- Page 1 KODAK KODAK KODAK Portable Power Station Portable Power Station ppS100 pro ppS100 pro user manual please read this manual carefully before operating the product. please keep this manual with you for further reference.
-
Page 2: Table Of Contents
CONTENTS Set includeS introduction Safety inStructionS tranSportation Get to know your kodak ppS100 pro charGinG 6.1. what it can power 6.2. Battery indicator 6.3. charGinG via mainS power Supply charGinG via Solar panel technical SpecificationS uSinG the kodak ppS100 pro... -
Page 3: Set Includes
1. SET INCLUDES Item Quantity kodak portable power Station ppS100 pro 5.5mm dc5521 to cigarette lighter adapter ac charger instruction manual user manual Portable Power Station ppS100 pro... -
Page 4: Introduction
Station ppS100 pro a plug-and-play power supply. with 88.8 watt-hours of stored energy, you can keep appliances, or electronic devices running. the kodak ppS100 pro portable power Station is designed to keep you powered up outdoor in your rv during emergencies or power outages. -
Page 5: Safety Instructions
2. SAFETY INSTRUCTIONS observe these instructions to ensure safe usage. Explanation of symbols this symbol together with noncompliance may very likely lead DANGER means to serious injury or death. this symbol together with noncompliance may lead WARNING means to serious injury or death. this symbol together with noncompliance may lead CAUTION means... - Page 6 DANGER Do NOT disassemble, repair or modify the unit or the battery. doing so may result in electric shock, fire, etc. Do NOT place the unit close to or in a fire or expose it to heat. Keep out of direct sunlight. doing so may result in fire or injuries.
- Page 7 WARNING Use and store the unit only in a clean and dry environment. Do not use and store in dusty and wet environment. failure to do so may result in a short circuit, smoke or fire if metal dust or small metallic parts come in contact with the connections.
- Page 8 CAUTION if rust, peculiar odors, overheating or other abnormal circumstances are observed, stop using the unit immediately and contact the dealer or our customer service center. The unit complies with all legal requirements for transport of dangerous goods. the capacity of the lithium battery pack in the unit exceeds 80 wh. Based on international standards: if this unit is to be sent by airplane, it must be transported in accordan- ce with iata standard packaging.
-
Page 9: Transportation
4. TRANSPORTATION 1. Carry the unit with both hands. ATTENTION ATTENTION keep the unit away from take extra care to ensure that the unit is never other objects when moving. allowed to fall to the ground. 2. Placing the unit on a stable surface. ATTENTION place the unit on a stable surface. -
Page 10: Get To Know Your Kodak Pps100 Pro
5. GET TO KNOW YOUR KODAK PPS100 Pro Button and connector explanations a. ac output on/off Button B. ac indicator c. Battery-indicator d. power on/off Button e. led lightpanel on/off Button cooling vents G. input: 1x 3.5mm dc35135 input 15~24 v, 1.2 a max. -
Page 11: Charging
6. CHARGING Before use or storage, plug your kodak ppS100 pro into the wall until it is fully charged. if the display shows less than 20% capacity, plug it into a power source, like an ac outlet or a solar panel as soon as possible. -
Page 12: Charging Via Mains Power Supply
6.3. CHARGING VIA MAINS POWER SUPPLY using the included ac wall charger, plug the unit into any wall outlet to charge the unit. you will know the unit is charging when the blue led battery indicators are blinking. the unit is fully charged when all battery indicators stop blinking and remain solid. -
Page 13: Using The Kodak Pps100 Pro
How to provide power for Type-C or USB devices with KODAK PPS100 Pro? connect the cable of your device to the type-c or one of the 4 uSB port of the kodak ppS100 pro. you can even use different ports simultaneously. - Page 14 How to provide power for DC 12V appliances (such as head lamp, fans) with KODAK PPS100 Pro? plug your appliances to the dc output port and press power switch button to gain power.
-
Page 15: Troubleshooting
• if you plug in devices that have a high power requirement, the charge level of kodak ppS100 pro can drop quickly and you will not be able to extract the entire 88.8wh of energy. -
Page 16: Frequently Asked Questions (Faq)
2. How do I know if my KODAK PPS100 Pro is charged? to check the charge level of your kodak ppS100 pro, refer to the battery indicator. the number of bars you see indicates the remaining power. kodak ppS100 pro can be used until it is empty but we recom- mend to recharge when the level is at one bar. -
Page 17: Storage And Downtime Maintenance
Gasoline, thinner, kerosene, petroleum, etc. have the characteristics of solvents. Do not use. 4. Failure failure to maintain your kodak ppS100 pro by following these steps can result in battery damage which will void the product warranty. 12. SERVICE LIFE OF LITHIUM ION BATTERIES Charge, supply current between -10 and 40°C (14 - 104 °F). -
Page 18: Disposal And Recycling
13. DISPOSAL AND RECYCLING Lithium ion battery as soon as the end of the battery‘s service life is reached, the entire lithium ion battery can be recycled. do not open or disassemble the unit. Electric device old electric devices may not be disposed together with normal household waste. according to the directive 2012/19/eu, the device must be disposed of in a controlled manner at the end of its service life. -
Page 19: Customer Service
14. CUSTOMER SERVICE Contact distributor for technical support / customer service europe [GBt Gmbh] an Gut nazareth 18a telephone: e-mail: 52353 düren +49 (0) 2421 / 20 85 60 info@gbt-international.com Germany uSa/canada [delta millenium inc.] 216 route 206 Suite 1 toll-free: e-mail: hillsborough, nJ 08844... - Page 20 © 2019 GBt Gmbh an Gut nazareth 18a, 52353 düren, Germany | phone: 02421 / 20856-0 the kodak trademark, logo and trade dress are used under license from kodak. qualcomm is a trademark of qualcomm incorporated, registered in the united States and other countries. quick charge is a trademark of qualcomm incorporated.
