Sentinel 1500
CONTENTS
Unpacking/Safety -------------------------- 2
Maintenance --------------------------------- 7
---------------------------------- 8
Parts List ------------------------------------ 9
Locations ---------------------- ------------ 10
Glossary ------------------------------------ 11
Warranty ----------------------------------- 12
Revised 11/15/2012
P/N MM0156
3868 E. Post Road, Las Vegas, NV 89120 (702) 454-5515, Fax (702) 454-5225
Air Scrubber
Air-Care is a Division of D.P.L. Enterprises, Inc.
Website: www.air-care.com, E-mail: Info@Air-Care.com
Item # FG0157
- 1 -
Advertisement
Summary of Contents for Air-Care Sentinel 1500
-
Page 1: Table Of Contents
Locations ---------------------- ------------ 10 Glossary ------------------------------------ 11 Warranty ----------------------------------- 12 Revised 11/15/2012 P/N MM0156 Air-Care is a Division of D.P.L. Enterprises, Inc. 3868 E. Post Road, Las Vegas, NV 89120 (702) 454-5515, Fax (702) 454-5225 Website: www.air-care.com, E-mail: Info@Air-Care.com - 1 -... -
Page 2: Unpacking/Safety
“Operating” section of this manual. Inspect all of the packing material for small parts before discarding packaging material. Check that all parts are present 1. Sentinel 1500 main assembly, with wheels and handles in tact. Open the top door and check for the filters and accessories inside. 2. White 1 stage, 1”... -
Page 3: How & When To Use An Air Scrubbers
Air Scrubbers, When and How to use them Briefly, an Air Scrubber circulates ambient air through its filter system, usually 3 stages with a HEPA final stage, and exhausts clean air into that environment. It is a BIG air purifier. Sometimes, the air scrubber may also contain activated carbon filters to adsorb odors and chemicals that may be in the ambient air. - Page 4 got General Particulate control as well as the much more stringent Mold and Asbestos protocols. Pressurization must be maintained at a minimum of .02” of W.G. between the area of Mold Growth and the uncontaminated area. If spores have spread to other areas of the building, that area needs to be cleaned and isolated, but it should NOT be in the same containment area as the primary growth area.
- Page 5 Length x Width x Height = cfm So, a room that is 15 feet wide by 40 feet long with an 8-foot ceiling would require a negative air machine with: 15 x 40 x 8 = 320 cfm If that room had a common ceiling return plenum, making the ceiling deck 11 feet high, then: 15 x 40 x 11 = 440 cfm Now here is the tricky part, what if the drop is NOT at the minimum?
- Page 6 To achieve balance on an actual job, it may be necessary to use multiple negative are machines, and it may be necessary to use a negative air machine in Zone 2 to exhaust clean air out outside. Once the air flow is in the correct direction, and the pressure drop between clean, sort of dirty and really dirty are balanced, it may still be necessary to add an air scrubber inside the work area for either the main remediation Zone due to dust and debris from heavy construction work, or in the Intermediate Zone where the building contents are being...
-
Page 7: Maintenance
It is also advisable to thoroughly decontaminate the Air scrubber after each job and start each job with a clean set of filters. Determine Project Requirements for Air Scrubbers Room size vs. Number of Sentinel 1500 required for 4 air changes per Hour Room Size Cubic feet of Space CFM Required for Required number of (8’... -
Page 8: Specifications
Specifications Specification Description Size 22” W x 29” D x 38.” H (Handle in Down Position) 105 lbs. Weight 120 V, 60 Hz, 13 Amps Power required 25’ Extension Cord Power Cord 4 stages when optional Carbon Odor adsorbing pad used Filtration Carbon Pre-Filter Optional Odor and VOC adsorber Stage 18”... - Page 9 Description Part# Sentinel 1500 Air Scrubber, complete with Filters FG0157 Sentinel 1500 Air Scrubber, Top Cover with 12” Inlet Collar MP0022 1st Stage, 18” x 24” x 2” Disposable Pre-Filter pad Pkg of 10 SAO0315 Stage, 18” x 24” x ¼” Disposable Pre-Filter pad. Pkg of 10 SAO0316 Third Stage, 18”...
-
Page 10: Locations
- 10 -... -
Page 11: Glossary
Glossary & Acronyms 1. ASHRAE—American Society of Heating, Refrigerating, and Air Conditioning Engineers 2. Air Handler/ AHU—The Furnace or air conditioner that heats, cools and moves the air. 3. Antimicrobial—Agent added to materials to retard growth of biological contaminants. 4. Arrestance – An ASHRAE standard procedure to measure air filter efficiency (52.1) 5. -
Page 12: Warranty
General Conditions This warranty shall be held void on any Air-Care equipment which has been modified or altered in any way or which has been subject to improper maintenance, improper usage or abuse. Air Care warrants its equipment to the original purchaser only.
