T7/T71/T73
M40000/M40001/M40003
REPAIR PARTS CATALOG NO. M30202(R)
For Machines with Serial No. T6183-T9031
ISSUED July 2009
ORDERS
Please use Part Numbers when ordering and include the
the machine Serial Number (found on the electrical data
plate) to insure that you will receive the correct parts.
Order from your HOST Distributor.
Racine International, LLC.
1405 Sixteenth Street
P.O. Box 1648
Racine, WI 53401 USA
1-262-637-4491
1-800-558-9439
FAX 1-262-637-0558
www.hostdry.com
Parts Catalog

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Freestyle T7 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Host Freestyle T7

Summary of Contents for Host Freestyle T7

  • Page 1 Please use Part Numbers when ordering and include the the machine Serial Number (found on the electrical data plate) to insure that you will receive the correct parts. Order from your HOST Distributor. Racine International, LLC. 1-262-637-4491 1405 Sixteenth Street...
  • Page 2 16. Do not use as a wet vacuum. 17. Do not use without filters in place. 18. Connect to a properly grounded outlet only. See Grounding Instructions. 19. This machine is to be used with HOST carpet cleaning products only. Use of other cleaning ®...

  • Page 3: Grounding Instructions

    G ROUNDING INSTRUCTIONS GROUNDED OUTLET BOXES TAB FOR METAL GROUNDING SCREW SCREW GROUNDING PIN ADAPTER This machine must be grounded. If it should malfunction or break down, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This machine is equipped with a cord having an equipment-grounding conductor and grounding plug.

  • Page 4: Table Of Contents

    T ABLE OF CONTENTS Safety Instructions __________________________________________________ Grounding Instructions ______________________________________________ Section I - T7/T71/T73 Parts __________________________________________ Operating Handle Assembly __________________________________________ Lifting Handle Assembly ______________________________________________ Motor Case Assembly ________________________________________________ 10/11 Outer Gear Case Assembly __________________________________________ 12/13 Inner Gear Case Assembly ____________________________________________ 14/15 Motor Shroud Assembly ______________________________________________ 16/17 Nozzle/Inner Hood Assembly __________________________________________ 18/19 Brush &...
  • Page 5 Racine International, LLC. Racine Industries Inc. 1405 Sixteenth Street P.O. Box 1648 Racine, Wisconsin 53401 1-800-558-9439 1-262-637-4491 FAX 1-262-637-0558 www.hostdry.com...

  • Page 7: Operating Handle Assembly

    OPERATING HANDLE ASSEMBLY Code No. Part No. Description M30592 Operating Handle Assembly (Includes Code Nos. 1-6) M30591 Handle, Pinned & Welded K1031 Cord Hook (2 Required) K1030 Cord Clip (T7) M7053B ⁄ Screw 10-32 x " (4 Required) M30600 Tube Plug M30604 Foam Grip *Not Illustrated...

  • Page 8: Lifting Handle Assembly

    L IFTING HANDLE ASSEMBLY...
  • Page 9 L IFTING HANDLE ASSEMBLY Code No. Part No. Description M30140 Decal, Handle Release M30101 Plunger, Handle Release M30117 Spring M30104 Retaining Ring ⁄ " Shaft M30100 Retainer, Handle Release M30553 Handle Support M30456 Lifting Handle Weldment M30281 Screw 10-32 x ⁄...

