OPERATING INSTRUCTIONS

MTC-40 radio-controlled room thermostat

Table of Contents

Need help?

Do you have a question about the MTC-40 and is the answer not in the manual?

Questions and answers

Summary of Contents for Marmony MTC-40

Page 1 OPERATING INSTRUCTIONS MTC-40 radio-controlled room thermostat...
Page 3: Table Of Contents
CONTEN TS OP E RA T ING IN S TRUCTIO NS M TC -40 Technical data ..................4-5 Description ....................6 Use in the home ..................7 Explanation ....................8 Installation .................... 9-12 Settings ....................13-14 Button features description ..............15 Menu selection ................... 16-19 Holiday mode ..................
Page 4: Technical Data
TECHNICAL DATA T RA N S M ITTER / THERMO STA T » Display with background lighting » Holiday programme » Key lock / parental control » Automatic frost protection (3 ˚C) » Automatic daylight saving time / » Open window recognition standard time change »...
Page 5 T E C H NIC A L D A TA RE CE I VE R » Switching capacity: 6.3 A / 230 V AC / 1449 W Max. » Switching capacity: 6.3 A / 230 V AC / 1449 W Max. (Switzerland) »...
Page 6: Description
/ off button without a thermostat. Warnung! The receiver is only suitable for use with a marmony marble heating plate. Operation with devices over 1449 Watt / 6.3 A 230 V leads to the triggering of the internal...
Page 7: Use In The Home
USE IN THE HOME...
Page 8: Explanation
ERKLÄRUNG Holiday Parental control Frost protection Transmission display Heating Battery empty display Target temperature (SOLL) SOLL Actual temperature (IST) Day (T), Month (M), Year (J) Day of the week Time MO DI MI DO FR SA SO ON / OFF Daylight saving time / standard time AUTO MANU...
Page 9: Installation
INSTALLATION TRANSMITTER 1. Remove the cover of the battery compartment by gently pressing the recessed grip and removing the battery cover. See Fig. 1 2. Insert two alkaline batteries (Type AA / LR6) into the battery compartment. Fig. 1 Ensure that the polarity is correct! See Fig.
Page 10 INSTALLATION DISPLAY HINTERGRUNDBELEUCHTUNG SOLL SOLL Press any button. AUTO AUTO The display must be switched on to change a setting (1 x press any button). The display switches itself back off again after 15 seconds. When you are programming a setting, the thermostat switches back to the main menu after 30 seconds if you do not enter anything! Anything you have already entered will be saved automatically.
Page 11 INSTALLATION RECEIVER LED display of the operating status Manual ON / OFF switch Ready for operation (Heating off) Green Heating operation (Heating on) With the ON / OFF button, the heater can be switched on and off independently from the thermostat. Important information: If the receiver is being operated without a thermostat, the thermostat/transmitter must be switched off.
Page 12 1. Connect the receiver to the 230 V socket which you intendto use to connect your marmony infrared heater. 2. Connect the connector plug on your marmony infrared heater to the receiver socket. 3. That’s it! In the factory settings, both the transmitter and the receiver are connected to each other (paired).
Page 13: Settings
Example: If the TARGET temperature is 20 °C and the hysteresis is 1 °C, the thermostat switches the heater off at 20 °C and switches it back on again in the event of a temperature drop to 19 °C. Recommended setting for marmony infrared heaters: “1.0 °C”...
Page 14 In the display at the top left you can see OFF and at the bottom the “1” value is flashing. Press the “SET / OFF button” to confirm. This value is not relevant for marmony infrared heaters and must not be changed. Confirm value by pressing the “SET / OK button” to confirm.
Page 15: Button Features Description
BUTTON FEATURES DESCRIPTION SET / OK – button: Sets the date and time, sets the programmes and confirms entry values: AUTO P1 / P2 – Holiday mode – Date / time + / - button: Programme selection in ON / OFF mode: AUTO-P1 /AUTO-P2 / MANU / Holiday / TEST / OFF Value entry during programming START button: Activates the programme selected in the programme row (programme...
Page 16: Menu Selection
If the thermostat is in an active programme (display in the programme row is flashing, the active programme can be exited by pressingthe ON / OFF button. The programme row now showsOFF. Heating mode is switched off. Symbol row: The symbol row features the symbols for heating , frost protection , holiday , parental control...
Page 17 The “flame symbol” is illuminated in the symbol row when heating mode is switched on. The receiver switches your marmony infrared heater on. The LED on the receiver is illuminated in green (heating mode).
Page 18 MENU SELECTION AUTOMATIC TEMPERATURE CONTROL “AUTO” Setting automatic temperature control “AUTO” (P1 / P2) In “AUTO” mode, you can set different programmes for each day of the week as you wish (P1 / P2), each with 6 switching and switching off times (U1-U6).
Page 19 - Press the “SET / OK” button for 3 seconds The day of the week “Mon” flashes! Use the + / - buttons now to select an individual day (individual Mon, Tue, Wed, Thu, Fri, Sat, Sun) or a day of the week group.
Page 20: Holiday Mode
Note: If you only wish to set one, two, three, four or five switching on and off times, once you have entered the final value you wish to enter, wait until the thermostat switches back to the main menu (approx. 15 seconds) and the values you have entered will be saved automatically.
Page 21 - The date for the holiday start date “year” flashes, use the “+/- button” to select the desired year and confirm by pressing the “SET / OK” button. The month flashes, use the “+ / - button” to select the desired month and confirm by pressing the “SET / OK”...
Page 22: Miscellaneous
MISCELLANEOUS Frost protection: Should the room temperature fall below 3 °C in “OFF mode”, the frost protection is automatically activated (the frost symbol is illuminated in the symbol row). The thermostat switches to heating mode. If the room temperature rises to +12 °C, the heating mode is deactivated again and the thermostat switches back into “OFF mode”.
Page 23 Daylight saving time / standard time changeover: The thermostat automatically switches the daylight saving time / standard time on or off. On 24th March at 23:59, the time is moved forwards by an hour. (daylight saving time) On 28th October at 23:59, the time is moved backwards by an hour (standard time).
Page 24 Contact: Phone: +49 (0) 800-540 54 54 support@carstensen.de Distributor: Carstensen Import-Export Handelsgesellschaft mbH Werner-von-Siemens-Straße 3-7 25479 Ellerau Produced for: marmony GmbH Johannes-Kepler-Straße 11f DE-94315 Straubing www.marmony.de...
