1 indicator (green) and button.
  • Page 12: Listening To The Sound

    When pairing with a BLUETOOTH stereo audio source device that cannot display a list of detected devices or that has no display You may pair the device by setting both this unit and the BLUETOOTH stereo audio source device to pairing mode.
  • Page 13 To finish listening Terminate the BLUETOOTH connection by any of the operations below. – Operate the BLUETOOTH stereo audio source device to terminate the connection. For details, refer to the operating instructions supplied with the device. – Turn off the BLUETOOTH stereo audio source device. –...
  • Page 14: Using By Connecting With A Cord

    Using by Connecting with a Cord You can listen to the sound from a device connected to the INPUT jack. Example Portable audio device, CD/MD player, computer, etc. Note For details on how to operate the device to be connected, refer to the operating instructions supplied with the device.
  • Page 15: Listening To The Sound

    Listening to the sound 1 button VOLUME +/– buttons Check the following before operating the unit. – If you have been listening to the sound from the BLUETOOTH stereo audio source device, stop playing on the device or terminate the BLUETOOTH connection. Press the 1 button to turn on this unit.
  • Page 16: Precautions

    ADDITIONAL INFORMATION Precautions On BLUETOOTH communication • BLUETOOTH wireless technology operates within a range of about 10 meters (about 30 feet). Maximum communication range may vary depending on obstacles (person, metal, wall, etc.) or electromagnetic environment. This unit Steel cabinet Optimal performance Limited performance •...
  • Page 17 Others • If you have any questions or problems concerning this unit that are not covered in this manual, please consult your nearest Sony dealer. • Should any problem persist, consult your nearest Sony dealer.
  • Page 18: What Is Bluetooth Technology

    What is BLUETOOTH technology? BLUETOOTH wireless technology is a short-range wireless technology that enables wireless data communication between digital devices, such as a computer or digital camera. BLUETOOTH wireless technology operates within a range of about 10 meters (about 30 feet).
  • Page 19: Troubleshooting

    Troubleshooting If you run into any problems using this unit, use the following checklist. Should any problem persist, consult your nearest Sony dealer. Common No sound , Check that both this unit and the source device are turned on. , Turn up the volume of the unit.
  • Page 20: Initializing This Unit

    Initializing This Unit You can reset this unit to its default and delete all pairing information. If this unit is turned on, press and hold the 1 button to turn off this unit. While holding the 1 button, press the ID SET button for 7 seconds or more.
  • Page 21: Specifications

    Specifications Speaker section Speaker system 48 mm, Full range, magnetically shielded Enclosure type Bass reflex Impedance 4 Ω Rated input power Maximum input power Amplifier section Rated output 3 W + 3 W (10% T.H.D., 1 kHz, 4 Ω) Bass Boost MEGA BASS Audio input Stereo minijack ×...
  • Page 24 Printed on 70% or more recycled paper using VOC (Volatile Organic Compound)-free vegetable oil based ink. Printed in Malaysia...
