EXTREME 120
For optimum
performance use:
Synthetic Gut
Total String Length: 8,1 m / 26,6 ft
String Pattern:
12 Main (4,6 m / 15,1 ft)
17 Cross (3,5 m / 11,5 ft)
Rec. String Tension: 11-13 kg / 24-29 lbs
Main Strings
Start at the top with the center holes L + R29. For the right side of the main strings
clamp 2,4 m (7,9 ft) string at hole R29. Tighten two main strings right, two main
strings left, and so on, skipping holes L + R6 as well as
L + R7. Tie off at holes L + R26.
Cross Strings
Tie on the cross string at hole R25 and lace string through hole R23. Tighten all
cross strings in direction of racquet throat, skipping holes L + R8. Tie off at hole L4.
