AEROTRAK
+
®
REMOTE ACTIVE AIR SAMPLER
MODEL 7010
OPERATION MANUAL
P/N 6014704 REVISION A
JULY 2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7010 and is the answer not in the manual?

Questions and answers

Summary of Contents for Aerotrak 7010

  • Page 1 AEROTRAK ® REMOTE ACTIVE AIR SAMPLER MODEL 7010 OPERATION MANUAL P/N 6014704 REVISION A JULY 2020...
  • Page 3 AEROTRAK ® REMOTE ACTIVE AIR SAMPLER MODEL 7010 OPERATION MANUAL P/N 6014704 REVISION A JULY 2020 SHIP TO/MAIL TO: E-mail address: TSI Incorporated technical.services@tsi.com 500 Cardigan Road Shoreview, MN 55126-3996 Website: http://www.tsi.com U.S. INTERNATIONAL Technical Support: Technical Support: (001 651) 490-2860...

  • Page 4: Manual History

    M a n u a l H i s t o r y ® The following is a manual history of the AeroTrak + Active Air Sampler Model 7010 Operation Manual (P/N 6014704). Revision Date July 2020...

  • Page 5: Warranty

    W a r r a n t y 6014704 / Revision A / July 2020 Part Number Copyright ©TSI Incorporated / 2020 / All rights reserved. TSI Incorporated / 500 Cardigan Road / Shoreview, MN 55126 / USA Address E-mail Address answers@tsi.com Limitation Of Warranty And Liability (For country-specific terms and conditions outside of the USA, please visit www.tsi.com.)
  • Page 6 TSI’s Customer Service department at 1-800-680-1220 (USA) or +001 (651) 490-2860 (International). Trademarks TSI, the TSI logo, and AeroTrak are registered trademarks of TSI Incorporated in the United States and may be protected under other country’s trademark registrations. Modbus is a registered trademark of Modicon, Incorporated. Windows and Internet Explorer are registered trademarks of Microsoft Corporation.

  • Page 7: Table Of Contents

    Reusing and Recycling ............... viii Getting Help ....................ix CHAPTER 1 Introduction and Unpacking ......... 1-1 ® Unpacking the AeroTrak + Remote Active Air Sampler ....... 1-2 Optional Accessories ................. 1-3 CHAPTER 2 Installation and Getting Started ........2-1 Indicator LEDs ..................2-1 Electrical Connections ................
  • Page 8 International Contacts ................ 7-1 Service .................... 7-1 Technical Support ................7-2 Returning for Service ................7-2 APPENDIX A Specifications ............... A-1 Compliance .................... A-2 Dimensional Diagram - Model 7010 ............A-3 Index ® AeroTrak + Remote Active Air Sampler Operation Manual...

  • Page 9: Safety

    This section provides instructions to promote safe and proper handling of ® the AeroTrak + Remote Active Air Sampler Model 7010. I M P O R T A N T There are no user-serviceable parts inside the instrument. Refer all repair and maintenance to a qualified factory-authorized technician.

  • Page 10: Description Of Caution/Warning Symbols

    • DO NOT dispose of used batteries in the trash. • Follow local environmental requirements for battery recycling. • If instrument becomes obsolete, return to TSI for disassembly and recycling. ® viii AeroTrak + Remote Active Air Sampler Operation Manual...

  • Page 11: Getting Help

    G e t t i n g H e l p To obtain assistance with this product or to submit suggestions, please contact Customer Service: TSI Incorporated 500 Cardigan Road Shoreview, MN 55126 U.S.A. Fax: (651) 490-3824 (USA) Fax: 001 651 490 3824 (International) Telephone: 1-800-680-1220 (USA) or (651) 490-2860 International: 001 651 490-2860 E-mail Address:...
  • Page 12 (This page intentionally left blank) ® AeroTrak + Remote Active Air Sampler Operation Manual...
  • Page 13 C H A P T E R 1 I n t r o d u c t i o n a n d U n p a c k i n g The AeroTrak ® + Active Air Sampler is appropriate for use in monitoring airborne biocontamination in critical environments.
  • Page 14 + R e m o t e A c t i v e A i r S a m p l e r ® Carefully unpack the AeroTrak + Remote Active Air Sampler from the shipping container and check the contents of the shipment against the tables below.

