- Page 1 QUICK GUIDE TREADREADER HANDHELD 3D SCANNER...
-
Page 3: Table Of Contents
Redefining tire measurement CONTENT 01 Warnings 02 CE marking and declaration of conformity 03 Disclaimer 04 Safe use of a laser product 05 Label and label position 06 Specifications 07 Contents 08 Scanner keypad and leds 09 Switching the scanner on and off 10 How to connect to the smartphone/tablet 11 Login/upload to TREADMANAGER... -
Page 4: Warnings
Use of this product other than as specified in the user manual may result in hazardous radiation exposure. The user manual can be found at treadreader.com/library. 02 • CE MARKING AND... -
Page 5: Disclaimer
03 • DISCLAIMER TREADREADER recommends only those applications of TREADREADER tyre measurement products as specified within TreadReader product literature, technical information, and warranty statements. TREADREADER accepts no liability for use of its products in applications other than those for which they are designed. It is the responsibility of the driver, or vehicle owner, or operator, to ensure tyres have sufficient tread depth, are defect free and are in a roadworthy condition. -
Page 6: Label And Label Position
Class 1, 660nm, visible laser, max power output is less < 0.1mW Operating temperature 0°C to 50°C (32°F to 122°F) Environmental rating IP54 Power 5V DC rechargeable Li-Ion battery Mobile device software Android version 5.1 or later requirement TREADREADER HANDHELD • QUICK GUIDE... - Page 7 07 • CONTENTS This product comprises: 1 x TREADREADER 3D hand held scanner 1 x Mobile device, software license (TREADREADER hand held scanner app is downloaded from App Store) 1 x Rigid plastic carry case 1 x Calibration check piece...
-
Page 8: Switching The Scanner On And Off
TREADREADER provides the mobile software application (app), TREADREADER HandHeld Scanner which can be downloaded from the app store, for phones or tablets to control the scanner. Switch on the hand held scanner. Launch the app on your phone or tablet. - Page 9 Direct mode: Allows for a one-to-one connection between the phone or tablet and the scanner. Once the direct mode has been selected a number of networks will appear on the app screen. Select the desired scanner (serial number located on rear of hand held).
-
Page 10: Login/Upload To Treadmanager Tm In The App
TREADMANAGER IN THE APP HandHeld app releases after 11.53.1.0 include the ability to upload scans to TreadManager. Android 6.0 or later is required for this option to be available. 1. When starting the app, the landing page will have a login to TREADREADER button below the direct mode/network mode option. - Page 11 When landing on the 4 scan page, the cloud icon will upload any scans completed.
-
Page 12: Entering Vehicle Registration
The 3D scan will be shown on the results screen together with colour-coded tread depth measurements (red, amber, green) and icons to indicate tyre type (summer or winter) and if uneven wear is detected. TREADREADER HANDHELD • QUICK GUIDE... - Page 13 A summary report can be saved or printed in PDF file format. The summary report shows the company logo and vehicle information, 3D tyre scans and tread depths produced by the hand held scanner, with an overall statement about the tire condition: Pass (green), advisory (amber) or fail (red).
- Page 14 TREADREADER HANDHELD • QUICK GUIDE...
-
Page 15: Charging
14 • CHARGING To check the battery power, press and hold the battery button on the scanner keypad. The battery status is then displayed as either green, amber or red. It is recommended to recharge the scanner battery as soon as the red battery LED is illuminated. To recharge the scanner, plug the USB 3 cable into the recharging port on the lid of the scanner by pulling back the circular rubber cover. -
Page 16: Calibration Check
This is located at the base of the scanner compartment in its carry case. To check calibration, place the scanner into its compartment in the carry case. Switch on the scanner. Ensure the app is connected to the scanner. TREADREADER HANDHELD • QUICK GUIDE... -
Page 17: Factory Reset
While the scanner is ON, hold simultaneously the POWER and wi-fi buttons for 5 seconds. The device will buzz for 3 seconds and switch off and restart automatically. 18 • FURTHER INFORMATION Please refer to TREADREADER for the user manual, which includes full user instructions and troubleshooting. - Page 18 Scan here to access this document in another language. www.treadreader.com TreadReader is a product of Total Shop Solutions , family of Snap-on® Incorporated. © 2020 Snap-on Incorporated a unique breadth of solutions to outfit any shop from floor to ceiling.
