dōTERRA Laluz GH2168 Instruction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Laluz
™

Advertisement

loading
Need help?

Need help?

Do you have a question about the Laluz GH2168 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for dōTERRA Laluz GH2168

Summary of Contents for dōTERRA Laluz GH2168

  • Page 1 Laluz ™...
  • Page 3 Overview Mist Outlet Inner Lid Top Cover Timer Indicator Light Control Button Power/Timer Button Mist Control Button Max Water Level Marker Water Tank Mist Plate Main Body DC Socket Air Inlet Adapter...
  • Page 4 Instructions For Use Place aroma diffuser on a flat, water-resistant surface when operating. 1. Remove Top Cover and Inner Lid from the Main Body. 2. Insert the Adapter’s DC connector into the DC Socket located on the bottom of the diffuser. 3.
  • Page 5 4. Replace Top Cover and Inner Lid by aligning onto Main Body. 5. Plug the AC end of the Adapter into an electrical wall outlet. 6. Turn on and begin diffusing. (see “functions” for instructions) NOTES: • The unit will automatically shut off completely when water level becomes too low.
  • Page 6 Features Ultrasonic vibrations transform water and essential oil into a powerful stream of aroma-infused mist. 1. Water Capacity: 120ml/4.06 fluid oz 2. Suggested Room Size: Up to 330Sq. ft/30Sq. m 3. Continuous Operation: Highest Mist Output: Up to 4 hours Lowest Mist Output: Up to 8 hours 4.
  • Page 7 Functions Power/Timer Button 1st press = ON Indicator light, Continuous Mist 2nd press = 1hr Indicator light, 1hr Timer Indicator On 3rd press = 2hr Indicator light, 2hr Timer Indicator On 4th press = 4hr Indicator light, 4hr Timer Indicator On 5th press = Mist Off *Timer Indicator light slowly dims off 10 seconds after last Power/Timer Button press.

  • Page 8: Cleaning And Maintenance

    Cleaning and Maintenance Before cleaning, turn the unit off and unplug the Power Adapter plug. When emptying the Water Tank, pour water from the opposite side of the Air Outlet. Clean the Water Tank and Mist Plate at least twice a week. Clean the Mist Plate in the Water Tank with a cotton cloth and neutral cleanser.

  • Page 9: Troubleshooting

    Troubleshooting Status Cause(s) Solution(s) Startup 1. Insufficient water 1. Fill water to the Max Water Level Marker. Failure/Early 2. Improper power cable connection 2. Unplug the Power Adapter plug Shutdown and reset carefully. Misting failure but normal light 1. Make sure the water level does not exceed the Max Water Level Marker.
  • Page 10 Cautions 1. Ensure the Inner Lid is properly on Water Tank and Top Cover properly sits flush on the Base. 2. It is normal for vapor volume to vary with the type of water and essential oil used, humidity, and/or air temperature. 3.
  • Page 11 10. Do not place the product in direct sunlight or close to a refrigerator, a fan, or other hot environment. 11. This product should not be operated by children unless supervised by an adult. 12. This product is not for medical purposes. DO NOT inhale the vapor directly from the Mist Outlet.

  • Page 12: Product Warranty

    Product Warranty dōTERRA One (1) Year Limited Warranty. dōTERRA’s warranty obligation for this product is limited to the terms set forth below: dōTERRA International, LLC (“dōTERRA”) warrants this diffuser against defects in materials and workmanship under normal use for a period of ONE (1) YEAR from the date of purchase by the original end-user purchaser (“Warranty Period”) provided the operation and maintenance strictly follow the instruction manual.
  • Page 13 CAN ICES-1/NMB-1 This ISM device complies with Canadian ICES-001 This device complies with part 18 of the FCC Rules (a) The interference potential of device or system: Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 14 • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help.
  • Page 16 model number: GH2168 Manufactured for: dōTERRA Intl., LLC 389 S 1300 W, Pleasant Grove, UT 84062 USA...
