Summary of Contents for Thermoray ISENTECH ITC200E
- Page 1 Smart Sensing Solution Provider Thermal Imaging Camera System Instruction Manual ITC200E Make sure to read and use the ‘Safety Precautions’ before using the product. Product warranty is included in the instruction manual.
-
Page 2: Cautions In Use
CAUTIONS IN USE v Cautions of safety Do not use for any purpose other than temperature measurements. § Do not disassemble arbitrarily. This may cause electric shock or fire. Product § warranty and repair may be penalized. Do not touch parts that have been compromised by product damage. It may §... - Page 3 v Equipment Installation Location This product is affected by the environment in which it is used as an electronic device (camera), it can be significantly affected by temperature and humidity. § It maintains a normal temperature (20°C and 25°C) and has ideal accuracy when installed in a room with a relative humidity of 50% or less.
-
Page 4: Product Components
Product Components Install SW Thermal Imaging Camera USB Cable Tripod User Manual Thermoray Install SW... - Page 5 v Component Name – Thermal Imaging Camera Lens Thermal Imaging Camera tightening port Micro 5pin port Camera pin port...
- Page 6 v Component Name - Tripod Camera fixing pin Camera fixing screw Camera direction fixing screw Camera direction adjuster Height adjuster...
- Page 7 We offer S/W for Windows so you can use your PC with minimal space on the tripod. S/W for Windows OS can be downloaded via the archive at THERMORAY homepage(www.thermoray.co.kr). The installation method of the product is based on the use of the tripod of the existing [MT-01] model, and the installation method is as follows.
- Page 8 § When the thermal imaging camera screen appears, wait 5 to 10 minutes for equipment optimization. v To exit § Double-click “THERMORAY” brand image on the upper left of the main surface of the program. § Click “Yes (Y)” when the exit window appears.
- Page 9 Set up a program v To set up The program setting button is located on the upper right of the main screen, and the method for setting the program according to the usage environment is as follows. § Place the metric reference article at 1.0m or 1.5m from the instrument. §...
-
Page 10: Program Configuration
Program Configuration v Windows OS-only programs The program structures for Windows-based desktop PCs and laptop PCs are as follows. Main Screen Setting Screen... - Page 11 v Program Configuration On the main screen, the thermal image is displayed, and the degree of the part recognized at the highest degree in the thermal image will be pointed out. You can also immediately check if the displayed temperature is in the desired temperature setting. See below for more information Description •...
- Page 12 v Program Configuration By accessing the Settings screen, users can determine various functions by focusing on the optimization to each environment in which the product is being used. In addition, a temperature correction function was added to measure the temperature more accurately. Description •...
-
Page 13: Product Specification
Product Specification v Thermal Imaging Camera 80mm 31mm 26mm 65mm Thermal Imaging Camera Resolution 206 X 156 (32K pixel) Measurement Distance 1.0m ~ 1.5m Field of View (FOV) 36˚ Temperature Range 20 ~ 45℃ (68 ~ 113℉) Accuracy ± 0.3℃ (30~42℃) @ 1.0m ~ 1.5m Frame Rate <... -
Page 14: Product Warranty
Product Warranty v Product Warranty This warranty is valid only for products purchased by authorized dealers (sales stores) and will not be reissued, so please be careful not to lose it. This warranty provides free warranty coverage within the stated period, please check [Compensation Regulations]. - Page 15 v Compensation Rules Paid/free warranty service provided accordance with compensation rules below. Content Type Within Warranty After Warranty Period Period Failure within 10 days of Product exchange or purchase refund Failure within 1 month of Product exchange or purchase free warranty service Not Applicable If the replaced product Refund...
- Page 16 Service Hour : 9 AM ~ 7 PM (M~F) ISENTECH Co.,Ltd 88, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, Republic ofKorea, 16681 v Online Inquiry www.thermoray.co Visit Thermoray website to find various information such as product use, AS-related, and product SW upgrade. Customer Service Support cs@thermoray.co...
- Page 17 Smart Sensing Solution Provider ‘THERMORAY’ is filed as trademark rights domestically and internationally. Copyright ⓒ 2020 ISENTECH Co., Ltd. All Rights Reserved...
