TECHNICAL MANUAL
MODEL: 61-724
The Service Information provides the following information:
• Precautions and safety information
• Specifications
• Performance test procedure
• Calibration and calibration adjustment procedure
• Basic maintenance (replacing the battery)
Form number: TM61724
Revision: 2. Date: September 2006
Form number TM61724
Rev 2 Sept 2006
Advertisement
Related Manuals for IDEAL INDUSTRIES 61-724
Summary of Contents for IDEAL INDUSTRIES 61-724
- Page 1 IDEAL INDUSTRIES, INC. TECHNICAL MANUAL MODEL: 61-724 The Service Information provides the following information: • Precautions and safety information • Specifications • Performance test procedure • Calibration and calibration adjustment procedure • Basic maintenance (replacing the battery) Form number: TM61724 Revision: 2.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Page Title Introduction Precautions and Safety Information Safety Information Specifications General Specification Voltage Specifications Current Specifications Resistance Specifications Frequency Specification Diode Specifications Continuity Specifications Performance Verification Calibration Clamp Jaw Alignment Figures Replacing the Battery Form number TM61724 Rev 2 Sept 2006... -
Page 3: Introduction
The information provided in this document is for the use of qualified personnel only. Caution The 61-724 contains parts that can be damaged by static discharge. Follow the standard practices for handling static sensitive devices. For additional information about IDEAL INDUSTRIES, INC. and its products, and services, visit IDEAL INDUSTRIES, INC. -
Page 4: Specifications
Page 2 General specifications Characteristics Description Display 3½ Digit LCD display Display Count 2000 count, maximum reading 1999 Overrange Indication “OL” is displayed Sampling Rate 2.5 time/second Operating Environment: 0°C to 50°C (32°F to 122°F) Relative Humidity 0 ~ 75% RH Storage Environment: -20°C to 60°C (-4°F to 140°F) at <80% relative humidity Power source:... -
Page 5: Performance Verification
Page 3 PERFORMANCE VERIFICAITONS Perform the following analysis, if the meter conforms to the limits listed in Table 1 the meter is functioning correctly. If the meter does not conform to any of the listed limits the calibration procedure must be performed. -
Page 6: Calibration
Note: Use care to keep the Jaw (CT) of the unit properly centered to the Source 3. Adjust R62 until the display reads 100.0 ± 2 digit Calibration of the 61-724 is complete. Remove all leads from the calibrator and equipment. -
Page 7: Clamp Jaw Alignment Figures
Page 5 Placement of source for DC Balance Calibration Battery Replacement (refer to Figure 2) 1. Disconnect the test leads from any circuit under test and turn off meter. 2. Use a Philips head screwdriver to remove the two screws on battery cover 3.
