Summary of Contents for Steiner LS340
- Page 1 MODEL: 75-70632A LAWN SWEEPER LS340...
- Page 2 CALIFORNIA WARNING Proposition 65 Warning Diesel engine exhaust and some of The engine exhaust from this product its constituents are known to the State contains chemicals known to the State of California to cause cancer, birth of California to cause cancer, birth defects and other reproductive harm.
- Page 3 See a Steiner dealer for any service or parts needed. Schiller Grounds Care, Inc. service ensures that you continue to receive the best results possible from Schiller Grounds Care, Inc. products. You can trust Schiller Grounds Care, Inc.
- Page 4 DESCRIPTION / SPECIFICATIONS LAWN SWEEPER DESCRIPTION The Lawn Sweeper is designed to give a “clean sweep” in your lawn sweeping operations. The unit is ground-driven so it can be pulled by any lawn and garden tractor. It can be used to trail behind with offset hitch while mowing, or regular hitch to clean-up after you’ve finished mowing.
- Page 5 SAFETY LAWN SWEEPER This symbol means: NOTICE !!! ATTENTION! Unauthorized modifications may present extreme BECOME ALERT! safety hazards to operators and bystanders and could also result in product damage. Your safety and the safety of others is involved. Schiller Grounds Care, Inc. strongly warns against, Signal word definitions rejects and disclaims any modifications, add-on accessories or product alterations that are not...
- Page 6 SAFETY LAWN SWEEPER GENERAL SAFETY • Read and understand the owner’s manual, • Never allow anyone to operate or service this before attempting to operate this machine. machine while under the influence of alcohol or drugs. • Operate all controls from the operator’s seat, (if so equipped).
- Page 7 OPERATION / SERVICE LAWN SWEEPER OPERATING INSTRUCTIONS 1. Determine hitch position for offset or straight pull position. 2. Transport to clean-up site with the clutches disengaged and sweeper in transport position. 3. Lower the sweeper housing and adjust sweeper height on right side of sweeper housing by choosing the pin location to regulate gauge wheel height.
- Page 8 MAIN PARTS LAWN SWEEPER FIGURE 1 30 15...
- Page 9 MAIN PARTS LAWN SWEEPER FIGURE 1 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 62-602.17 MAIN FRAME, LS340 60-187.17 DOOR 42-205.7 HINGE ROD 64140-1 COTTER PIN-1/8X1 41-010 SPRING 40-114.17 LATCH-RIGHT 40-115.17 LATCH-LEFT 83-407016 SPROCKET 41-013 SPRING 86-020.7 CLUTCH PAWL-RIGHT 64164-10 1/4X1/4X1-1/4 MACH KEY 86-043.7...
- Page 10 BRUSH PARTS LAWN SWEEPER FIGURE 2...
- Page 11 BRUSH PARTS LAWN SWEEPER FIGURE 2 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 62-385.17 HOUSING, BROOM LS340 64025-19 HEX, NUT 1/2-13 64025-05 NUT-3/8-16 HEX 64158-04 EYEBOLT 3/8-16X6 41-010 SPRING 64163-16 WASHER-41/64 X 1, 3/8 X 12 12 53-186 WHEEL-10.25 X 3.25...
- Page 12 SCHILLER GROUNDS CARE, INC. ONE BOB-CAT LANE P.O. BOX 469 JOHNSON CREEK, WI 53038 920-699-2000 www.schillergc.com ©Schiller Grounds Care, Inc. 2010...
