TRANSLATION OF THE ORGINAL VERSION
Operation Manual
DSG-D - Double Sided Mitre Fence
For use on sliding table saws according to the DIN EN 1870-18:2011-08 standard
DSG-D
Type:
HOKUBEMA Maschinenbau GmbH
Graf-Stauffenberg-Kaserne, Binger Str. 28 | Halle 120
DE 72488 Sigmaringen | Tel. +49 07571 755-0
E-Mail:
info@hokubema-panhans.de
| Web:
https://hokubema-panhans.de

Advertisement

Table of Contents
loading

Summary of Contents for Sitec DSG-D

  • Page 1 TRANSLATION OF THE ORGINAL VERSION Operation Manual DSG-D - Double Sided Mitre Fence For use on sliding table saws according to the DIN EN 1870-18:2011-08 standard DSG-D Type: HOKUBEMA Maschinenbau GmbH Graf-Stauffenberg-Kaserne, Binger Str. 28 | Halle 120 DE 72488 Sigmaringen | Tel. +49 07571 755-0 E-Mail: info@hokubema-panhans.de...

  • Page 2: Table Of Contents

    Further documentation ..........................9 Wall Bracket ..............................9 List of Illustrations Figure 1: Adjusting the DSG-D (1) ........................... 5 Figure 2: Adjusting the DSG-D (2) ........................... 5 Figure 3: Adjusting the DSG-D (3) ........................... 5 Figure 4: Adjusting the DSG-D (4) ........................... 6 Figure 5: DSG-D adjustment example ........................

  • Page 3: Functional Description

    Functional Description With the double-sided mitre fence DSG-D, mitre cuts can be made quickly and precisely. The wooden support block included in the scope of delivery enables tear-free cuts and further serves as an additional support during cutting, especially for narrow and short workpieces.

  • Page 4: Working With The Dsg-D

    Press-on screw Eccentric lever M8 screws Figure 2: Placing the DSG-D on the edging table Figure 3: Clamping the DSG-D on the edging table 1. Move eccentric lever to "handle up" position. 1. Loosen the two M8 screws. This ensures that the 2.

  • Page 5: Figure 1: Adjusting The Dsg-D (1)

    Adjusting the fence  Precise adjustment of the DSG-D fence is of enormous importance, as it affects the accuracy of all cuts made with it. To achieve optimum cutting results, always use sufficiently precise measur- ing equipment (e.g. vernier calliper) for adjustment.

  • Page 6: Figure 4: Adjusting The Dsg-D (4)

    9. The length measurement must correspond to position "0" (≙ 90°) on the angle scale ( Figure 4). 10. If the length measurement does not correspond to the "0" position, leave the DSG-D fence in the clamped state, loosen the screws of the scale, and move it until the 0 of the upper scale corresponds exactly to the measured value (...

  • Page 7: Figure 7: Set Factor By Scale

    This automatically results in the correct angle to the saw blade for the narrower workpiece (S) on the left side of the DSG-D and for the wider workpiece (B) on the right (refer  Figure 8). The corresponding sides for the narrow and wide workpiece are also shown graphically on the turntable plate.
  • Page 8 Length compensation X depending on mitre angle Angle (°) X (mm) Angle (°) X (mm) Angle (°) X (mm) 24.5 36.4 49.5 38.9 36.9 38.4 25.5 37.3 50.5 37.8 37.7 37.2 26.5 38.1 51.5 36.6 38.5 36.0 27.5 38.9 52.5 35.3 39.2 34.5...

  • Page 9: Calibrate Indicator To The Fence

    Further documentation and manuals for the digital display can be found on the manufacturer's website:  https://www.siko-global.com/en-de/products/magline-magnetic-linear-and-angular-measurement/electronic-displays/ma504-1 Wall Bracket The wall bracket for the DSG-D offers Clamping pins a practical way to store the fence within easy reach when not in use.
