OWT P2B-IW-6 Quick Start Manual

127
5.00
244
9.61
Weight: 3.43 LBS
Scale: 1:4
Last updated: 4/29/2016
51735
Product & Packaging Specs
1.5 min
2.0 max
117
4.61
6" Post to Beam (P2B-IW-6)
ITEM
QTY.
NO.
1 0.08
2 0.4
3 0.08
4 1
5 1
2
3
5
4
1
2
kit contains 2 assemblies
V2.00 - Installation Instructions, Specifications and Project Plans are effective 4/29/2016 . This information is updated periodically
and should not be relied upon after 2 years from 4/29/2016 . Please visit OZCOBP.com to get current information.
Item #: 51735
PART
DESCRIPTION
NUMBER
OWT Timber
56626
Screw 2-3/4"
1 1/2" Hex
56621 Cap Nut
(HCN)
OWT Timber
56627
Screw 3-3/4"
Ledge, Post to
51710-11
Beam
Plate, Top 6"
51735-11
Post to Beam
127
5.00
1.5 min
2.0 max
244.16
9.61
117
4.62
1
