Summary of Contents for HotHouse EHP-1000O
- Page 1 Instruction manual Aluminium radiator Smart Electric Heaters READ THIS CAREFULLY BEFORE USING THIS DEVICE FOR THE FIRST TIME. PAY ATTENTION: to avoid overheating, do not cover the appliance. EHP-1000O / EHP-1500O / EHP-1800O...
-
Page 2: Safety Advice
Do not use if the power cord, plug or appliance is damaged • The device should not be placed underneath a power outlet. • The power cable should never be in contact with hot parts of the device. EHP-1000O / EHP-1500O / EHP-1800O... - Page 3 • A repair involving the opening of the radiator can be made by the manufacturer or its distribution EHP-1000O / EHP-1500O / EHP-1800O...
- Page 4 7° to protect pipes from freezing Number of Insulation Model Power Voltage elements class EHP-1000O 1000W AC 230 50Hz Class II EHP-1500O 1500W AC 230 50Hz Class II EHP-1800O 1800W AC 230 50Hz Class II ONLY FOR USE INDOORS EHP-1000O / EHP-1500O / EHP-1800O...
-
Page 5: Replacing The Plug
L or coloured Red. The Blue wire must be connected to the terminal marker with the letter N or coloured Black. A 13amp Plug to BS 1363 must be fitted with a 13amp fuse to BS 1362. EHP-1000O / EHP-1500O / EHP-1800O... -
Page 6: How To Install The Device
How to install the device Make sure that the distance from walls and objects is respected. Figure 1a 1 – Drill holes in the wall by following the steps in Figure 1. Make sure they are all correct. EHP-1000O / EHP-1500O / EHP-1800O... - Page 7 5 – Attach the lower brackets with screws and place the radiator to the wall Warning: Before plugging in the unit make sure the radiator is properly attached to the wall. Otherwise problems can occur. 2 / Description 2.1 / The Control Panel - On / off EHP-1000O / EHP-1500O / EHP-1800O...
- Page 8 - setting time, day and temperature - Mode selection and programs - Increase of the selected Digit - Decrease of the selected Digit 2.2 / LCD display Hour Program name Program setting Timer EHP-1000O / EHP-1500O / EHP-1800O...
- Page 9 Selecting one daily program (from daily programs P1-P7) for every day in a week to combine a weekly program. Open window function: Once the open window function is on, the radiator will stop heating while the room temperature getting down 2 EHP-1000O / EHP-1500O / EHP-1800O...
- Page 10 Open window function can work in all the running programs when it turns on. 3 / FREE OPERATING MODE 3.1 – Use : Connect the unit to the mains, press the power switch on the back of the unit. EHP-1000O / EHP-1500O / EHP-1800O...
- Page 11 3.2 – Adjustment of day and time : • Press once , the hours are flashing, then use the buttons to adjust the hours, • Press again , the minutes are flashing, then use the buttons to adjust the minutes, EHP-1000O / EHP-1500O / EHP-1800O...
- Page 12 3.4 – How to use the timer Press for 3 seconds, the icon appears. At the same time the hour display flashes and will pass at 00:00. Using the buttons choose the operating time in steps of EHP-1000O / EHP-1500O / EHP-1800O...
- Page 13 3- Press once to confirm your choice NOTE : If after selecting the program, no button on the keyboard is activated for 5 seconds, the selection is confirmed automatically. 4.2 – Daily program : EHP-1000O / EHP-1500O / EHP-1800O...
- Page 14 The nine programs have been preset at the factory as follows: • for comfort , temperature of 22ºC • for economic , temperature of 17ºC • for frost , temperature of 7ºC (this mode cannot be personalised !) EHP-1000O / EHP-1500O / EHP-1800O...
- Page 15 Press , then choose the program you want to personalise from , using Press for 3 seconds, the icon appears on the display. The first segment of 00 : 00 flashes. Example program P1 : EHP-1000O / EHP-1500O / EHP-1800O...
- Page 16 Then press the button for 7 seconds to reset the heater. 4.5 – Weekly programming : 1- Press once. 2- Choose the daily program by using 3- Press once to confirm your choice EHP-1000O / EHP-1500O / EHP-1800O...
- Page 17 (1 - to 7 Monday-Sunday) 4- After assigning the program to 7-Sunday, confirm your selection with . The icon disappears on the display. 5- The heater then operates in accordance with the new weekly EHP-1000O / EHP-1500O / EHP-1800O...
- Page 18 EU Directive 2002/96/EC. It will then be recycled or dismantled to minimize impacts on the environment. Electrical and electronic products are potentially harmful to the environment and human health due to the presence of hazardous substances. EHP-1000O / EHP-1500O / EHP-1800O...
- Page 19 For Information please contact: Please fill in the warranty form below to register your product. Once completed please send to: Hothouse products, Imperial Point Express Trading Estate, Stonehill Road, Farnworth Bolton, BL4 9TN Serial Number of Radiator: __________________________________________________...
