Pilgrim 18565 Assembly Instructions

Utility outdoor wood rack

STEP 1

Remove the Utility Outdoor

Wood Racks Upright. (fig1)

(Part #18565)

Utility Outdoor

Wood Rack 45" Extension

Item# 18564

Upright

(fig1)

STEP 2

Insert the Wood Rack 45" Extension pieces

into the Base Plates. (fig2)

STEP 3

Insert the Upright into the Base Plate. (fig2)

Wood Rack

45" Extension

Quantity = 2

Wood Rack 45"

Extension Base Plate

Quantity = 1

Upright

(fig2)

Table of Contents

Need help?

Do you have a question about the 18565 and is the answer not in the manual?

Page 1 STEP 1 Remove the Utility Outdoor Wood Racks Upright. (fig1) (Part #18565) Upright Upright STEP 2 (fig1) Insert the Wood Rack 45” Extension pieces into the Base Plates. (fig2) STEP 3 Insert the Upright into the Base Plate. (fig2) (fig2) Wood Rack 45”...
Page 2 “A” and “B” and press down. (fig. 5) STEP 6 Use the Large Allen Screws and attach the Hooks on the ends of parts “A” and “D”. (fig. 6) Small Allen Screw x 4 Utility Outdoor Wood Rack Item# 18565 3/2008...
