Back Bar Bottle Cooler
Service, Installation and Care Manual
Please read this manual completely before attempting to install or operate this equipment.
Notify carrier of damage! Inspect all components immediately. See page 2.
I M P O R T A N T I N F O R M A T I O N
R E A D
PLEASE SAVE THESE INSTRUCTIONS!
B E F O R E
U S E
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Entree BB-2D-60
Summary of Contents for Entree BB-2D-60
- Page 1 Back Bar Bottle Cooler Service, Installation and Care Manual Please read this manual completely before attempting to install or operate this equipment. Notify carrier of damage! Inspect all components immediately. See page 2. I M P O R T A N T I N F O R M A T I O N R E A D B E F O R E U S E...
-
Page 2: Table Of Contents
CIRCUIT DIAGRAM…………………………………………………………………………………9 All rights reserved. Reproduction without written permission is prohibited. is a registered trademark of The Entree Company. SERIAL NUMBER INFORMATION The serial number of all self-contained refrigerators and freezers is located inside the unit on the left hand side near the top on the wall. -
Page 3: Specifications
Service and Installation Manual SPECIFICATION BACK BAR BOTTLE COOLER STORAGE SHIP CAPACITY CHARGE WEIGHT NEMA Cu-ft MODEL# V/Hz/Ph AMPS PLUG BB-2D-60 115/60/1 13.8 3200 5-15P BB-2D-70 115/60/1 14.5 3200 5-15P BB-3D-90 115/60/1 25.3 5800 5-15P BB-2D-60-G 115/60/1 13.8 3200 5-15P... -
Page 4: Installation
Service and Installation Manual INSTALLATION Location Units represented in this manual are intended for indoor use only. Be sure the location chosen has a floor strong enough to support the total weight of the cabinet and contents. A fully loaded unit can weigh as much as 1500 pounds. -
Page 5: Operation
Service and Installation Manual OPERATION Do not throw items into the storage area. Failure to heed these recommendations could result in damage to the interior of the cabinet. Do not throw items into the storage area. Failure to heed these recommendations could result in damage to the interior of the cabinet. - Page 6 Service and Installation Manual OPERATION 1.1 Function of LEDS 2. MAIN FUNCTIONS 2.1 HOW TO SEE THE SETPOINT 1. Push and immediately release the SET key: the display will show the set point value. 2. Push and immediately release the SET key or wait for 5 seconds to display the sensor value again.
-
Page 7: Maintenance
Service and Installation Manual MAINTENANCE The power switch must be turned OFF and the unit disconnected from the power source whenever performing service, maintenance functions or cleaning the refrigerated area. Refrigerators and Freezers The interior and exterior can be cleaned using soap and warm water. If this isn't sufficient, try ammonia and water or a nonabrasive liquid cleaner. - Page 8 Service and Installation Manual MAINTENANCE Cleaning solutions need to be alkaline based or non-chloride based. Any cleaner containing chlorides will damage the protective film of the stainless steel. Chlorides are commonly found in hard water, salts, and household and industrial cleaners. If cleaners containing chlorides are used, be sure to rinse and dry thoroughly.
-
Page 9: Circuit Diagram
Service and Installation Manual CIRCUIT DIAGRAM MODEL: BB-2D-60/BB-2D-70/ BB-2D-60-G/BB-2D-70-G MODEL: BB-3D-90/ BB-3D-90-G For warranty service, call 866-417-6140... - Page 10 APPLICABLE TIME AND MATERIALS RATES. If shipment of a replacement part is requested by the end user prior to the arrival in the Entree factory of the part claimed to be defective, the Original Purchaser must accept delivery of the replacement part of a C.O.D. basis, with credit being issued after the part has been received and inspected at Entree's plant and determined by Entree to be within this warranty.
- Page 11 In case of warranty compressor, the compressor warranty form must be filled out by a qualified refrigeration technician. This form can be obtain by down load from our website: www.entree.biz. This form must be emailed, in its completion, with a copy of the original proof of purchase to: john@entree.biz.
- Page 12 Service and Installation Manual STANDARD TWO-YEAR WARRANTY （TWO-YEAR PARTS & LABOR WARRANTY For products produced after serial number 1301ENTH00001.） RESIDENTIAL APPLICATIONS: Entrée L.L.C. assumes no liability for parts or labor coverage for component failure or other damages resulting from installation in non-commercial or residential applications. ALTERATION, NEGLECT, ABUSE, MISUSE, ACCIDENT, DAMAGE DURING TRANSIT OR INSTALLATION, FIRE, FLOOD, ACTS OF GOD.
- Page 13 Service and Installation Manual ENTRÉE LLC 4673 OSBORNE DR., SUITE I EL PASO, TX 79922 www.entree.biz For warranty service, call 866-417-6140...
