The Multilander Logging Trailer is available in five (5) configurations shown below. Each configuration can be further customized with additional accessories such as a cant hook mount, a ball mount hitch kit, and a universal mounting kit. Contact Woodland Mills or visit our website for information and pricing. 1. LOGGING TRAILER 3.
2020-2021 Multilander ™ Accessory Manual OVERALL DIMENSIONS—MAX Multilander Pro Logging Trailer in its most expanded configuration: • Widest track width: 60 in • Longest tongue extension: 151-½ inch overall length • Logging arms up 0002413-M-EN: Rev A Page 01-Dec-2021...
2020-2021 Multilander ™ Accessory Manual PRO LOGGING ASSEMBLY 1. TOOLS REQUIRED Tool Specification Wrench/Socket 8 mm Wrench/Socket 9 mm Wrench/Socket 10 mm Wrench/Socket 13 mm Wrench/Socket 14 mm Wrench/Socket 15 mm Wrench/Socket 18 mm Hex Key Set of Metric Hex Keys (e.g. 2-10 mm) Adjustable Wrench Variable Torque Wrench...
Accessory Manual 2. SHIPPING & UNPACKING When purchased on its own, the Multilander Pro Logging Kit ships in three (3) separate boxes (Pro Logging Kit, Telescoping Boom, and Winch) as shown below. When purchased as the Multilander Pro Logging Trailer configuration, the three (3) boxes ship stacked with the Multilander Logging Trailer as shown below.
2020-2021 Multilander ™ Accessory Manual 3. LOG SUPPORTS Using the components listed in the table below, assemble the four (4) log supports—two (2) per log rack—to the inside faces of the log racks on the trailer. Log Support Log Support Inner Spacer Outer Spacer Log Support...
Page 11
2020-2021 Multilander ™ Accessory Manual Discard flat washer—it is no longer required REMOVE M18 LOCK NUT & WASHER INSTALL BUSHING Teeth point toward centre of trailer INSTALL INNER SPACER INSTALL LOG SUPPORT See M18 Lock Nut note on next page INSTALL OUTER SPACER RE-INSTALL M18 LOCK NUT 0002413-M-EN: Rev A...
Page 12
2020-2021 Multilander ™ Accessory Manual INSTALL LOCKING PIN AND LINCH PIN LOG SUPPORT INSTALLATION COMPLETE M18 LOCK NUTS When re-installing the M18 lock nuts, rock the green logging arm up and down as the nut is tightened as shown to the left.
Page 13
2020-2021 Multilander ™ Accessory Manual REPEAT LOG SUPPORT INSTALLATION ON ALL FOUR CORNERS 0002413-M-EN: Rev A Page 01-Dec-2021...
2020-2021 Multilander ™ Accessory Manual 4. TELESCOPING BOOM If it was not installed during the Multilander trailer assembly, install the telescoping boom using the hardware below. Consult the Multilander Trailer Operator’s Manual for complete trailer assembly instructions. Chassis Clamp (50 mm Wide) M10 X 60 mm Telescoping Flanged Hex...
Page 15
2020-2021 Multilander ™ Accessory Manual Secure the boom to the tongue with the two (2) chassis clamps, four (4) M10 X 60 mm flanged hex bolts, and four (4) M10 flanged lock nuts. 0002413-M-EN: Rev A Page 01-Dec-2021...
Page 16
2020-2021 Multilander ™ Accessory Manual With the boom securely fastened to the tongue, slide the tongue into the trailer chassis up until the proper tongue extension point (L2-L5) based on the length of timber to be hauled. • Shorter logs = lower extension point (L2, L3) •...
Page 17
2020-2021 Multilander ™ Accessory Manual Using two (2) M12 X 80 mm flanged hex bolts, two (2) clamping disks, and two (2) M12 flanged lock nuts (part of Multilander Trailer assembly), securely fasten the tongue to the chassis. Ensure each clamping disk is centred in the large holes in the chassis and fully seated against the tongue when tight.
2020-2021 Multilander ™ Accessory Manual 5. LOGGING CAGE Using the hardware listed below, assemble the logging cage to the boom. M10 X 120 mm Logging Cage Hex Bolt M10 Flanged Storage Hook Lock Nut M10 Flat Washer Using the four (4) M10 X 120 mm hex bolts, M10 flat washers, M10 lock nuts, and the two (2) storage hooks, secure the logging cage to the boom.
2020-2021 Multilander ™ Accessory Manual 6. LOG RAMPS Mount the log loading ramps to the boom using the components in the table below. Log Ramp Leg Storage Clamp Hitch Pin Knob Linch Pin Attach the ramp legs to the boom by inserting the two (2) storage hooks into the rectangular slots in each leg.
Page 20
2020-2021 Multilander ™ Accessory Manual With the log loading ramp legs in the storage position, the hitch pins can be stored on the log racks (left or right side): Or the hitch pins can be stored on the ramp legs themselves: 0002413-M-EN: Rev A Page 01-Dec-2021...
2020-2021 Multilander ™ Accessory Manual 7. WINCH Install the winch into the receiver on the boom saddle and insert the bent clevis pin through both. Secure the clevis in place with the linch pin. Bent Clevis Pin Winch Linch Pin 0002413-M-EN: Rev A Page 01-Dec-2021...
2020-2021 Multilander ™ Accessory Manual OPERATION LOG LOADING RAMP SETUP To set up the trailer for side-loading logs, start by rotating all four (4) log supports to they are pointing straight up (teeth pointing toward trailer centreline) as shown below. REMOVE LOCKING PIN AND LINCH PIN ROTATE LOG SUPPORT UP 90°...
Page 23
2020-2021 Multilander ™ Accessory Manual Next, remove the hitch pins from the log racks if they are currently installed. The green logging arms need to be rotated down and the pins must be removed or they will hinder the arms’ rotation. Hinge Pin Rotate the two (2) green logging arms on...
Page 24
2020-2021 Multilander ™ Accessory Manual Install the ramp legs and re- install the hitch pins and linch pins to secure them. Move the winch from the boom saddle by removing the bent clevis pin and linch pins and place the winch post in the chassis receiver opposite the ramp legs.
Page 25
2020-2021 Multilander ™ Accessory Manual The log loading ramps and winch can be positioned to side-load logs from either side of the trailer depending on the requirements of the operator. 0002413-M-EN: Rev A Page 01-Dec-2021...
2020-2021 Multilander ™ Accessory Manual WINCHING A LOG When winching a log, route the rope as follows: a. Start at the winch → b. Route over the top of the log ↗ c. Around and underneath the log ↩︎ d. And then secure the winch hook to the eyelet located on the side of the grey index tube. Toggle Switch The winch is rated for 2500 lb and has two (2)
Next, turn to the Parts List section and locate the balloon number in the “Item” column: Record the part number (e.g. 0001071, HHB-MBM080FCJ, etc.) in the “Part No.” column. Contact Woodland Mills through the website (or via phone/email) and provide the list of part numbers, including quantities for each item.
2020-2021 Multilander ™ Accessory Manual PARTS LIST Item Part No. Description 0002390 BOOM SADDLE 0002391 BOOM SLEEVE 0004750 CLEVIS PIN, 15.5 mm DIA, 50 mm USABLE LG, 59 mm LG 0004760 COTTER PIN, HAIRPIN, 10-16 mm CLEVIS, 3 mm WIRE DIA 0002392 SWIVEL PIN, BOOM 0004707...