  • Page 15: Chapter 1 Introduction And Unpacking

    Item Description Part/Model Reference Picture Power Supply PSU-ARWP USB-C Cable 700360 ® AeroTrak + Calibration 700220 Accessory Tri-clamp with Gasket 700211 Containment Filter 700214 Wall Mounting Bracket 700008-1...
  • Page 16 One or more holders can be attached to the sample head base to simplify settle plate deployment and/or store the sample cap during the agar plate change process. ® 1–4 AeroTrak + Remote Active Air Sampler Operation Manual...

  • Page 17: Indicator Leds

    I n s t a l l a t i o n a n d G e t t i n g S t a r t e d This chapter describes the features, connections, and installation of the AeroTrak ® + Remote Active Air Sampler.

  • Page 18: Electrical Connections

    E l e c t r i c a l C o n n e c t i o n s ® The state-of-the art AeroTrak + Remote Active Air Sampler supports multiple communications and connectivity options. A brief description of each of the connections is listed below.

  • Page 19: Ethernet Connector

    USB-C for configuration. The air sampler cannot be powered by USB-C for sampling. I n s t a l l a t i o n ® Installation of the AeroTrak + Remote Particle Counter consists of: • Determine the Installation Location •...

  • Page 20: Mounting The Control Box

    (circled in figure). ® To remove the AeroTrak + Active Air Sampler from the mounting bracket: 1. Press the locking tab at the top of the bracket.

  • Page 21: Using Power-Over-Ethernet (Poe)

    Using Power-Over-Ethernet (PoE) To supply power using a PoE device: 1. Make sure the Ethernet hub or router supplies power over the Ethernet cable (check with the equipment supplier or your computer services or Information Technology department). If the device is not capable of providing power, you will have to use an auxiliary AC power supply (see “Using DC...

  • Page 22: Connecting The Air Sampler To A Computer

    Ethernet. Connect the Ethernet cable to the Ethernet connector. If you used PoE to provide power, you have already made the necessary communications connection to the air sampler. Vacuum Tubing Installation The AeroTrak ® + Remote Active Air Sampler uses a critical or...
  • Page 23 W A R N I N G Excess tube length between the Sample Head and Control Box may result in flow errors. It is; therefore, recommended that the tube length does not exceed 20 m. Installation and Getting Started 2–7...
  • Page 24 (This page intentionally left blank) ® 2–8 AeroTrak + Remote Active Air Sampler Operation Manual...

  • Page 25: Setting The Ip Address Of The Air Sampler

    ® particle counter through Modbus TCP over Ethernet. Consult the FMS Software manual for more information. NO T E Technical documentation for integrating the TSI AeroTrak ® + Remote Active Air Sampler into custom applications, including details of the ®...

  • Page 26: Title Bar

    + Remote Active Air Sampler to the Windows operating system PC using the USB-C cable. The USB-C cable will ® power the air sampler. Launch the AeroTrak + Active Air Sampler App and you will arrive at the Main Page.

  • Page 27: Main Page-Instrument Tab

    Main Page—Instrument Tab The Instrument tab shows device information as described in the table below: Label Function Firmware version Current firmware version programmed on the device Last Cal Date (yyyy-mm-dd) Last date the device was calibrated Nominal Flow (lpm) Nominal flow rate of the device Instrument Temperature (C) Device temperature measured inside the enclosure...

  • Page 28: Main Page-Communication Tab

    USB-C cable. The USB-C cable will power the air sampler. NO T E USB-C power is designed for instrument configuration viewing and setup, not for operation. ® 3–4 AeroTrak + Active Air Sampler Operation Manual...
  • Page 29 ® Launch the AeroTrak + Active Air Sampler App and you will arrive at the Main Page. Open the menu at the upper left-hand corner and click on Tech Page. To enter the Tech Page, you will need to enter the Tech Password.

  • Page 30: Tech Page-Instrument (Instr) Tab

    This feature enables auto-discovery in FMS. SNTP Configure use of network time protocol. Set IP address of the network time server, turn on and off and offset time zones from UTC. ® 3–6 AeroTrak + Active Air Sampler Operation Manual...

  • Page 31: Tech Page-Password (Passwd) Tab

    Tech Page—Password (Passwd) Tab The Password tab is used to change the Tech Page password. The default password is admin Save must be pressed for the configurations to be saved to the instrument. Tech Page—Reset Tab This will reset the instrument to its original factory settings. Communications 3–7...

