PROJECT:
LOCATION:
SUBMITTED BY:
FAN MODEL
DIAMETER
DOWNROD
WALL CONTROL
VARIABLE FREQUENCY DRIVE
INSTALLATION
COMMENTS
NOTES
*Available upon request.
Fan(s) will be located at the nearest location(s) as per building plans.
Wall control location(s) to be identified by owner at time of installation.
IF INSTALLATION IS TO BE PERFORMED BY OTHERS: Installation and site preparation to be performed by others at owner's request.
IF GOLD LEVEL INSTALLATION: Basic mechanical installation includes: scissor lift rental (if necessary), mounting all fans and equipment, routing all
communication cables, connecting fans and controls (if applicable) to power supply, and factory authorized startup and commissioning.
**CUSTOMER IS RESPONSIBLE FOR PROVIDING POWER SUPPLY TO 15' FROM EACH FAN LOCATION PRIOR TO FAN INSTALLATION*
IF PLATINUM LEVEL INSTALLATION: Full turnkey installation includes: routing all electrical wire and conduit from each fan location to electrical
panel, terminating electrical connections with NEMA rated receptacles, scissor lift rental (if necessary), mounting all fans and equipment, routing all
communication cables, connecting fans and control (if applicable) to power supply, routing low voltage fire relay cable from each fan location to security
panel (if fire relay tie-in is required – Customer's fire/security company to land final connections), and factory authorized startup and commissioning.
P: 629.333.7100 | F: 615.232.3891 | TOLL: 1.844.591.FANS (3267) 180 THREET INDUSTRIAL ROAD, SMYRNA 37167 |
14 '
12 '
7' 8 ' 10 '
48"*
36"*
24"
Platinum Level Installation (Premium Turnkey)
Gold Level Installation (Basic Mechanical)
To Be Performed By Others
HUNTERFAN.COM/INDUSTRIAL
1
Advertisement
Table of Contents
Related Manuals for Hunter Industrial XP 14
Summary of Contents for Hunter Industrial XP 14
- Page 1 PROJECT: LOCATION: SUBMITTED BY: FAN MODEL DIAMETER 7' 8 ' 10 ' 12 ' 14 ' DOWNROD 24" 36"* 48"* WALL CONTROL VARIABLE FREQUENCY DRIVE INSTALLATION To Be Performed By Others Gold Level Installation (Basic Mechanical) Platinum Level Installation (Premium Turnkey) COMMENTS NOTES *Available upon request.
-
Page 2: Dimensions And Weight
POWER & EFFICIENCY AC 1PH 100-120V 50/60Hz INPUT POWER OPTIONS CURRENT AT MAX SPEED (Amp) 6.2 A @ 120v POWER (hp) BLDC Motor 5/8 HP MAXIMUM SPEED (RPM) 108 RPM MAX AFFECTED AREA 70 ft Dia | 4,900 sqft DIMENSIONS & WEIGHT FAN DIAMETER 14 ft (4.3m) FAN WEIGHT... -
Page 3: Safety And Precautions
SAFETY & PRECAUTIONS Important Safety Information To prevent SERIOUS INJURY, DEATH and PROPERTY DAMAGE, you should read, understand and follow the warnings and instructions in this manual before installing or operating the fan. READ AND SAVE THESE INSTRUCTIONS. This manual must always be kept with the fan and should remain with the fan if it is transferred or sold. - Page 4 Do not make any changes to any part of the fan without first consulting Hunter Industrial Fan. Installation is to be in accordance with ANSI/NFPA 70: National Electrical Code and local codes.
