INSTRUCTION MANUAL
1)
2)
3)
Method of Attachment to Forklift
Operational and Safety Procedures
4)
5)
6)
7)
8)
9)
10)
Terms and Conditions
Appendix A
ALL EAST WEST WORK PLATFORMS CONFORM TO
AS/NZS 1554.1:2011, AS 2359.1 - 1995 & AS 2359.2 - 1985
Type WP
WORK PLATFORM
Table of contents
81-87 Old Pittwater Rd, Brookvale Australia
P.O. Box 112, Brookvale NSW 2100
Ph: (02) 9938 0644 Fax: (02) 9938 0655
Toll Free: 1800 061 998
Email: sales@eastwesteng.com.au
Page
2
2
3
4
5
7
8
9
10
11
Attached
1
Advertisement
Summary of Contents for East West Engineering WP
-
Page 1: Table Of Contents
EAST WEST ENGINEERING INSTRUCTION MANUAL Type WP WORK PLATFORM Table of contents Page Quality Policy Statement General Description of Product Method of Attachment to Forklift Operational and Safety Procedures Risk Control Measures – Summary Parts List Maintenance Compliance Plate Information... -
Page 2: East West Engineering
The Safe Working Load (SWL) is 250 kg. Weight of the type WP Work Platform is 115 kg. Two locking pins are supplied to prevent the Work Platform from moving off the fork arms. The Work Platform is fitted with an internally swinging spring-loaded door. - Page 3 Before installation of the type WP Work Platform onto a Forklift, ensure that the fork arms are suited and set to the correct width. The type WP Work Platform is supplied with the rear (top) frame wired to cage for ease of transport...
- Page 4 Do not exceed the rated capacity of the Industrial Truck to handle the load. Referring to AS 2359.1 clause 12.3.1, Industrial Trucks used to lift the type WP Work Platform must have capacities equal to or greater than;...
-
Page 5: Risk Control Measures - Summary
WARNING: In some states of Australia, the use of Work Platforms must be approved by the statutory Authority. The type WP Work Platform is designed to carry a maximum of two (2) people or a SWL of 250kg and is for approved use only. - Page 6 Do not exceed the rated capacity of the Industrial Truck to handle the load. Trucks used to lift the type WP Work Platforms must have capacities equal to or greater than; • For a counterbalance truck – 1825 kg, •...
-
Page 7: Parts List
PARTS LIST Warning Notice Rear Frame Part No SP-0103 Part No WP-06 Bow Catch Part No Downee CAC 22 Top Frame Spigot M10 Nut, Bolt & Washers (2 sets) Gate Frame Part No WP-07 Hinges (100 x 75mm) Spring Bracket SP-0161... -
Page 8: Maintenance
MAINTENANCE Regular maintenance including Testing, Inspection and Cleaning should be carried out on the Work Platform to reduce the risk of potential hazards arising. The Work Platform should be cleaned and visually inspected by a “Competent Person” under adequate lighting conditions, before each shift, to ensure all components are functioning correctly and are free from any noticeable wear or damage. -
Page 9: Compliance Plate Information
COMPLIANCE PLATE INFORMATION “A” “D” “E” “B” “C” “F” Fig. 8.1 Product Type Refer “A”, Table 8.2 Serial Number Individually stamped Safe Working Load Refer “C”, Table 8.2 Dry weight of the unit Refer “D”, Table 8.2 Horizontal C of G Refer “E”, Table 8.2 Load Centre Refer “F”, Table 8.2... -
Page 10: Certification Information
CERTIFICATION INFORMATION Certificate Type WP Work Platform We certify that the type WP Work Platform is rated to 250kg Safe Working Load (SWL) and is designed and fabricated strictly in accordance with relevant Australian Standards including those listed below –... - Page 11 TERMS of TRADE, CONDITIONS of SALE and WARRANTY STATEMENT East West Engineering (EWE) products are to be used only as indicated. Misuse or misapplication may cause failure resulting in possible property damage or bodily injury. It is the obligation of the user to ensure EWE products are used in accordance with appropriate Codes and System requirements.
