- Page 1 INSTALLATION INSTRUCTIONS SUNRISE PLUG-IN DIGITAL DOOR CHIME Model No: CHM0166 Additional Door Presses: CHM0168 Black, CHM0169 White It is very important to install and operate this product according to the following instructions. Transmitter Receiver Exterior Door Press Indoor Chime Unit...
-
Page 2: Product Instruction
PRODUCT INSTRUCTION Thank you for purchasing this Smix Sunrise Plug-in Digital Door Chime. Simply plug the indoor chime to an AC outlet, mount the door press where needed and you are ready to go! The indoor chime can be expanded to work with up to 30 door presses or door chimes using a simple procedure in 10-15 seconds. -
Page 3: Package Contents
PACKAGE CONTENTS Receiver, Transmitter, 3V CR2032 button battery, and mounting kit. TECHNICAL SPECIFICATIONS Receiver Voltage: 220-240V AC Wattage: <2.0 Watts Working Frequency: 433.92 MHz Sound dB(A): 25-85 dB(A) Operating Range (Free Air): Up to 100m Transmitter Battery (included): CR2032 Working Power: <... - Page 4 SELECTING YOUR MOUNTING LOCATIONS Before fixing the products, check your desired locations can communicate first. The product is rated to operating up to a range of 100 metres in free air. The operating range will be reduced if the signal is transmitted through a number of walls or ceilings.
- Page 5 SETUP THE AUTO-LEARNING CODE What is Auto-learning Code? The Transmitter sends a wireless signal to the Receiver. The Receiver would automatically register and memorize the signal as an operation code. So the Transmitter can work with the Receiver by this code. Auto-learning Code Set Up - Operation for 1 Transmitter and 1 Receiver •...
- Page 6 It is important to remember that when you replace the run-out battery with new one that you may need to follow the same procedure of the auto-learning code set-up as above. NOTE: Interference from another similar door chime operating nearby: To reset all settings, press the Music Forward Button for 5 seconds, then pairing will be relieved and melody turn into the default music -Ding Dong.
-
Page 7: Structure Diagram
STRUCTURE DIAGRAM Product Diagram (Receiver) AC Plug Volume Control Music Backward Music Forward Speaker Product Diagram (Waterproof Transmitter) Mount Wall Bracket Ridge Points Waterproof Button Open From Here Screws... -
Page 8: Installing The Batteries
INSTALLING THE BATTERIES Battery Battery Slot Push Button Screws • Unscrew and lever the base off the top cover of the Transmitter. There is a small slot at the base of the unit to facilitate this. The base is held in place firmly, so some pressure may be required. It will not break, rather will pop open. -
Page 9: Operation
OPERATION Press the push button on the Transmitter unit once, it sends a wireless signal to the Receiver which will play the selected melody. The sound will stop as soon as the melody ends. For repeat sound, press the button again. -
Page 10: Electrical Compliance
ELECTRICAL COMPLIANCE This product complies to all relevant NZ/AU compliance standards. An SDOC (supplier compliance declaration) is available on www.simx.co.nz Type the product code into Search on the home page, this takes you to the item product page, a download link is located below the product details on that page.