  • Page 10: Motor Case Assembly

    M OTOR CASE ASSEMBLY...
  • Page 11 M OTOR CASE ASSEMBLY Code No. Part No. Description H1072 Screw 8-32 x ⁄ " (2 Required)) M30062 Motor Exhaust Duct D365 Set Screw 10-24 x ⁄ " (4 Required) M30122 Motor Case (Includes Code No. 5) M50325 Tolerance Ring M30373 Field 100V (T73) M6100NA...
  • Page 13 Code No. Part No. Description M9019 Screw 10-24 x 1" (3 Required) D277 Lockwasher #10 (6 Required) M30115 Mounting Flange F2771 Screw 10-32 x ⁄ " (3 Required) M30361 Gasket, Outer Gear Case M30157 Gear Case Assembly M30541 Brush Shaft Assembly M6003A Bearing (2 Required) M30085...
  • Page 15 Code No. Part No. Description M12010 Gasket U1423 Retaining Ring ⁄ " Shaft (2 Required) M12042 Gear, Left Hand U1605A Woodruff Key (2 Required) M12043 Gear, Right Hand M12018 Inner Gear Case M9002 Bearing (2 Required) M12019 Pulley Flange (2 Required) M12044 Pulley Shaft (2 Required) M12008A...
  • Page 17 (Also includes Code Nos. 36, 37) M30535 Motor Shroud Assembly w/ Switches 100/120V (T7/T73) M30536 Motor Shroud Assembly w/ Switches 220/240V (T71) (Also includes Code No. 38) M30046 Decal HOST Machine ® M30568 Hook Fastener (2 Required) M30367 Decal Switch 220/240V (T71)

  • Page 19: Nozzle/Inner Hood Assembly

    NOZZLE/INNER HOOD Code No. Part No. Description M30508 Pickup Nozzle V115 Screw 10-24 x ⁄ ", Hood to Gear Case (2 Required) U1018A Washer #10 (2 Required) M30063 Inner Hood M30145 Screw 8-32 x ⁄ ", Nozzle to Hood (3 Required) M30284 Gasket, Inner Hood Side (2 Required) M30283...

  • Page 20: Brush & Tray Assembly

    B RUSH & TRAY ASSEMBLY...
  • Page 21 B RUSH & TRAY ASSEMBLY Code No. Part No. Description See Below Brush (2 Required) F817 Washer, Nylon (4 Required) M1014 Spring Clip (1 Required per Brush) V703A Screw #4 x ⁄ " Self-Tapping (1 Required per Brush) M40300 Tray Assembly M30011 Tray F824...

  • Page 24: Section Ii - M40000/M40001/M40003 Vac Parts

    T ABLE OF CONTENTS Section II - M40000/M40001/M40003 Vac Parts ____________________________ Vac Assembly ______________________________________________________ 26/27 Vac Motor Assembly ________________________________________________ 28/29 Vac Wiring Diagram - 100/120V ________________________________________ Vac Wiring Diagram - 220/240V ________________________________________...
  • Page 25 Racine International, LLC. Racine Industries Inc. 1405 Sixteenth Street P.O. Box 1648 Racine, Wisconsin 53401 1-800-558-9439 1-262-637-4491 FAX 1-262-637-0558 www.hostdry.com...
  • Page 26 V AC ASSEMBLY...
  • Page 27 V AC ASSEMBLY Code No. Part No. Description M30584 Cover, Filter Housing W529 Nylon Washer, Flat (2 Required) M30172 Washer, Square (2 Required) L2012 Screw, Shoulder (2 Required) M30010 Carrying Handle M30003 Filter Housing M30028 Latch Assembly (2 Required) H1072 ⁄...
  • Page 28 V AC MOTOR ASSEMBLY...
  • Page 29 V AC MOTOR ASSEMBLY Code No. Part No. Description M30054 Terminal Block Cover ⁄ M30147 " (2 Required) Screw 8-32 x M5005 Lockwasher #8 (2 Required) M30053 Terminal Block M30016 Motor Mounting Plate ⁄ M30216 " Self-Tapping (4 Required) Screw #10 x ⁄...
  • Page 32 © 2009 Racine International, LLC. (800) 558-9439 1405 Sixteenth Street (262) 637-4491 P.O. Box 1648 (262) 637-0558 Racine, WI 53401 USA www.hostdry.com M30202(R) HOST, Freestyle and extractorVAC are registered trademarks of Racine International, LLC. Racine, Wisconsin USA.
