Dante Breakout and Headphone Amp – Quick Start Guide
klang.com/blog/products/klangquelle
KLANG:quelle | Quick Start Guide
Quick Start PDF Download
Download KLANG:quelle 19" | Quick Start
Manual PDF
Download KLANG:quelle (compact) | Quick
Start Manual PDF
We will show you how easy it is to setup
your new Dante enabled headphone amplifier
KLANG:quelle. With these 6 simple steps, we
will guide you through Dante tools installation
and audio routing so that you can enjoy
listening to your music with your favourite pair
of headphones in a quality you have never
experienced before.
What you need
1. PC or Mac (with Ethernet port or adaptor)
2. KLANG:quelle + Power Supply
3. Network cable
4. Dante Virtual Soundcard
5. Dante Controller
6. Music Player and tunes on your computer (iTunes, Cuppertino VOX, WinAmp,
Windows Mediaplayer...)
The Device
KLANG:quelle is available in either a compact house (approx ⅓ of 19" rack mount format)
and in a 19" rack mount with 8 additional XLR line level outputs.
The front has Volume Control knobs, TRS (tip ring sleeve) jack connectors (stereo, 6.3mm), a
Gain switch (–12dB | 0dB | +12dB) and a signal strength LED (green/red) for each of the four
independent stereo headphone channels.
1/8
Advertisement
Table of Contents
Summary of Contents for Klang X-KG-QUELLE-19
- Page 1 Windows Mediaplayer…) The Device KLANG:quelle is available in either a compact house (approx ⅓ of 19″ rack mount format) and in a 19″ rack mount with 8 additional XLR line level outputs. The front has Volume Control knobs, TRS (tip ring sleeve) jack connectors (stereo, 6.3mm), a Gain switch (–12dB | 0dB | +12dB) and a signal strength LED (green/red) for each of the four...
- Page 2 On the back side, KLANG:quelle is equipped with a network connector that hooks up to any standard RJ45 Ethernet cable or to a locking Neutrik EtherCON connector. It can be powered by either Power over Ethernet (PoE) or by an external switching DC power supply (included).
- Page 3 DVS is stopped. Step 3: Connect Device 1. Connect external power supply if your network does not already offer Power over Ethernet (PoE). 2. Connect CAT5e/CAT6 network cable to KLANG:quelle and to your computer or Dante enabled product/network. Step 4: Sample Rate...
- Page 4 3. Close the window. 4. Now do the same for KLANG:quelle and use the same sampling rate. Note: Dante devices can only be connected if they run at the same sampling rates. Step 5: Routing Connect (stereo) audio stream from sound source to KLANG:quelle Out Left and Right.
- Page 5 Set your system volume as low as possible. Avoid prolonged exposure to excessive sound pressure levels. Technical Data Compliance KLANG:quelle has been tested and found to comply with the requirements defined in: EN55103-1:2009, EN 55103-2: 2009, EN 55022:2006/CISPR 22:1997, CAN/CSA-CEI/IEC CISPR 22:02 and FCC 47 CFR, Part 15.
- Page 6 If you are unsure how to recycle this product please contact us and we will recycle the device for you. Dimension and Weight KLANG:quelle compact Weight: 0.9 kg Size (W/H/D): 12 / 4.5 / 19 cm Dimensions and Weight KLANG:quelle 19″...
- Page 7 Read more on how to route audio between Dante products. Find out how to connect KLANG products to your audio equipment directly or via digital audio format converters. Update Dante Firmware of your KLANG device including AES67 support and make it Dante Domain Manger (DDM) ready.
- Page 8 Thanks for using KLANG gear. We hope you find this tutorial helpful. Please let us know what connection examples you want to read about next. — contact@KLANG.com —END—...
