Summary of Contents for LiteLEES BIG EYE L4007R
- Page 1 KEEP THIS USER MANUAL FOR FUTURE NEEDS...
-
Page 3: Table Of Contents
Content 1. Introduction ………………………..………………………………………4 Cleaning and Maintenance ….……………………………………………4 S t a t e m e n t … … … … … … … … … … … … … … … … … … … … … … … … 5 4. -
Page 4: Introduction
Thank you for your patronage! We are confident that our excellent products and service can satisfy you. For your own safety, please read this user manual carefully before installing the device. In order to install, operate, and maintain the lighting safety correctly. We suggest that the installation and operation should be done by the verified technician and follow the instruction strictly. -
Page 5: Statement
unbalances. 4) The electric power supply cables must not show any damage, material fatigue or sediments. Further instructions depending on the installation spot and usage have to be adhered by a skilled installer and any safety problems have to be removed. CAUTION! Disconnect from mains before starting maintenance operation! In order to make the lights in good condition and extend the life time, we suggest a regular... -
Page 6: Technical Parameters
TECHNICAL PARAMETERS Power supply AC90 - 250V,50/60Hz Power consumption: 350W@220V Light source 7*40W RGBW 4 in1 Osram LEDs Individual LED control Average life: 30,000 hrs Color temperature：2500K-9000K Color RGBW (red, green, blue and white) linear color mixing adjustment Effect Zoom angle: 4-60°; 16800lux@5m@Min angle Wash/Beam/Graphic/Effects function Front lens can rotated infinity With“vortex”and “kaleidoscope”... -
Page 7: Fixture Size
Fixture Size Photometrics Electrical parameters cosΦ （V） （A） （W） （PF） （HZ） 1.311 299.3 0.952 50.0 1.419 0.963 50.0 2.600 0.991 60.0... -
Page 8: Menu Function
MENU FUNCTION Main Menu Level 1 Level 2 Address Setting Address 21CH 35CH DMX Mode 42CH 49CH Automatic Mode Running Mode Color Macro Manual Test Strobe Dimmer Tilt Zoom Zoom Rotation... - Page 9 Main Menu Level 1 Level 2 Pan Reverse Tilt Pan Reverse Pan/Tilt Swap Screen Reverse Advanced Settings Language Chinese/English Dimmer Speed Fast/Smooth Dimmer Curve Reset Reset default Version Number Running Mode System Information Dmx Address Temperature Lamp Beads Hours...
-
Page 10: Functions Of Buttons
FUNCTIONS OF BUTTONS Reversal of the display To activate this function, press the UP and DOWN keys while the display is in the still mode.the screen is reversed, and the control keys are also reversed. To return to the initial state, repeat the operation again. - Page 11 Packaging considerations The X-axis rapid lock forward is LOCKED,and backward (UNLOCKED) to open. CAUTION! Before packing, please get the zoom lens back inside.(Please match the ARROWS with the DOT) Without this operation, there will be damage of the fixture!
-
Page 12: Dmx Channels
DMX Channels... -
Page 15: Shape Details
CONCEPTS: FOREGROUND AND BACKGROUND The powerful shapes engine embedded in the LiteLEES Big-EYE L10 ROTATION and L10 EASY allows the user to set all the possible parameters relating to the pixels of the light in an organic way, with a distinction between the pixels affected by a selected "image"... - Page 16 SELECTION*SHAPE SPEED*SHAPE OFFSET*SHAPE FADE*BACKGROUND SELECT Rando Shape Shape Background Shape Speed Shape Offset Shape Fade Shape Name Selection Slot Select(*3)(*4) Colors Macro OFF Pixel 1 Ring 2 Size change One outer loop 0-7 = wash 8-15 = background rings Two outer loop selection Double abreast 16-254 = wash...
- Page 17 Background Shape Shape Random Shape Speed Shape Offset Shape Fade Select Shape Name Selection Slot Colors *1 (*3)(*4) Left/Right scrolling bar Mirror pixel 0-7 = wash 8-15 = Bkgnd Following pixel rings selection Wing 16-254 = Vertical pixel wash scrolling 255 = Mirror effect with Vertical double...