  • Page 32: Loading Or Saving A Configuration

    All critical parameters on the instrument can be seen grouped in the configuration report. To enter the report page, open the menu at the upper left-hand corner and click on Report Page. ® 3–8 AeroTrak + Active Air Sampler Operation Manual...

  • Page 33: Saving A Configuration Report

    The report page will show a configuration report on all the instruments configurable parameters. Saving a Configuration Report The configuration report can be saved to a PDF file by pressing the up arrow at the top of the report and selecting a name and location for the file.

  • Page 34: About Page

    A b o u t P a g e The About Page is accessed by the menu in the upper left hand of the application. The about page shows the current version of the software application. ® 3–10 AeroTrak + Active Air Sampler Operation Manual...

  • Page 35: Load Plate For Sampling

    NO T E ® The stated efficiency of the AeroTrak + Active Air Sampler has been established using 27 mL deep fill 90 mm plates. The efficiency of the air sampler when sampling with plates of a different fill volume has not been established.
  • Page 36 To calculate the concentration of the viable particles in the sample, divide the corrected MPN by the sample volume. Feller Corrections: 15.8 32.6 18.1 38.9 10.0 20.9 48.4 11.8 24.0 67.4 13.7 27.8 ® 4–2 AeroTrak + Remote Active Air Sampler Operation Manual...

  • Page 37: Cleaning And Disinfection

    C H A P T E R 5 M a i n t e n a n c e The following maintenance may be performed to assure performance and reduce the risk of contamination. C l e a n i n g a n d D i s i n f e c t i o n The sample head, base and cap, as well as the exterior of the control box can be cleaned and disinfected using common cleanroom cleaning agents and disinfectants.
  • Page 38 (This page intentionally left blank) ® 5–2 AeroTrak + Remote Active Air Sampler Operation Manual...
  • Page 39 Flow LED is flashing or off, Vacuum line may be disconnected, Check vacuum line to make sure indicating a flow error (7010) blocked, or kinked. it is connected, unblocked and not kinked. Inlet may be restricted. Remove any obstructions from inlet.
  • Page 40 (This page intentionally left blank) ® 6–2 AeroTrak + Remote Active Air Sampler Operation Manual...

  • Page 41: Technical Contacts

    T e c h n i c a l C o n t a c t s • ® If you have any difficulty setting up or operating the AeroTrak Remote Active Air Sampler, or if you have technical or application questions about this system, contact an applications engineer at TSI Incorporated, 1-800-680-1220 (USA) or (651) 490-2860 or e-mail technical.services@tsi.com.

  • Page 42: Technical Support

    Package instrument for shipment ensuring the front display and the inlet orifice inlet are protected. ® 5–2 AeroTrak + Active Air Sampler Operation Manual...
  • Page 43 A P P E N D I X A S p e c i f i c a t i o n s All specifications are subject to change without notice. Valve Warranty....Five Years Instrument Warranty ..Two Years Calibration Frequency ..

  • Page 44: Compliance

    Korean Standard KN 11 with RRA Public Notification 2017-19 and RRA Announce 2017-71 Korean Standard KN 61000-6-1 with RRA Public Notification 2017-19 and RRA Announce 2017-71 FCC Part 15 Subpart B RoHS Marking ® AeroTrak + Active Air Sampler Operation Manual...
  • Page 45 D i m e n s i o n a l D i a g r a m - M o d e l 7 0 1 0 Specifications A–3...
  • Page 46 (This page intentionally left blank) ® AeroTrak + Active Air Sampler Operation Manual...
  • Page 47 I n d e x Ethernet, 1-1 instrument tab, 3-3 connector, 2-3 screen, 3-3 about page, 3-10 Ethernet address, 3-1 tech page, 3-5 screen, 3-10 excess tube length password, 3-5 accessories warning, 2-7 screen, 3-5 included, A-2 maintenance, 5-1 optional, 1-3, A-2 cleaning and disinfection, 5-1 agar plate, 1-1 facility monitoring system software,...
  • Page 48 3-2 trademarks, iv tri-clamp with gasket, 1-3 uninsulated voltage symbol, viii unload plate, 4-1 unpacking, 1-1, 1-2 USB connection, 3-2 USB drive, 1-2 USB-C cable, 1-3, 3-4 USB-C connector, 2-3 ® Index-2 AeroTrak + Active Air Sampler Operation Manual...
