90cm black glass wall canopy with roof cavity/external wall motor.

Advertisement

Quick Links

User Manual
anopy
INLCP92BGRCPACK
90cm Black Glass Wall Canopy with External Wall Motor
INLCP92BGEMPACK

Advertisement

loading
Need help?

Need help?

Do you have a question about the INLCP92BGRCPACK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Euromaid INLCP92BGRCPACK

  • Page 1 User Manual anopy INLCP92BGRCPACK 90cm Black Glass Wall Canopy with External Wall Motor INLCP92BGEMPACK...
  • Page 3: Table Of Contents

    Content 1…………………………………..………………………………Safety instructions 2…………………………………..………………………………Installation 3…………………………………..………………………………Start using your Rangehood 4…………………………………..………………………………Troubleshooting 5…………………………………..………………………………Maintenance and cleaning 6…………………………………..………………………………Environment protection SAFETY INSTRUCTIONS This manual explains the proper installation and use of your Rangehood, please read itcarefully before using even if you are familiar with the product. The manual should be keptin a safe place for future reference.
  • Page 4 Things not to do: instructions and all measurements Do not try to use the Rangehood followed. without the grease filters or if the filters are excessively greasy! by a competent person or qualified electrician. high level grill. lnerable to it. during use because overheated fats or oils might catch fire.
  • Page 5 touching the heating elements. should stay away unless they are under permanent supervision. Rangehood is for domestic use only. ntilation of the room when the Rangehood is used at the same time as appliances burning gas or other fuels. carried out in accordance with the instructions If the supply cord is damaged, it must of air have to be fulfilled.
  • Page 6 IMPORTANT INFORMATION Points to consider for installation remaining bits of debris and dust. themselves. Ensure the fan motor is level and there is no vibration when in use. 3. The location of the fan unit shall allow access for maintenance and repair. beyond the extent of normal steps or ladders.
  • Page 7 INSTALLATION - ROOF CAVITY MOTOR VERSION Schematic diagram Rangehood main body with the external cabinet by control wire, to achieve power on and off, and also speed switching. 2. The control wire is separated into 3 parts, the first two parts are fixed onto the main body and external cabinet, while the middle part is extension wire.
  • Page 8: Installation

    MOUNTING OF THE V-FLAP If the Rangehood -flap 1, you should mount the half- parts to its body. The -flap, the outlet may be various according to different models and configuration. • Mount two half-parts 2 into the body 6 •...
  • Page 9 2. The Rangehood should be placed at a distance of 65~75cm above the cooking surface for best effect. 3. Install the hook on a suitable place once the installation height is fixed, and keep it in line. The fixed position of the inside chimney bracket is the place of chimney. See pic 2.
  • Page 10 and be sure that the inside chimney can be adjusted the height in it freely, put the chimneys onto the Rangehood. See pic 5. 6. Equip the chimneys, fix the outside chimney bracket with 2 pcs 4*40mm screws, and use 2 pcs 4*30mm screws to fix the hood body. See pic 6. screws, and dismantle the outlet mesh cover, see pic 7.
  • Page 11 10. Screw 4 pcs 4*30mm screws to fix the external cabinet onto the ceiling. See pic 11 & 12. 11. Install the expansion pipe and fix it with cable tie. See pic 13. 12. Equip the expansion pipe to the outlet, and fix with cable tie. Lead one end of the expansion pipe which install on the external cabinet outlet to the of the motor extension wire should connect with the external cabinet control wire and the control wire of the main body top.
  • Page 12 n the connecting wire before repair, follow a. Rotate the lock catch of the connecting wire following the arrow direction. screws. See pic 15. 14. Installation is finished. See HINTS FOR EXHAUST DUCT INSTALLATION The following rules must be • Keep expansion pipe short and straight. •...
  • Page 13 INSTALLATION - EXTERNAL WALL HUNG MOTOR VERSION Schematic diagram achieve power on and off, and also speed switching. 2. The control wire is separated into 3 parts, the first two parts are fixed onto the main body and external cabinet, while the middle part is extension wire. 3.
  • Page 14 MOUNTING OF THE V-FLAP If the Rangehood does not have an -flap 1, you should mount the half- -flap, the outlet may be various according to different models and configuration. • Mount two half-parts 2 into the body 6 • a pin 3 should be top oriented; •...
  • Page 15 2. The Rangehood should be placed at a distance of 65~75cm above the cooking surface for best effect. 3. Install the hook on a suitable place once the installation height is fixed, and keep it in line. The fixed position of the inside chimney bracket is the place of chimney. See pic 2.
  • Page 16 and be sure that the inside chimney can be adjusted the height in it freely, put the chimneys onto the Rangehood. See pic 5. 6. Equip the chimneys, fix the outside chimney bracket with 2 pcs 4*40mm screws, and use 2 pcs 4*30mm screws to fix the hood body. See pic 6. 7.
  • Page 17 10. Install the expansion pipe onto the main body outlet and fix it with cable tie. main body top control wire. The plastic base of the control wire should be plugged to the bottom, and make the bucket to tight status. See pic 10. c.
  • Page 18 HINTS FOR EXHAUST DUCT INSTALLATION The following rules • Keep expansion pipe short and straight. • Do not reduce the size or restrict expansion pipe. • When using expansion pipe always install the pipe pulled taut to minimize pressure loss. to observe these basic instructions will reduce the performance and increase noise levels of the Rangehood.
  • Page 19: Start Using Your Rangehood

