Summary of Contents for Derovis HydraIP APC-R
- Page 1 Installation Manual HydraIP APC-R module Manual Version: 1.2.0 Date: 23.11.2017 Read the manual carefully befor use! Keep the manual!
-
Page 2: Table Of Contents
HydraIP APC-R module Content 1. Installation 2. Installation of counting module ..........................4 Preparing the counting modules Application of templates and installation of counting ..........................5 modules Back door 2.2.1 ........................5 Front door 2.2.2 ........................11 ..........................12 Measuring the counting module 3. -
Page 3: Installation
HydraIP APC-R module Installation Installation This manual describes the installation of APC-R people counter modules using the Derovis counter module fixture using a Citaro standard bus. Only Derovis APC-R counting modules can be used for the Derovis Automatic People Counting system (APC). External devices can not be used. -
Page 4: Installation Of Counting Module
HydraIP APC-R module Installation of counting module Installation of counting module § Crosstip screwdriver Necessary tools § Template and pen § Measuring tape or folding rule § Oscillating tool § 5 mm-drill bit with drill (or cordless screw gun) §... -
Page 5: Application Of Templates And Installation Of Counting Modules
HydraIP APC-R module Installation of counting module Application of templates and installation of counting modules Please make sure there is sufficient space behind the cover for the counting module, the template has to be possibly adjusted a bit. 2.2.1 Back door The template should be centered above the door, about 20 cm from the top edge While determining the center, you should orient yourself to the door and not the cover. - Page 6 HydraIP APC-R module Installation of counting module Check again, using a measuring tape (or similar), if the cutout is sitting straight. Carefully cut out... Drill holes... Version: 1.2.0 Seite: 6 Datum: 23.11.2017...
- Page 7 HydraIP APC-R module Installation of counting module Trim edges and drill holes... Since the material is very weak, you should work very carefully. Clean thoroughly afterwards! Now you can place in the module fixture. Version: 1.2.0 Seite: 7 Datum: 23.11.2017...
- Page 8 HydraIP APC-R module Installation of counting module Place in the transparent protective cover from the backside It is absolutely necessary to clean the backside of the cover in the installation area of any dust! Next, the protective housing is set in place (the flattened side facing upward) and the six bolts of the long side with adquate washers and appropiate screws are prepared.
- Page 9 HydraIP APC-R module Installation of counting module The screws should be inserted diagonally and turned lightly! (7mm-hexagon socket screw bit). At the same time, you should make sure that the aluminum frame fits evenly against the cover on the other side.
- Page 10 HydraIP APC-R module Installation of counting module Insert and screw in the counting module with clean hands (in order to keep the white module clean). Next, roughly adjust the counting module (e.g.in the "Citaro": between the second and third "adjusting screw" hole (counting from the bottom)).
-
Page 11: Front Door
HydraIP APC-R module Installation of counting module 2.2.2 Front door Same installation process as the back door, but: The cutout should have a 2 cm gap from the top edge of the cover i.e. the top edge of the template should have a gab of 1 cm to the edge of the cover. -
Page 12: Measuring The Counting Module
HydraIP APC-R module Installation of counting module Measuring the counting module The installation height and angle of the camera has to be measured and written down for every door, while the covers are shut tight. The information is needed later for the software configuration of the cameras. -
Page 13: Interfaces
HydraIP APC-R module Interfaces Interfaces 14pin-connector (1) Pin no. Name Description I/O characteristics DID_OUT (4) Coding Pin 4 Output DID_IN(4) Coding Pin 4 Input DID_OUT(3) Coding Pin 3 Output DID_IN(3) Coding Pin 3 Input DID_OUT(2) Coding Pin 2 Output DID_IN(2) -
Page 14: Power Supply Of Counting Module
HydraIP APC-R module Power supply of counting module Power supply of counting module Use the male 14 pin connector (see Interfaces) to connect the power supply (12 V or 24 V) to the counting module. Negative terminal (GND) = Pin 13... - Page 15 HydraIP APC-R module Power supply of counting module The control circuit should be assembled with the the AMP-connector. Version: 1.2.0 Seite: 15 Datum: 23.11.2017...
-
Page 16: Setting Ip Addresses Of The Counting Modules
HydraIP APC-R module Setting IP addresses of the counting modules Setting IP addresses of the counting modules If you connect the 14pin connector and M12 connector the counter will automatically have the default IP address: 192.168.100.10. The IP addresses need to be set manually for every counting module. You can select an IP address by connecting a pair of Coding pins of the 14pin Connector plug. - Page 17 Derovis GmbH Tel.: +49 (0) 30 515 932 - 100 E-Mail: contact@derovis.de www.derovis.de...