-
Page 5: Crush Hazard
EVERY fan. The Retention Cable, if installed per Hunter Industrial Fan specifications, can limit the distance the fan could fall in the unlikely event of mounting system failure. Failure to install and to secure the Retention Cable will void your warranty. -
Page 6: Fan Placement
FAN PLACEMENT ALWAYS mount fan so the bottom edge of blade to the floor is at least 10 feet from the floor and at least 25% of fan diameter from the ceiling. Always mount fans away from the following: Sprinkler Systems Prior to installing fans, review all codes applicable to sprinkler systems and fans to ensure code compliance and refer to NFPA 13: Fire Sprinkler System Installation. -
Page 7: Minimum Clearance
FAN PLACEMENT FAN PLACEMENT FAN SPACING CHART MIN - MAX 14ft 35ft - 56ft (427cm) (10,67m - 17,07m) 12ft 30ft - 48ft (366cm) (19,14m - 14,63m) 10ft 25ft - 40ft (305 cm) (7,62m - 12,19m) 20ft - 32ft (244 cm) (6,10m - 9,75m) 18ft - 28ft (213 cm) -
Page 8: Maintenance
MAINTENANCE Electric Shock Hazard Electric Shock Hazard To prevent serious injury or death: • BEFORE performing maintenance or service, ALWAYS disconnect the power by turning off the circuit breaker or breakers to the fan locations and confirm Lockout/Tagout procedures are in place. •... -
Page 9: Fan Components
IN THE BOX FAN COMPONENTS A (1) Downrod E (1) Standard Control B (1) Motor F (1) Communication Cable C (4) Blades G (1) Installation Manual (not shown) D (1) Control Panel... -
Page 10: Standard Control
STANDARD CONTROL 350 SERIES TOUCHSCREEN CONTROLLER [3.05] 77.44 [0.203] 5.16 4 places [3.95] [2.00] 100.31 50.80 [2.06] 52.26 [2.73] 69.31 [3.55] 90.14 • Comes standard on XP and Eco Fans • Plug-n-Play design • Simple control of speed and direction •... - Page 11 149.31 [3.59] [4.30] 91.20 109.31 UP TO 10 FANS 4.3” TOUCHSCREEN • Compatible with all Hunter Industrial Fans • Simple intuitive user Interface NUMBER OF FANS CONTROLLED UP TO 10 FANS • Standard on Titan ACTIVE DISPLAY AREA 4.3” DIAGONALLY •...
- Page 12 CONTROL 700 SERIES TOUCHSCREEN CONTROLLER [7.69] 195.20 [5.18] [4.04] 131.60 102.70 TOUCHSCREEN • Optional Environmental Control NUMBER OF FANS CONTROLLED UP TO 30 FANS • BMS Integration with optional gateway • Control up to 30 fans with network solutions to ACTIVE DISPLAY AREA 7”...
- Page 13 OPTIONS FOR CONTROLS BACNET GATEWAY BACNET GATEWAY • Simple approach to OPERATING ENVIRONMENT TEMPERATURE -20° TO 70°C/(-4° TO 158°F) interface fans to a Building OPERATING ENVIRONMENT HUMIDITY 10-95% RH NON-CONDENSING Management System • Enables remote monitoring, INPUT VOLTAGE 24VAC 125MA, 12-24VDC 250MA @ 12VDC control and visualization of a ENCLOSURE RATING IP67...
- Page 14 OPTIONS FOR CONTROLS CONTROL CABLE REPEATER BACNET GATEWAY • Extend standard Cat 5e/Cat OPERATING ENVIRONMENT TEMPERATURE -40° TO 75°C (-40° TO 167°F) 6 Ethernet cable runs an OPERATING ENVIRONMENT HUMIDITY 10-95% RH NON-CONDENSING additional 100M without loss of transfer speed INPUT VOLTAGE CLASS 2 POWER SUPPLY: 12-48VDC, 18-30VAC 50/60HZ •...
- Page 15 ELECTRICAL Electrical Plug Requirements Voltage Plug Receptacle 110-120V L5-15P L5-15R A Plug and Receptacle are included with each fan Breaker Size Chart XP AMP DRAW Fan Diameter AC 1PH 100-120V 50/60Hz Recommended Breaker Size 14’ 7.5A - 6.2A 12’ 8.4A - 7A 10’...
- Page 16 FIRE PANEL (FIELD WIRING) DRY CONTACTS: NORMALLY CLOSED FIRE RELAY • On the Terminal Strip mounted to the outside of the VFD enclosure a Jumper will be in place on terminals “S” and “C”. Remove the Jumper from C SA terminals “S”...
- Page 17 FIRE PANEL (FIELD WIRING) FIRE RELAY ARRANGEMENT FOR MULTIPLE FANS (30 FAN MAXIMUM) Normally Energized/Unenergized Fire Panel 10-40VDC VFD Enclosure VFD Enclosure VFD Enclosure VFD Enclosure with Fire Relay without Fire Relay without Fire Relay without Fire Relay Dry Contacts Fire Panel Normally Closed...
- Page 18 XP 14 14'-0" 14'.0...
