Engineering Incorporated PAC45A Manual

Special mission audio controller system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Special Mission Audio Controller System
with MultiTalker® and IntelliVox®
Patented under one or more of the following;
No. 4,941,187; 5,903,227; 6,160,496 and 6,493,450, 7,391,877
In certified aircraft, warranty is not valid unless this product is installed by an
Any reproduction or retransmittal of this publication, or any portion thereof, without the expressed written permission of PS En-
gineering, Inc. is strictly prohibited. For further information, contact the Publications Manager at PS Engineering, Inc., 9800
Martel Road, Lenoir City, TN 37772. Phone (865) 988-9800, email contact@ps-engineering.com.
9800 Martel Road
Lenoir City, TN 37772
www.ps-engineering.com
PAC45A
Document P/N 200-045-1000
Revision 18, December 2021
Audio Control System with Intercom
System Installation and Operation Manual
FAA - TSO C139a
Authorized PS Engineering dealer.
PS Engineering, Inc. 2021 ©
Copyright Notice
