- Page 1 PicoDrive P40 PD; P41 PD; P42 PD; P43 PD; P44 PD INSTRUCTION MANUAL Part 3 Parameter list This instruction manual applies to drives from the following software version onwards: P40 PD - P44 PD # 4_040_11 296-12-18 979/002 Betriebsanleitung engl. 10.10...
-
Page 2: Table Of Contents
Electrical connections diagram X5 PD / P41 PD / P44 PD ..........13 The reprinting, copying or translation of PFAFF Instruction Manuals, whether in whole or in part, is only permitted with our previous authorization and with written reference to the source. -
Page 3: Survey And List Of Parameters
Explanation Survey and List of Parameters Explanation of Parameter Survey The parameter survey is designed as an aid for fi nding parameters quickly. It is a summary of references for the parameter list. Listed behind each reference are all parameters which exert an infl... -
Page 4: Overview Of Functions And Parameters P40Pd - P44Pd
After a Master Reset 3 all parameters are set back to there default values! With the control box P40PD - P44PD, following machine classes are available: Machine class 1 = PFAFF 1163 = P43PD Machine class 2 = PFAFF 1180 = P40PD... - Page 5 Overview of functions- / parameters Function Parameter Function Parameter Photocell 111, 112, 113, 199, 615 Accelerate Piece counter Affichage 180, 605, 795, 933 105, 110, 364, 523, Presser foot 427 , 636, 642, 651, 668, Backtack 584, 585 688, 719, 729, 730, 770 Program 206, 313 Backtack inversion...
-
Page 6: List Of Parameters For The Control Unit P40 Pd - P44 Pd
List of parameters List of parameters for the control unit P40 PD - P44 PD 4_040_11 User Function Setting range Set valu Machine class level Speed for front backtack / stitch conden- 0300 - 2000 1200 Kl. 1, 3 sation 0300 - 2000 1600 Kl. - Page 7 List of parameters User Function Setting range Set valu Machine class level Output Ax is 0001 - 0004 Kl. 1, 2, 3, 4, 5, 6 1 = wiper Kl. 7 2 = thread clamp 3 = motor runs 4 = lifting puller Operating mode of the input E4 0001 - 0003 Kl.
- Page 8 List of parameters User Function Setting range Set valu Machine class level Backtack Kl. 1, 2, 3, 4, 5, 6, 7 ON = four times , OFF = double Speed limitation 0300 - 4800 1000 Kl. 1, 2, 3, 5, 7 0300 - 4800 Kl.
- Page 9 List of parameters User Function Setting range Set valu Machine class level Target stitch before sewing Kl. 1, 2, 3, 4, 5, 6, 7 ON = yes, OFF = no Run locking/stop Kl. 1, 3, 5, 7 ON = contact closed, OFF = contact open Kl.
- Page 10 List of parameters User Function Setting range Set valu Machine class level Timing output A5 (feed reverse) 0010 - 0090 Kl. 1, 2, 3, 7 0010 - 0090 Kl. 4, 6 0010 - 0090 Kl. 5 Acceleration ramp 0001 - 0030 Kl.
- Page 11 Set valu Machine class level 799* Machine class which has been selected 0001 - 0007 Kl. 1 (PFAFF 1163) 0001 - 0007 Kl. 2 (PFAFF 1180) 0001 - 0007 Kl. 3 (PFAFF 1122) 0001 - 0007 Kl. 4 (PFAFF 591) 0001 - 0007 Kl.
- Page 12 List of parameters User Function Setting range Set valu Machine class level Additional P-Amplifi cation of the speed 0005 - 0050 Kl. 1, 2, 3, 4, 5, 6, 7 control Switchover of display on screen 0000 - 0004 Kl. 1, 2, 3, 4, 5, 6, 7 Rate time (premature change-over) for the 0010 - 0200 Kl.
-
Page 13: Electrical Connections Diagram X5 Pd / P41 Pd / P44 Pd
Electrical connection diagram Electrical connections diagram X5 PD / P41 PD / P44 PD +15V +24V 500 mA 500 mA 500 mA 500 mA 500 mA 500 mA +24V 500 mA 500 mA +24V... - Page 14 Electrical connection diagram Bedeutung der Magnete bzw. Magnetventile, Taster / Meaning of magnets and/or solenoids and keys Signification des aimants resp. solenoides et touches / Significação dos imaõs e/ou as solenoidas e teclas Significato dei magneti, delle valvole magnetiche e dei tasti / Significación de los imanes y/o los solenoides y pulsadores / Betekenis van de magneten resp.
- Page 15 Electrical connection diagram Bedeutung der Magnete bzw. Magnetventile, Taster / Meaning of magnets and/or solenoids and keys Signification des aimants resp. solenoides et touches / Significação dos imaõs e/ou as solenoidas e teclas Significato dei magneti, delle valvole magnetiche e dei tasti / Significación de los imanes y/o los solenoides y pulsadores / Betekenis van de magneten resp.
