BSH Thermador CEM456 Service Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

https://appliancetechmanuals.com

OFF

MED

OFF

HOT SURFACE

MED

CEM456

OFF

HOT SURFACE

MED

CEM365

OFF

HOT SURFACE

MED

CEM304

Service Manual

CEM/CET/CEP COOKTOPS

CEP456

CEP365 • CET365

CEP304 • CET304

for

PANEL

LOCK

PAN

ZONE

SIZE

SMART™

POWER

KEEP

WARM

PANEL

LOCK

PAN

ZONE

SIZE

SMART™

POWER

KEEP

WARM

PANEL

LOCK

PAN

ZONE

SIZE

SMART™

POWER

KEEP

WARM

Table of Contents

Need help?

Do you have a question about the Thermador CEM456 and is the answer not in the manual?

Questions and answers

Summary of Contents for BSH Thermador CEM456

Page 1 CEM456 CEP456 PANEL LOCK ZONE SIZE SMART™ HOT SURFACE POWER KEEP WARM CEM365 CEP365 • CET365 PANEL LOCK ZONE SIZE SMART™ HOT SURFACE POWER KEEP WARM CEM304 CEP304 • CET304 Service Manual CEM/CET/CEP COOKTOPS © 2002 BSH Home Appliances Corp.
Page 2: Table Of Contents
https://appliancetechmanuals.com Table of Contents Cooktop Models..........1 - 2 Component D escription ........14 CEM Cooktops ............3 Electronic Touch Control Board ...... 15 CET Cooktops: ............4 Component D escription ........15 CEP Cooktops: ............5 Relay board ............16 Ceramic Cooktop Technical O verview .....
Page 3: Cooktop Models
https://appliancetechmanuals.com CEM/CET/CEP Service Manual Cooktop Models Cooktop Models HOT SURFACE HOT SURFACE CEM304 CEM365 HOT SURFACE CEM456 TYPE SIZE WATTAGE Single 6" (140 mm) 1200 W D ouble 5"/8" (120/210 mm) 750 / 2200 W D ouble 7"/8"(140/230 mm) 1100 / 2500 W Single 7"...
Page 4 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Cooktop Models Cooktop Models PANEL LOCK PANEL LOCK ZONE SIZE SMART™ ZONE SIZE SMART™ POWER KEEP POWER WARM KEEP WARM CET304 CET365 CEP304 CEP365 PANEL LOCK ZONE SIZE SMART™ POWER KEEP WARM CEP456 TYPE SIZE WATTAGE Single 6"...
Page 5: Cem Cooktops
https://appliancetechmanuals.com CEM/CET/CEP Service Manual Cooktop Models CEM Cooktops The CEM cooktops are mechanical models with a ceramic top and control knobs. The single radiant elements are controlled by the 1-cycle infinite switches. The dual elements are controlled by the 2-cycle infinite switches. The bridge element is controlled by a 2-cycle infinite switch and a relay (together they ser ve as a gang switch).
Page 6: Cet Cooktops
https://appliancetechmanuals.com CEM/CET/CEP Service Manual Cooktop Models CET Cooktops: The CET cooktop has a touch sensitive mono-control system. By touching the pads on the ceramic top, you select the mode of operation and the desired power level. The electronic touch control board interprets the selection and activates the single, dual, triple and bridge elements.
Page 7: Cep Cooktops
https://appliancetechmanuals.com CEM/CET/CEP Service Manual Cooktop Models CEP Cooktops: The CEP cooktop incorporates all the features of the cet cooktop plus zone smart. Z one smart senses the presence of cookware and selects the most appropriate sized element. Additionally, it turns the element off when the pan is removed.
Page 8: Ceramic Cooktop Technical Overview
https://appliancetechmanuals.com CEM/CET/CEP Service Manual Technical Overview Ceramic Cooktop Technical Overview The CEM/CET/CEP cooktops are comprised of the following components: Radiant Elements Single Elements D ual Elements Triple Elements Radiant Bridge Elements Infinite Switches 1-Cycle 2-Cycle Control Knobs Relay Board Electronic Touch Control Relay Board Pot Sensing Circuit Board H eat Limiters Sensors...
Page 9: Component Description
https://appliancetechmanuals.com CEM/CET/CEP Service Manual Component Description Component Description Radiant Elements A single element, illustration above, uses a wire ribbon that is located under the glass ceramic surface to provide the heat for cooking. The single element uses 1 wire ribbon. Radiant elements are designed to cycle on and off.
Page 10: Radiant Elements
https://appliancetechmanuals.com CEM/CET/CEP Service Manual Component Description Radiant Elements The triple element, illustration above, uses 3 wire ribbons to provide heat for cooking. There are 3 ribbons within the same heating area. You can select the inner, the inner and middle, or the inner, middle and outer elements.
Page 11: Infinite Switches
https://appliancetechmanuals.com CEM/CET/CEP Service Manual Component Description Infinite Switches There is 2 types of infinite switches. 1-cycle, and 2 cycle. The 1-cycle infinite switch controls the single element. The 1-cycle has an infinite number of heat settings between the low and high positions. D etents are found at low and high to define minimum and maximan heat settings.
