Summary of Contents for Excelair Dual Room Damper Package
- Page 1 Thermostat 1 Top Supply Air Plenum Thermostat 2 Dampers Room Dampers Room (black) (black) Bottom Return Relay Air Plenum 11 Pin Damper Commons (White) Air Handler “R” Terminal Air Handler “C” Terminal Air Handler “G” Terminal...
- Page 2 Dual Room Damper Package Installation To begin, first designate which room you will label as Room 1 (which will be the “off” room when there is no power to the timer) and Room 2. Step 1: Place the Bottom Return Air Plenum where you would like the unit to sit. Now set the Indoor Air Handler on top of the bottom plenum.
