- Page 1 Safety Guidelines & Installation Manual Language: English Version:...
-
Page 2: Table Of Contents
Safety ........................4 Intended Use ......................4 Delivery Contents ......................5 Mechanical Installation ....................6 Safety Precautions ....................6 Directions for the ALPHA ..................6 3.2.1 SIM Card ......................7 3.2.2 Tool setting via pushbutton and LED indication ..........8 3.2.3... -
Page 3: Indications For Use
1 Indications for Use It is essential to read the operating instructions carefully and completely before using the first time the equipment and software. They contain important information on safety, installation and use. Keep these instructions in a safe place. 1.1 Symbols Warning of dangerous situations that can cause injury and damage to the devices. -
Page 4: Safety
Do not make any changes or alterations to our products. The ALPHA contains a rechargeable battery. The battery/cells must not be removed from the ALPHA, must not be short-circuited, physically damaged or exposed to heat, fire or water. -
Page 5: Delivery Contents
ALPHA V2: Communication between loggers and repeaters Solar panel: Recharges the battery of the ALPHA Power cord: For the connection between the ALPHA and the solar panel Fastening material: For fastening the ALPHA and the solar panel External antenna (optional): For enhanced data transmission... -
Page 6: Mechanical Installation
Especially when in use in conjunction with ZONESCAN 820 system, which is spread out over a larger area, it is recommended to place the ALPHA at the highest position available in order to ensure the best radio connection possible. -
Page 7: Sim Card
3.2.1 SIM Card Open the ALPHA carefully. The SIM card slot is located at the top of the device. Place the SIM card as shown and insert it into the slot: Before closing the ALPHA, check the seal. Remove any dirt and exchange it if damaged. -
Page 8: Tool Setting Via Pushbutton And Led Indication
3.2.2 Tool setting via pushbutton and LED indication The device is equipped with a push button and one LED that can indicate red and green. This allows to enforce some fundamental settings. • Switch the device into the sleep mode and wake it up from the sleep mode: In the sleep mode nearly all functions of the device are disabled and the power consumption is reduced to the minimum. -
Page 9: Mounting The Alpha
3.2.3 Mounting the ALPHA On the back side of the ALPHA there is a metal mounting plate which enables secure installation also to round objects. Make sure to use mounting material suitable for the environment. To ensure redundancy, it is mandatory to use always two fastening elements for the ALPHA housing. - Page 10 Modem antenna location Internal on both sides Modem antenna provision Free line of sight to the base station is optimal Internal radio antenna location Internal antenna below the lid Internal radio antenna provision Free line of sight to the repeater is optimal 10 I 19...
-
Page 11: Directions For The Power Supply
3.3 Directions for the Power Supply The main power supply for the ALPHA is a solar panel which is used to charge the internal battery. If an alternative power supply (12V ±10% / 4W) is used, it must be installed by a skilled electrician in compliance with local regulations. -
Page 12: Directions For External Antennas
This Yagi type antenna is a directional antenna with a main horizontal distribution at +/- 30 ° of the direction it is pointed to. It is best used, if the ALPHA is placed outside the installation area of loggers that should be covered. -
Page 13: Omnidirectional Antenna Xl-900-3Lw
3.4.2 Omnidirectional Antenna XL-900-3LW This 70 cm rod antenna is an omnidirectional antenna. It is best used, if the ALPHA is placed within the installation area of loggers which should be covered. Mounting clamp fits poles up to 50 mm. Always use both clamps and securely tighten the screws. -
Page 14: Technical Data
4 Technical Data 4.1 Mechanical Dimensions Parameter Comment min. typ. max. Unit Size Length Without connector Width Height With mounting plate Others Weight Operating temperature °C Protective class Connector inserted IP67 14 I 19... -
Page 15: Used Radio Frequencies
4.2 Used Radio Frequencies System Frequency Emitting Power Gutermann Radio (internal) 869.525 MHz 20 mW Gutermann Radio (external) 869.525 MHz Up to 500 mW (*) UMTS Band I 250 mW UMTS Band II 250 mW UMTS Band V 250 mW... -
Page 16: Battery
4.3 Battery Type LiFePO Number of cells Voltage 3.3 V / 3.6 V (nominal / charge) Capacity 33 Wh / 10 Ah Charging temperature -30 °C – 55 °C 4.4 Pin Assignment 4.4.1 Power Connector M8 Connector Pin Signal +12V / 4W Input Ground 4.4.2 Antenna Connector 1 to 3... -
Page 17: Storage And Transport
2 seconds. The LED will confirm entering sleep mode with 5 red flashes. The ALPHA will enter sleep mode on its own if over the course of two days there is no power supply connected and no SIM card inserted. -
Page 18: Conformity
8 Conformity This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference, including interference that may cause undesired operation of the device. -
Page 19: Important Information
9 Important Information Please draw your attention to all warnings and information in the manual and on the products. By using this product, you acknowledge that you are aware of and have read the warnings and information provided in the manual. Always clean the sensors and mechanical accessories with a clean towel after use before stowing them away in the carry case.