Page 12: Relay Board
https://appliancetechmanuals.com CEM/CET/CEP Service Manual Component Description Relay board A relay board and a 2-cycle infinite switch are used to operate the bridge elements. The bridge element (4000 watts) draws 16 amps at full capacity. The 2-cycle infinite switch is rated at about 10 amps. The relay is wired in series with the infinite switch and the bridge element.
Page 13: Temperature Limiters
https://appliancetechmanuals.com CEM/CET/CEP Service Manual Component Description Temperature limiters Each element uses a temperature limiter to prevent the element from becoming too hot. The limiters have 2 sets of contacts, one is normally open, and one is normally closed. The normally open contact closes and turns on the hot surface light when the glass is too hot to touch.
Page 14: Component Description
https://appliancetechmanuals.com CEM/CET/CEP Service Manual Component Description Indicator lights There are two indicator lights on the ceramic cooktops. The O N indicator light turns on whenever any element is turned on. The light remains on until all the elements are turned off. (see illustration) Each element features a hot indicator light circuit to show when the cooking surface is too hot to touch.
Page 15: Sensors
https://appliancetechmanuals.com CEM/CET/CEP Service Manual Component Description Sensors: O n CEP models the sensors detect pan sensing and pan sizing. Pan sensing: The CEP models have sensors under the glass that detects if there is a metallic pan sitting on the element. The element will not heat if it is turned on without a pan present, or if the pan is removed from the element when it is operating.
Page 16: Component D Escription
https://appliancetechmanuals.com CEM/CET/CEP Service Manual Component Description Pot Sensing Circuit Board The pot sensing circuit board works with the electronic touch control board to sense the presence and the size of a pan on the burner. Heres how it works: The input board sends a signal to the sensor in each of the elements. W hen a pan is placed on the element,the sensor sends a signal back to the input board.
Page 17: Component Description
https://appliancetechmanuals.com CEM/CET/CEP Service Manual Component Description Electronic Touch Control Board The electronic touch control board is a microproccessor based control. It is comprised of 2 components, an input board, and a relay board. These 2 components are fastened together with stand off clips. There is a mylar sheet sandwiched between the 2 components.
Page 18: Relay Board
https://appliancetechmanuals.com CEM/CET/CEP Service Manual Component Description Relay board The relay board has snap relays, a step down transformer, a microproccessor chip and several zenner diodes. The stepdown transformer receives 120 v.a.c. and steps it down to 12 v.a.c.. The zenner diodes rectify the 12 v.a.c.
Page 19: Component Description
https://appliancetechmanuals.com CEM/CET/CEP Service Manual Component Description Input board The input board has three functions. First, it accepts mode and setting selections by the user. Second, it commands the relay board to perform the selected functions. And third, it outputs a signal voltage circuit to the element sensors to determine the presence of a pan , and the size of the pan.
Page 20: Installation
https://appliancetechmanuals.com Cooktop Installation CEM/CET/CEP Service Manual Installation CEM Cooktops stainless steel, 0.024 inch (0.6 mm) aluminum, or 0.020 OVERALL DIMENSIONS inch (0.5 mm) thick copper. Flame retardant materials bear the mark: See Illustration , Page . These dimensions are overall. UN D ERW RITERS LABO RATO RIES IN C .
Page 21 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Cooktop Dimensions CEM304 " / (505 mm) 20" / (508 mm) " / (731 mm) " / (734 mm) CEM365 " / (505 mm) 20" / (508 mm) " / (883 mm) " / (886 mm) CEM365 "...
Page 22 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Cooktop Dimensions underneath the countertop before tightening the INSTALLING THE COOKTOP bracket screws. 4. Center cooktop in the cutout to insure adequate WARNING: clear ance bet ween t he bur ner box and countertop edge. (A light pencil mark along the DISCONNECT POWER BEFORE...
Page 23 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Cooktop Installation PAGE 21...
