- Page 1 DXM Enclosure Kit (DEK) Series Instruction Manual Original Instructions 223953 Rev. A 20 July 2021 © Banner Engineering Corp. All rights reserved 223953...
-
Page 2: Table Of Contents
5.1.1 Activate Cell Services ................................15 5.1.2 Create an Account .................................15 5.1.3 Add a Device to the Cellular Network ............................15 5.2 Banner Cloud Data Services (BannerCDS) ........................... 16 5.2.1 Activate Cloud Services ................................16 5.2.2 Create a New Gateway ................................. 16 5.2.3 Modifying the XML Configuration File ............................17... -
Page 3: Kit Contents
Banner Cell Data management portal. Access to a prepaid 90-day trial of the Banner Cloud Data Services web-based software is provided with an authorization code delivered with each kit. This software allows users to access, store, protect, and export critical data collected by the controller. -
Page 4: Controller Enclosure
DXM Enclosure Kit (DEK) Series 2 Controller Enclosure The DEK100 Series kit includes an enclosure assembly with the following parts already installed. • DXM Controller with USB programming cable • Lithium-Iron Phosphate (LiFePO ) battery with flying leads • LTE tape antenna threaded to the second SMA connector for the cellular module (on all models) •... -
Page 5: Install And Wire The Solar Panel
DXM Enclosure Kit (DEK) Series Figure 2. DEK100 internal layout 2.3 Install and Wire the Solar Panel 1. Install the solar panel's bracket. Figure 3. Solar panel bracket installation a) Open the packaging for the five-watt solar panel and assemble the aluminum mounting cleat with the arc facing out. - Page 6 DXM Enclosure Kit (DEK) Series Figure 4. Solar panel wiring a) Place the solar panel face down to prevent unplanned power applied to the kit. b) Remove the black sliding cover to expose the terminals. c) Wire the two-wire cable lead to the back of the panel. First, wire the blue lead to the negative terminal as marked on the plastic wiring chamber, then connect the brown lead to the positive terminal.
-
Page 7: Controller Details
DXM for your application. Banner's DXM Logic Controller integrates cellular connectivity and local I/O to provide a platform for the Industrial Internet of Things (IIoT). Inputs/Outputs—On-board universal and programmable I/O ports connect to local sensors, indicators, and control equipment. -
Page 8: Models
DXM Enclosure Kit (DEK) Series 3.1.2 Models Models Cellular Carrier ISM Radio Inputs and Outputs DXM100-A1-V Verizon Four universal inputs: Sinking/sourcing discrete, 4–20mA analog, 0–10 V analog, None DXM100-A1-A AT&T counter, and/or temperature with a 10 kOhm thermistor Four NMOS outputs, two 0–10 V analog outputs, and two DC Latching outputs DXM100-A2R1-V Verizon 900 MHz... - Page 9 DXM Enclosure Kit (DEK) Series Name Description Input A (+) connection for second external DC latching solenoid. Use I/O board Modbus register 2A. DLatch 2A 508 to control. 2B. DLatch 2B Input B (-) connection for second external DC latching solenoid Modbus Slave RS-485 (+) connection for host system as a Modbus master communicating to the S-.
-
Page 10: Configuration Instructions
DXM Enclosure Kit (DEK) Series 4 Configuration Instructions 4.1 DXM100-A Configuration Use the DXM Configuration Software to customize the configuration of the controller. Select the DXM100-A model when using the configuration software. To configure the DXM-100Ax, connect the DXM's USB to a computer. When the USB cable is plugged into the DXM Controller, the device is powered by the USB power. -
Page 11: Configuration Example: Reading Registers On A Modbus Slave Device
Figure 7. Traditional Setup opening screen Banner recommends disconnecting the COMM port through the Device menu before turning off power or disconnecting the USB cable. Use Device > Reboot to restart the DXM if needed; the tool automatically disconnects the COMM port, then reconnect it again. - Page 12 DXM Enclosure Kit (DEK) Series If the Cloud Permissions are set to Read, the web server only views data from the device and cannot write data to the device. If the permissions are set to Write, the web server only writes to the device and cannot read the data. If the permissions are set to Read/Write, the web server can read the data from the device and write to the device from the web.
-
Page 13: Save And Upload The Configuration File
DXM Enclosure Kit (DEK) Series 4.2.2 Save and Upload the Configuration File After making any changes to the configuration, you must save the configuration files to your computer, then upload it to the device. Changes to the XML file are not automatically saved. Save your configuration file before exiting the tool and before sending the XML file to the device to avoid losing data. -
Page 14: Conduct A Site Survey From The Dxm
If you find poor signal quality, common solutions include moving the DXM to a more central location relative to the Nodes or using higher-gain antennas on the DXM. Contact your local Banner Engineering representative for assistance. www.bannerengineering.com - Tel: + 1 888 373 6767... -
Page 15: Activating Services
The DEK Series kit uses a cellular network specifically designed for IoT devices that use low power, have minimal data consumption, and are low cost. Banner has created several tiers of service plans for IoT deployment. Select the appropriate plan size for the kit to avoid any data overage fees applied to your account. -
Page 16: Banner Cloud Data Services (Bannercds)
5. Read and accept the Services Access and Use Agreement. 5.2.2 Create a New Gateway After you log into the Banner Cloud Data Services website, the Gateway screen displays. Follow these steps to create a new monitoring site. 1. Click on +New Gateway. -
Page 17: Modifying The Xml Configuration File
2. Copy and paste the Site ID. The Site ID is that long string of numbers and letters from the Banner Cloud Data Services website. 3. Verify the Server Name/IP is set to push.bannercds.com and the Page is set to /push.aspx for sending to the website. -
Page 18: Upload The Xml Configuration File To The Website
Completing these steps creates continuity between the site created on the website with the DXM used in the field. The DXM pushes data to the website, which can be viewed at any time. Refer to the Banner Cloud Data Services Instruction Manual (p/n 178337) to review all the features available for monitoring, comparing data, and establishing warnings/alarms on the website. -
Page 19: Installation Instructions
DXM Enclosure Kit (DEK) Series 6 Installation Instructions 6.1 Install the Enclosure's Mounting Plate The DEK100 kit includes a custom mounting plate designed to be fastened to a pole with the included clamps or bolted to a wall or flat surface. 1. -
Page 20: Product Support And Maintenance
This device has been designed to operate with the antennas listed on Banner Engineering’s website and having a maximum gain of 9 dBm. Antennas not included in this list or having a gain greater that 9 dBm are strictly prohibited for use with this device. -
Page 21: Banner Engineering Corp. Limited Warranty
7.4 Banner Engineering Corp. Limited Warranty Banner Engineering Corp. warrants its products to be free from defects in material and workmanship for one year following the date of shipment. Banner Engineering Corp. will repair or replace, free of charge, any product of its manufacture which, at the time it is returned to the factory, is found to have been defective during the warranty period. This warranty does not cover damage or liability for misuse, abuse, or the improper application or installation of the Banner product. - Page 22 Index cloud data services settings 17 configuration file modify save modify 17 configuration file 17 configuration file 13 save 13 multiple registers 11 upload 13 registers 17 upload to website 18 configure upload cloud settings 17 configuration file 13, 18 create registers new site 16...
