Merit Megatouch FORCE Technical Reference Manual

OBSERVE PRECAUTIONS FOR HANDLING ELECTROSTATIC DEVICES
(Fun Zone games and Fusion games with electronic boxes)
1. Turn off and unplug the game.
2. Unlock and open the bezel.
3. Remove the 6 thumbnuts fastening the bezel to the game (see Figure 1) and remove the
bezel.
4. If you will not be reusing the existing touchscreen, remove the cable clamps securing the
touchscreen cable and the touchscreen power harness, then remove the screws fastening the
touchscreen controller (see Figure 4) to the game and disconnect the cable from the back of
the controller. Locate and disconnect the Molex connector (orange and gray wires) running
from the touchscreen controller cable to the main power harness, and also disconnect the
ground screw. See Figure 1.
If you will be reusing the existing touchscreen, disconnect the touchscreen controller cable
from the LCD panel (see Figure 1). Then use dental floss to carefully cut the foam tape
holding the touchscreen to the monitor until you are able to completely remove the screen.
You will need to place the touchscreen on a stable surface until it is installed on the new
monitor. Then remove any residual foam tape from the reverse side of the screen with denatured
alcohol.
5. Disconnect the VGA monitor connector and ground screw, as well as the monitor power
connector. Standard monitors only: Also disconnect the monitor control board connector. See
Figure 1.
6. Remove the 4 screws fastening the monitor to the game (see Figure 2) and remove it. Be
sure to keep track of the plastic standoffs under the monitor.
(Fun Zone games and Fusion games with electronic boxes)
1. With the plastic standoffs in place, install the new monitor in the game and fasten it with the 4
screws (see Figure 2).
2. Connect the VGA monitor connector and ground screw to the new monitor, as well as the
monitor power connector. Standard monitors only: Also connect the monitor control board
connector. See Figure 1.
3. If your replacement monitor already has a touchscreen, connect the touchscreen cable in the
back of the controller and secure the controller with the existing hardware. Also connect the
Molex connector (orange and gray wires) to the main power harness (after routing the wires
through the cable clamps) and attach the ground screw. See Figure 1.
If you are using the original touchscreen, clean the glass on the new LCD monitor with the
supplied alcohol wipe, then cut pieces of the supplied 1/2" foam tape long enough to cover
each edge of the monitor without overlapping. After the tape is in place on the monitor, peel
off the backing. Carefully place the touchscreen over the monitor in the same manner it was
attached to the old monitor, making sure the screen is properly and evenly aligned over the
Troubleshooting Information - Removal/Installation of Monitor -
Megatouch FORCE Technical Reference Manual
COPYRIGHT © 2004 MERIT INDUSTRIES, INC.
ATTENTION:
Removal/Installation of Monitor -
FORCE Upright Fusion/Fun Zone

Monitor Removal

Monitor Installation

FORCE Upright Fusion/Fun Zone