Page 24: Cet/Cep Cooktops Installation
https://appliancetechmanuals.com CEM/CET/CEP Service Manual Cooktop Installation Installation CET/CEP Cooktops stainless steel, 0.024 inch (0.6 mm) aluminum, or 0.020 OVERALL DIMENSIONS inch (0.5 mm) thick copper. Flame retardant materials bear the mark: See Illustration , Page . These dimensions are overall. UN D ERW RITERS LABO RATO RIES IN C .
Page 25 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Cooktop Installation CET304 " / (505 mm) 20" / (508 mm) CEP304 " / (731 mm) " / (734 mm) CET365 " / (505 mm) 20" / (508 mm) CEP365 " / (883 mm) " / (886 mm) CEP456 "...
Page 26 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Cooktop Installation underneath the countertop before tightening the INSTALLING THE COOKTOP bracket screws. 4. Center cooktop in the cutout to insure adequate WARNING: clear ance bet w een t he bur ner box and countertop edge. (A light pencil mark along the DISCONNECT POWER BEFORE...
Page 27 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Cooktop Installation PAGE 25...
Page 28: Cooktop D Isassembly
https://appliancetechmanuals.com CEM/CET/CEP Service Manual Cooktop Disassembly Disassembly Uninstall and flip the cooktop over so the main top faces down. Remove the T20 screws then lift the base off. PAGE 26...
Page 29 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Cooktop Disassembly Disassembly After the screws are removed, lift off the bottom. CEP Bottom Off PAGE 27...
Page 30 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Cooktop Disassembly Disassembly Element Removal Remove T20 screw from brace. PAGE 28...
Page 31 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Cooktop Disassembly Disassembly Element Removal Mark the spring location with a magic marker. Loosen T20 screw to remove element. PAGE 29...
Page 32 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Cooktop Disassembly Disassembly Control Board Removal 2. Remove supports by lifting up and off. 1. Remove T20 Screws 3. Press in the clips. 4. Raise the wire blocks out of the frame. PAGE 30...
Page 33 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Cooktop Disassembly Disassembly Control Board Removal 5. Lift out the control module. PAGE 31...
Page 34 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Cooktop Disassembly Disassembly Mechanical Module PAGE 32...
Page 35: Cooktop Reassembly
https://appliancetechmanuals.com Cooktop Reassembly CEM/CET/CEP Service Manual Reassembly Install the center screw first, then install remaining screws. PAGE 33...
Page 36: Technical D Ata - Table Of Errors
https://appliancetechmanuals.com CEM/CET/CEP Service Manual Technical Data Technical Data Table of Error Messages The error message will show on the display clockwise. The assign between display and digit is dependend of the cooktop variants. Display Name Meaning The data that is transmitted to the shift registers to control the relays and the fan is watched permanently.
Page 37: Cet/Cep Residual H Eat On Time
https://appliancetechmanuals.com CEM/CET/CEP Service Manual Technical Data Technical Data Residual Heat on Time CET/CEP • • • • • • • minute minutes minutes minutes minutes minutes minutes Element ON Time Zone ON Time Setting Residual Heat Indocator ON Time 1 minute ..........32 minutes 2 minutes ..........36 minutes 5 minutes ..........46 minutes 10 minutes ..........
Page 38: Pot Sensing Calibration
https://appliancetechmanuals.com CEM/CET/CEP Service Manual Pot Sensing Calibration Pot Sensing Calibration CEP models have the “Z one Smart” (Pot Sensing) feature, and must be calibrated, or recalibrated, whenever the Electronic Control is replaced. To calibrate the cooktop, the “P7” Menu must be accessed, followed by the “P8” Menu. A set of calibration plates, each having a specific size, weight, and material, must be placed on their appropriate element locations during the calibration procedure.
Page 39 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Pot Sensing Quick Calibration POT SENSING QUICK CALIBRATION I. Touch and hold the PO W ER and LF (Left Front) element pads. The display will quickly flash a series of dashes. Immediately release only the LF (Left Front) element pad. The dashes on the display should now remain on continuously.
Page 40 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Pot Sensing Quick Calibration 5. Simultaneously touch the ZONE SMART pad and the number “3” Heat Setting pad and then release both pads. A flashing “U” will appear in the display. The unit will beep, and “P8U”...
