SumoSecurity IP-WF-42M Connection Setup

2.1mp hd wireless 4 camera kit nvr security system

Sumo

Security

Powerful Defense

NVR Connection Setup

Connect a HDMI cable from the NVR to a monitor / television. Connect a Cat5e / 6 cable from

the NVR to the LAN port of a router. Plug in the included USB mouse to the NVR. Plug in the

power adapter to a power outlet. Note: A 2TB surveillance hard drive is preinstalled in the

NVR. USB and SD card ports are also provided for backing up onto external media

Antenna

Monitor / Television

SD Card

VGA

Storage

HDMI

12V

WAN

Cat5e / 6

Antenna

Power Adapter

LAN 1

LAN 2

LAN 3

Router

Table of Contents

Do you have a question about the IP-WF-42M and is the answer not in the manual?

Page 1 Sumo Security Powerful Defense NVR Connection Setup Connect a HDMI cable from the NVR to a monitor / television. Connect a Cat5e / 6 cable from the NVR to the LAN port of a router. Plug in the included USB mouse to the NVR. Plug in the power adapter to a power outlet.
Page 2 Sumo Security Powerful Defense Camera Setup Install the camera inside or outside. The camera has an ingress rating of IP66 and can be installed outside in the elements. Plug in the power adapter to an available power source. The NVR will automatically detect the wireless camera. No pairing is necessary. In case the IP camera is not detected, the NVR user interface has an option to pair cameras.
Page 3 Sumo Security Powerful Defense Mobile Setup Launch the app and add the Download the free RXCamView app on your smartphone or tablet NVR by clicking on Device Click on the icon and select Fill in all the relevant elds. For the Manual for adding the NVR Device...
Page 4 Sumo Security Powerful Defense Mobile Setup Click the gear icon Turn on push noti cations by clicking Alarm Toggle to green to enable push noti cations...
