3.6V SCREWDRIVER KIT

Article No. 612323

Model No. S010

ORIGINAL INSTRUCTION MANUAL

Please read these instructions fully before starting assembly.

HHGL Limited, MK9 1BA; HHGL (ROI) Limited, D02 X576

Technical Support & Parts

01904 727509

Mon-Fri 9am-5pm Sat-Sun 11am-4pm

www.coreservice.co.uk

July 21

Table of Contents

Need help?

Do you have a question about the S010 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sovereign S010

Page 1 3.6V SCREWDRIVER KIT Article No. 612323 Model No. S010 Technical Support & Parts 01904 727509 Mon-Fri 9am-5pm Sat-Sun 11am-4pm www.coreservice.co.uk ORIGINAL INSTRUCTION MANUAL Please read these instructions fully before starting assembly. HHGL Limited, MK9 1BA; HHGL (ROI) Limited, D02 X576...
Page 2: Table Of Contents
CONTENTS Contents General safety warnings Warning symbols In the box Operation Maintenance and storage Technical data Recycling and disposal Getting help Warranty...
Page 3: General Safety Warnings
GENERAL SAFETY INFORMATION WARNING! Read all safety warnings, provided with this power tool. Failure to follow all instructions listed below injury. Save all warnings and instructions for future reference. The term 'power tool' in the warnings refers to your mains-operated (corded) power tool or battery- operated (cordless) power tool.
Page 4 Unmodiﬁed plugs and matching outlets will reduce risk of electric shock. b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded. c.
Page 5 or medication. A moment of inattention while operating power tools may result in serious personal injury. b. Use personal protective equipment (PPE). Always wear eye protection. Protective equipment, such as a dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
Page 6 h. Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles. A careless action can cause severe injury within a fraction of a second. 4) Power tool use and care a.
Page 7 power tool repaired before use. Many accidents are caused by poorly maintained power tools. f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control. g. Use the power tool, accessories and tool bits, etc., in accordance with these instructions, taking into account the working conditions and the work to be performed.
Page 8 one terminal to another. Shorting the battery terminals together may cause burns or a ﬁre. d. Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, ﬂush with water. If liquid contacts eyes, additionally seek medical help.
Page 9 Screwdriver safety warning a. Hold the power tool by its insulated gripping surfaces, when performing an operation where the cutting accessory may contact hidden wiring. Cutting accessories that contact a 'live' wire may make exposed metal parts of the power tool 'live' and could give the operator an electric shock.
Page 10 Recharge only with the charger speciﬁed by SOVEREIGN. Do not use any charger other than that speciﬁcally provided for use with the equipment. A charger that is suitable for one type of battery may create a risk of ﬁre when used with another battery.
Page 11 p. Retain the original product literature for future reference. q. Dispose of properly. r. Do not mix cells of diﬀerent manufacture, capacity, size or type within a device. s. Do not use any cell which is not designed for use with the equipment. Safety warnings for the charger WARNING Read all safety warnings and all instructions.
Page 12 After charging, disconnect the battery charger from the supply mains. Then remove the chassis connection and then the battery connection. Do not charge a leaking battery. Do not use chargers for functions other than those for which they are designed. Before charging, ensure your charger is matching the local AC supply.
Page 13 4.5°C, or above 40.5°C. This is important, as it can prevent serious damage to the battery pack. 18. Charge only battery packs of the same model provided by SOVEREIGN and of models recommended by SOVEREIGN.
Page 14: Warning Symbols
WARNING SYMBOLS Warning Read the instructions Wear ear protection Wear eye protection Wear a dust mask Class II tool The product complies with the applicable European directives, and an evaluation method of conformity for these directives was done. Recycle unwanted materials instead of disposing of them as household waste.
Page 15 Do not subject the battery to strong sunlight over long periods of time. Do not leave on a heater (max. 45°C). Do not throw into water Do not throw on ﬁre The output plug has a positive centre pole and negative outer pole.
Page 16: In The Box
IN THE BOX Description 1. Chuck 2. Adjustable handle lock switch 8. LED light 3. Torque setting 9. Battery capacity indicator 4. Soft grip 10. Battery capacity button 5. Charging socket Accessories 1 piece 3-5hours charger 52 piece accessories 1 piece bit holder 9 10...
Page 17: Operation
OPERATION NOTE: Before using the tool, read the instruction book carefully. Intended Use This tool is intended for driving in and loosening screws. BEFORE PUTTING INTO OPERATION 1. CHARGING THE BATTERY (SEE FIG. A) NOTE: a) Do not use any charger other than that speciﬁcally provided for use with the equipment.
Page 18 IMPORTANT: When charging, the charger and screwdriver may become warm to the touch, this is normal and does not indicate a problem. WARNING! When the battery charge runs out after continuous use or exposure to direct sunlight or heat, allow time for the tool to cool down before re-charging to achieve the full charge.
Page 19 3. SWITCH LOCK (SEE FIG. D) This helps to reduce the possibility of accidental starting when not in use. To lock the switch, place the forward and reverse rotation selector in the centre position. 4. ON/OFF SWITCH screwdriver. 5. ADJUSTABLE HANDLE This tool can be used with a straight grip or pistol grip.
Page 20 6. USING THE SIGHTLIGHT 7. BATTERY CAPACITY INDICATOR Press the battery capacity indicator button to show the battery capacity. When the battery capacity indicator lights up red, the battery has less than 30% of its capacity and should be charged. Full power Green + Yellow + Red Full power but will require...
Page 21 The higher number on the collar, the higher torque and the larger fastener can be driven. To select any of the numbers, rotate the collar until the desired number aligns with the arrow head indicator on the housing.
Page 22: Maintenance And Storage
MAINTENANCE AND STORAGE Your power tool requires no additional lubrication or maintenance. There are no user serviceable parts in your power tool. Never use water or chemical cleaners to clean your power tool. Wipe clean with a dry cloth. Always store your power tool in a dry place.
Page 23: Technical Data
TECHNICAL DATA Model S010 3.6V No-load speed Max. torque 3N.m Torque setting Charger YYYD-S05B0500600YU Input Output 0.6A Protection class Charge time 3~5hour Weight 0.5kg NOISE AND VIBRATION DATA A weighted sound pressure (L 66 dB(A), k=3dB(A) A weighted sound power (L...
Page 24 Using the correct accessory for the too,l and ensuring it is sharp and in good condition. The tightness of the grip on the handles and if any anti-vibration accessories are used. And the tool is being used as intended by its design and these instructions.
Page 25: Recycling And Disposal
RECYCLING AND DISPOSAL Waste electrical products should not be disposed with household waste. Please recycle where facilities exist. Check with your local authority or retailer for recycling advice. GETTING HELP Our dedicated UK-based customer helpline is open 7 days a week to assist you with assembly, parts queries and technical send an email via support@coreservice.co.uk.
Page 26: Warranty
WARRANTY This product is covered by a 1 year warranty. The warranty covers any manufacturing defect in materials, Any claim under this warranty must be made by going to your nearest Homebase store, taking your proof of purchase with you, and claims must be made within 12 months of the date of purchase.