Page 41 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Pot Sensing Quick Calibration 7. Simultaneously touch the ZONE SMART pad and the number “4” Heat Setting pad, then release the pads. A flashing “U” will appear in the display. When a beep sounds, the unit is properly calibrated. 8.
Page 42: Wiring And Visuals
https://appliancetechmanuals.com CEM/CET/CEP Service Manual Wiring and Visuals Wiring and Visuals PAGE 40...
Page 43 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Wiring and Visuals PAGE 41...
Page 44 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Wiring and Visuals PAGE 42...
Page 45 https://appliancetechmanuals.com...
Page 46 https://appliancetechmanuals.com...
Page 47 https://appliancetechmanuals.com...
Page 48 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Wiring and Visuals PAGE 46...
Page 49 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Wiring and Visuals PAGE 47...
Page 50 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Wiring and Visuals PAGE 48...
Page 51 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Wiring and Visuals PAGE 49...
Page 52 https://appliancetechmanuals.com...
Page 53 https://appliancetechmanuals.com...
Page 54 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Wiring and Visuals PAGE 52...
Page 55 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Wiring and Visuals PAGE 53...
Page 56 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Wiring and Visuals PAGE 54...
Page 57 https://appliancetechmanuals.com...
Page 58 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Wiring and Visuals Wiring Diagram CEP 30" Element Harness Element Harness DOC#:5060000000 Station 3 Date: 09/05/01 Rev: A ECO#: PAGE 56...
Page 59 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Wiring and Visuals Wiring Diagram CEP 30" Power Harness Power Harness DOC#:5060000000 Station 3 Date: 09/05/01 Rev: A ECO#: PAGE 57...
Page 60 https://appliancetechmanuals.com...
Page 61 https://appliancetechmanuals.com...
Page 62 https://appliancetechmanuals.com...
Page 63 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Wiring and Visuals Wiring Diagram CEP 36" Power Harness Note: This wire will be changed to a blue wire. DOC#:5060000000 Station 3 Date: 09/12/01 Rev: A ECO#: PAGE 61...
Page 64 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Wiring and Visuals Wiring Diagram CEP 36" Power Harness Note: This wire will be changed to a blue wire. DOC#:5060000000 Station 3 Date: 09/12/01 Rev: A ECO#: PAGE 62...
Page 65 https://appliancetechmanuals.com...
Page 66 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Wiring and Visuals Wiring Diagram CET 30" (Power Harness) Power Harness DOC#:5060000000 Station 3 Date: 08/30/01 Rev: A ECO#: PAGE 64...
Page 67 https://appliancetechmanuals.com...
Page 68 https://appliancetechmanuals.com...
Page 69 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Wiring and Visuals Wiring Diagram CET 30" (Element Harness) Element Harness DOC#:5060000000 Station 3 Date: 08/30/01 Rev: A ECO#: PAGE 67...
Page 70 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Wiring and Visuals PAGE 68...
Page 71 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Wiring and Visuals PAGE 69...
Page 72: Electrical Schematic D Rawings
https://appliancetechmanuals.com CEM/CET/CEP Service Manual Wiring and Visuals Electrical Schematic Drawing CET/CEP 365 PAGE 70...
Page 73: Cet/Cep 304
https://appliancetechmanuals.com CEM/CET/CEP Service Manual Wiring and Visuals Electrical Schematic Drawing CET/CEP 304 PAGE 71...
Page 74: Cem 456
https://appliancetechmanuals.com CEM/CET/CEP Service Manual Wiring and Visuals Electrical Schematic Drawing CEM 456 PAGE 72...
Page 75: Cem 304
https://appliancetechmanuals.com CEM/CET/CEP Service Manual Wiring and Visuals Electrical Schematic Drawing CEM 304 PAGE 73...
Page 76: Cem 365
https://appliancetechmanuals.com CEM/CET/CEP Service Manual Wiring and Visuals Electrical Schematic Drawing CEM 365 PAGE 74...
Page 77 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Wiring and Visuals Notes...
Page 78 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Wiring and Visuals Notes...
Page 79 https://appliancetechmanuals.com CEM/CET/CEP Service Manual Wiring and Visuals Notes...
Page 80 ® 5551 McFadden Avenue, H untington Beach, C A 92649 • 800/735-4328 5060008355 • © 2002 BSH H ome Appliances, Corp. • Litho in U. S. A. 11/02...
