- Page 1 MVC Pro SDI to HDMI Medical Video Converter User Guide English Applies to firmware 171214 and higher For more translations (available in pdf), please visit www.medicapture.com/support MVCPro-UG01-EN-211004-OB...
- Page 2 This symbol informs the user that this user manual and translated copies can be I : AC power ON downloaded from the MediCapture website at: O : AC power OFF www.medicapture.com/support This symbol indicates the equipotential pole which brings the various parts of a system to the same potential.
- Page 3 MVC Pro User Guide – English WARNING To avoid risk of electric shock, this equipment must only be connected to a supply mains with protective earth. Do not modify this equipment without authorization of the manufacturer. To avoid risk of electric shock, replace the fuse only by qualified service personnel, and only with the type specified in the user guide. To reduce the risk of fire or shock hazard, do not expose this equipment to rain or moisture, this device is designed for indoor use only.
-
Page 4: Table Of Contents
Intended Use: The MVC Pro SDI to HDMI is intended to convert SDI input from a variety of surgical imaging systems to HDMI video output. The MVC Pro SDI to HDMI has the capability to convert signals for recording systems to be archived and reviewed. -
Page 5: Residual Risks
19. Manufacturer will provide circuit diagrams, component part lists, descriptions calibration instructions to assist to service personnel in parts repair or replacement. Technical Support For technical support and other questions, please visit medicapture.com or call 888-922-7887 (toll free from within the USA) or 503-445-6935 (from outside the USA). MediCapture Inc. -
Page 6: Front Panel
Various input options are possible for 4K-SDI HDMI Output (2) Connecting the MVC Pro SDI to HDMI This MVC Pro connects to an SDI video source (for example, an endoscopic camera, surgical camera, ultrasound, etc.). 1. If you are adding the MVC Pro to imaging equipment that you are already using, begin by locating the video output of the primary video source. -
Page 7: First Installation / General Preparations For Safe Operation And Performance
This primary, directly connected main monitor should always be used for live view. The medical video chain that is connected through the MVC Pro SDI to HDMI convertor can only be used for recording and extra viewing, e.g. educational purpose. It can’t be used for medical purpose. -
Page 8: Recording With Your Recording Device
MVC Pro User Guide – English Recording with your recording device The HDMI Outputs of MVC Pro SDI to HDMI can be connected to the HDMI input or to the DVI Input of your recorder by using the supplied HDMI to DVI adapter.