    the same size of fixing or mounting screw which are recommended in this instruction manual. with these instructions may result in electrical hazards. Start Using Your Rangehood LED touch control “ ” button, the button controls the “on” & “off” of the hood. “Speed”...
  • Page 20: Troubleshooting

    TROUBLESHOOTING Fault Possible Cause Solution Select a fan switch position. Light on, but motor service centre. does not work Motor failed centre. House fuses blown Reset/Replace fuses. Light does not work, motor does Refit cord to power outlet. not work disconnected Switch power outlet on.
  • Page 21 CONTROL PANEL SURFACE The inlay control panel can be cleaned using warm soapy water. Ensure the cloth is clean and well wrung before any excess moisture left after cleaning. Important s and avoid using harsh cleaning chemicals, strong household detergents or products containing abrasives, as this will affect the appliance appearance and potentially remove any printing of artwork on the control panel and will void manufactures’...
  • Page 22 BULB REPLACEMENT The bulb must be replaced by the manufacturer, its service agent or similarly qualified persons. any operations on the appliance. When handling bulb, make sure it is completely cooldown before any direct contact to hands. When handling globes hold with a cloth or gloves to ensure perspiration does not come in contact with the globe as this can reduce the life of the globe.
  • Page 24: Environment Protection

    ENVIRONMENTAL PROTECTION: This product is marked with the symbol on the selective sorting of waste electronic equipment. This means that this product must not be disposed of with household waste but must be supported by a system of selective collection in accordance with Directive 2012/19/E .
  • Page 25 Subject to the exclusions below, we warrant that the product will not have any electrical or mechanical breakdowns within: a) In the case of Euromaid products used for personal, domestic or household purposes, a period of 2 years from the date the product is purchased as a brand-new product from a retailer located in Australia / New Zealand.
  • Page 26 c) The repair relates to the replacement of consumable parts such as fuses and bulbs or any other parts of the product which require routine replacement; d) You are unable to provide us with reasonable proof of purchase for the product; e) the breakdown occurs after the expiry of the express warranty period set out in section 1 or f) the product was not purchased in Australia / New Zealand as a brand-new product.
  • Page 27 5. Warranty claims If you make a valid claim under this warranty and none of the exclusions set out in section 2 apply, we will, at our election, either repair the product or replace the product with a product of identical specification (or where the product is superseded or no longer in stock, with a product of as close a specification as possible).
  • Page 28 READ THE INSTRUCTION BOOKLET BEFORE INSTALLING AND USING THE APPLIANCE. The manufacturer will not be responsible for any damage to property or to persons caused by incorrect installation or improper use of the appliance. The manufacturer is not responsible for any inaccuracies, due to printing or transcription errors, contained in this manual.
