Umbrella
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damage occurring to the parts.
We have taken great care in the design of this product and
request that you carefully and strictly follow our assembly
instructions to ensure a completed product as it was designed.
A.
Top
1 Pc.
Home Styles Consumer Assistance: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
B.
Bottom
1 Pc.
Advertisement
Table of Contents
Related Manuals for Home Styles 88 5560 66
Summary of Contents for Home Styles 88 5560 66
- Page 1 We have taken great care in the design of this product and request that you carefully and strictly follow our assembly instructions to ensure a completed product as it was designed. Part List Bottom 1 Pc. 1 Pc. Home Styles Consumer Assistance: www.homestyles-furniture.com, servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319...
- Page 2 Assembly Instructions STEP 1 Attach Top (A) to Base (B) with Flat Washer, Spring Washer and Nut. Flat Washer Spring Washer Tools required for assembly : 12 MM Wrench or Adjustable Wrench Home Styles Consumer Assistance: www.homestyles-furniture.com, servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319...
- Page 3 Assembly Instructions 2 Figure 1 STEP 1 Slide Bottom (B) into Top (A) by pushing in the pin on Bottom (B) and then, while holding the pin in, slide Bottom (B) into Top (A) until the pin pops out of the hole in Top (A). (See Figure 1) Knob Figure 2...
