Summary of Contents for Microgate LINKGATE EncRadio SF
- Page 1 INKGATE EncRadio SF & DecRadio SF User Manual Microgate s.r.l. Via Stradivari, 4 Stradivaristr. 39100 BOLZANO - BOZEN ITALY...
- Page 2 LINKGATE EncRadio SF & DecRadio SF Doc: ENC_SF_R_200_000 User Manual Version: 2.0 Page 2 of 12...
-
Page 3: Table Of Contents
INDEX ............................... 3 INTRODUCTION............................4 FIELD OF USE AND HOMOLOGIZATION................... 4 ENCRADIO SF............................5 DECRADIO SF............................6 LINKGATE ENCRADIO SF: SAFETY FEATURES FOR RADIO TRANSMISSION ......7 6.1..............7 IGITAL TRANSMISSION OF IMPULSES SWITCHING ON............................8 CHANGING LINKGATE ENCRADIO SF SETTINGS ................9 IMPULSE TRANSMISSION ........................ -
Page 4: Introduction
LINKGATE system the ideal instrument for training and competitions at every level. Linkgate EncRadio SF and DecRadio SF represent a further innovation with respect to the well- known and highly esteemed Linkgate Encoder and Decoder. The evolution of the products has... -
Page 5: Encradio Sf
< ON/OFF > key for switching on/off Led di segnalazione ricarica accumulatori Connettore Jack per ricarica accumulatori Coperchio per accesso al connettore di programmazione (riservato MICROGATE) Boccola VERDE per ingresso segnali Boccola NERA per segnale di Massa Connettore TNC per collegamento antenna esterna... -
Page 6: Decradio Sf
LINKGATE EncRadio SF & DecRadio SF Doc: ENC_SF_R_200_000 User Manual Version: 2.0 Page 6 of 12 5. DecRadio SF Figure 2 TNC for external antenna connection 5 pole Nucletron connector for Radio output... -
Page 7: Linkgate Encradio Sf: Safety Features For Radio Transmission
LINKGATE Encoder SF offers a number of innovative solutions: 6.1. Digital transmission of impulses Linkgate EncRadio SF transmits sets of data (no longer a single impulse) that contain a vast amount of information. In particular, the following are transmitted: •... -
Page 8: Switching On
The transmission channel is used to make sure that only Racetime2 or REI2 chronometers with the same reception channel setting can receive the transmitted signal as valid. Every Microgate chronometer allows you to view the channel currently selected. By selecting the same number on the EncRadio SF that you wish to use, you will be certain of receiving only the signals from your own timing system. -
Page 9: Changing Linkgate Encradio Sf Settings
LINKGATE EncRadio SF & DecRadio SF Doc: ENC_SF_R_200_000 User Manual Version: 2.0 Page 9 of 12 8. Changing Linkgate EncRadio SF settings Changes in settings can be made by keeping an arrow key pressed down while switching on the device with the ON/OFF key. -
Page 10: Impulse Transmission
BLACK banana jack as a ground and the GREEN banana jack as the signal. At the end of data transmission, the Linkgate EncRadio SF will emit a BEEP. 10. Setting the bib number The two arrow keys can be used to set a bib number. -
Page 11: Linkgate Encradio Sf Technical Data
LINKGATE EncRadio SF & DecRadio SF Doc: ENC_SF_R_200_000 User Manual Version: 2.0 Page 11 of 12 12. Linkgate EncRadio SF technical data Weight 145g Size 100 x 50 x 40 mm (l x h x p) Operating temperature –25º/+70ºC Frequency 434.075 MHz... - Page 12 Uploder, Microrun, µFlasher, LinkPod, LinkGate, LinkGate encoder, LinkGate decoder, EncRadio, DecRadio, Polifemo, MicroSem, µSem, are registered marks of Microgate s.r.l. or of licensed users. Microgate s.r.l. reserves the right to modify the products described in this document and/or in the relative manuals without notice.
