Yaris
AUDIO
RHD installation instructions
Model year: 2005
Vehicle code: **P90R-****KW
Part number: • CD-Changer: 08601-00911
• Subwoofer: 08691-00834
Manual ref. n
: AIM 000 481-01
o
All manuals and user guides at all-guides.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the Yaris 2005 and is the answer not in the manual?

Questions and answers

Summary of Contents for Toyota Yaris 2005

  • Page 1 All manuals and user guides at all-guides.com Yaris AUDIO RHD installation instructions Model year: 2005 Vehicle code: **P90R-****KW Part number: • CD-Changer: 08601-00911 • Subwoofer: 08691-00834 Manual ref. n : AIM 000 481-01...
  • Page 2: Revision Record

    All manuals and user guides at all-guides.com Yaris AUDIO Revision Record Rev. Nr. Datum Seite Abbildung Aktualisierung Gelöschte Schritte Rev. N Date Page Picture Update Deleted steps No. version Date Page Image Mise à jour Nouveau Etapes supprimées Application Application 02-07 Chart Chart Europe...
  • Page 3: Precautions

    All manuals and user guides at all-guides.com Yaris AUDIO PRECAUTIONS PLEASE READ THOROUGHLY THESE PRECAUTIONS BEFORE THE INSTALLATION . • Protect your car with fender • Be sure to disconnect the nega- tive (-) lead from the battery ter- covers, seat and so on. minals.
  • Page 4: Table Of Contents

    All manuals and user guides at all-guides.com Yaris AUDIO TABLE OF CONTENTS Revision Record ..........................Precautions ............................Application Chart Europe production .................... Application Chart Japan production ....................AUDIO Installation Instructions • Vehicle Disassembly ........................• CD-Changer Installation ......................• Subwoofer Installation ......................
  • Page 5: Application Chart Europe Production

    All manuals and user guides at all-guides.com Yaris AUDIO APPLICATION CHART EUROPE PRODUCTION Yaris (RHD) - 5 02-07...
  • Page 6: Application Chart Japan Production

    All manuals and user guides at all-guides.com Yaris AUDIO APPLICATION CHART JAPAN PRODUCTION 02-07 Yaris (RHD) - 6...
  • Page 7: Vehicle Disassembly

    All manuals and user guides at all-guides.com Yaris AUDIO VEHICLE DISASSEMBLY Put protective tape on the shaded areas. CAUTION Be sure to remove the parts carefully so you do not damage the panels. Fig. 1 Remove the center cluster panel (L) and (R) : Clip (6x) : Hook (8x)
  • Page 8 All manuals and user guides at all-guides.com Yaris AUDIO Remove the audio unit : Clip (4x) : Screw (4x) Fig. 4 FOR EUROPE PRODUCTION Remove the scuff plate and the cowl side trim on the driver’s side. : Clip (1x) (Cowl side trim) : Hook (1x) (Cowl side trim) : Clip (2x) (Scuff plate) : Hook (2x) (Scuff plate)
  • Page 9 All manuals and user guides at all-guides.com Yaris AUDIO FOR JAPAN PRODUCTION Remove the scuff plate and the cowl side trim on the passenger’s side. : Clip (1x) (Cowl side trim) : Hook (1x) (Cowl side trim) : Clip (2x) (Scuff plate) : Hook (2x) (Scuff plate) Fig.
  • Page 10: Cd-Changer Installation

    All manuals and user guides at all-guides.com Yaris AUDIO CD-CHANGER INSTALLATION Cut one tape into ten pieces and another tape into six as shown in the picture. • : Component part of CD changer kit Fig. 1 08695-00370 FOR EUROPE PRODUCTION Route the changer wire by using the tape...
  • Page 11 All manuals and user guides at all-guides.com Yaris AUDIO Cut the floor carpet. Fig. 4 Route the changer wire . Bundle excess wire and tape with the large tape as shown by going through the hole of the cross member near the door. Excess wire Hole Fig.
  • Page 12 All manuals and user guides at all-guides.com Yaris AUDIO Install the changer unit to the brack- b) Connect the changer wire to the changer unit : Screw (4x) • : Component part of CD changer kit Fig. 7 FOR JAPAN PRODUCTION Turn the floor carpet with felt.
  • Page 13 All manuals and user guides at all-guides.com Yaris AUDIO 10. Attach the spacers and the tapes to the base bracket : Screw (M5x10) (4x) : Spacer with nut (4x) : Tape (2x) Fig. 10 11. Attach the base bracket to the floor and fold back the cut parts of the carpet Fig.
  • Page 14 All manuals and user guides at all-guides.com Yaris AUDIO 12. Install the side brackets to the chang- er unit : Side bracket (2x) : Flat head screw (M5x8) (4x) Screw Hole position on the Hole position on the left side (G) right side (G) Fig.
  • Page 15: Subwoofer Installation

    All manuals and user guides at all-guides.com Yaris AUDIO SUBWOOFER INSTALLATION Put protective tape on the shaded areas. CAUTION Be sure to remove the parts carefully so you do not damage the panels. Fig. 1 Remove the center cluster panel (L) and (R) : Clip (6x) : Hook (8x)
  • Page 16 All manuals and user guides at all-guides.com Yaris AUDIO Remove the audio unit : Clip (4x) : Screw (4x) Fig. 4 Remove the scuff plate and the cowl side trim on the passenger’s side. : Clip (1x) (Cowl side trim) : Hook (1x) (Cowl side trim) : Clip (2x) (Scuff plate) : Hook (2x) (Scuff plate)
  • Page 17 All manuals and user guides at all-guides.com Yaris AUDIO Fit brackets to the subwoofer : Screw with washer (4x) • : Component part of audio mounting kit PZ425-B0221-60 • : Component part of subwoofer kit Fig. 7 Cut the carpet with felt as shown in the illustration.
  • Page 18 All manuals and user guides at all-guides.com Yaris AUDIO Turn the floor carpet with felt. b) Route and tape the subwoofer wire with tapes Floor carpet Excess wire Fig. 10 11. Connect the subwoofer wire harness 10P Audio connector to the 10P audio connector of the vehi- cle wire harness and to the audio unit Fig.
  • Page 19 All manuals and user guides at all-guides.com Yaris AUDIO Replace the floor carpet with felt. b) Fit the base bracket to the floor using adhesive tape • : Component part of audio mounting kit PZ425-B0221-60 Fig. 13 14. Mount the subwoofer as shown in the illustration and connect the sub- woofer wire...
  • Page 20 All manuals and user guides at all-guides.com GENUINE PARTS...
