HYDRO TRACTOR
Parts Manual
Models
936063 46" Hydro Tractor
ENGLISH
532 44 70-67 (21547957) Rev 1 10.21.11
Printed in the U.S.A.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 936063 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ariens 936063

Summary of Contents for Ariens 936063

  • Page 1 HYDRO TRACTOR Parts Manual Models 936063 46" Hydro Tractor ENGLISH 532 44 70-67 (21547957) Rev 1 10.21.11 Printed in the U.S.A.

  • Page 2: Table Of Contents

    The model number for your tractor can be found on the fender under the seat. When ordering parts, always give the following information: • Product - “Tractor” • MODEL NUMBER - “936063 (96046003301)” • Part Number • Part Description TABLE OF CONTENTS SCHEMATIC ........................

  • Page 3: Schematic

    TRACTOR - - MODEL NUMBER 936063 (96046003301), PRODUCT NO. 960 46 00-33 SCHEMATIC SCH11 BATTERY SOLENOID STARTER FUSE AMMETER BLACK (OPTIONAL) WHITE WHITE ATTACHMENT CLUTCH (CLUTCH OFF) BLACK CLUTCH/BRAKE GRAY (PEDAL UP) REVERSE SWITCH BLACK (NOT IN REVERSE) BLACK BLACK...

  • Page 4: Electrical

    TRACTOR - - MODEL NUMBER 936063 (96046003301), PRODUCT NO. 960 46 00-33 ELECTRICAL T02S With 12V Outlet Option With Service Minder Option...
  • Page 5 TRACTOR - - MODEL NUMBER 936063 (96046003301), PRODUCT NO. 960 46 00-33 ELECTRICAL ITEM MFG. ARIENS PART NO. DESCRIPTION 532 16 34-65 21546162 BATTERY.12.VOLT.28.AMP .WET 874 76 04-12 21546803 BOLT.HEX.HD.1/4-20 UNC X 3/4 532 19 32-28 21546315 BOX.BATTERY.MNT.REAR.LT.TEX.BL 532 17 61-38 21546205 SWITCH.INTERLOCK.NONO.GRAY...

  • Page 6: Chassis

    TRACTOR - - MODEL NUMBER 936063 (96046003301), PRODUCT NO. 960 46 00-33 CHASSIS chassis-tex_TEX LT PRED_57...
  • Page 7 TRACTOR - - MODEL NUMBER 936063 (96046003301), PRODUCT NO. 960 46 00-33 CHASSIS ITEM MFG. ARIENS PART NO. DESCRIPTION 532 42 57-72 21547746 DASH 532 44 17-89 21547755 HOOD 532 44 17-83 21547753 GRILLE 532 19 61-25 21546384 PLATE.ENGINE.WELDED.CHASSIS 817 06 05-12 21546187 SCREW.5/16-18 X 3/4.SMGML.TAP/R...

  • Page 8: Drive

    TRACTOR - - MODEL NUMBER 936063 (96046003301), PRODUCT NO. 960 46 00-33 DRIVE 80 125 drive-tex_K46_fender_24_r2...
  • Page 9 TRACTOR - - MODEL NUMBER 936063 (96046003301), PRODUCT NO. 960 46 00-33 DRIVE ITEM MFG. ARIENS PART NO. DESCRIPTION – – – – – – – – – – TRANSAXLE, TUFFTORQ K46 BA(408214) (ORDER PARTS FROM TRANSAXLE MANUFACTURER.) 532 12 35-83 21546070 KEY.SQUARE.2.0 X .1845/.1865...

  • Page 10: Engine

    TRACTOR - - MODEL NUMBER 936063 (96046003301), PRODUCT NO. 960 46 00-33 ENGINE OPTIONAL EQUIPMENT SPARK ARRESTER engine-tex_BS_2_r3...
  • Page 11 TRACTOR - - MODEL NUMBER 936063 (96046003301), PRODUCT NO. 960 46 00-33 ENGINE ITEM MFG. ARIENS PART NO. DESCRIPTION – – – – – – – – – – ENGINE BRIGGS MODEL NO. 331777-4372- G1(440263) (ORDER PARTS FROM ENGINE MANUFACTURER.)

  • Page 12: Steering

    TRACTOR - - MODEL NUMBER 936063 (96046003301), PRODUCT NO. 960 46 00-33 STEERING steering-tex_STDHRS_14...
  • Page 13 TRACTOR - - MODEL NUMBER 936063 (96046003301), PRODUCT NO. 960 46 00-33 STEERING ITEM MFG. ARIENS PART NO. DESCRIPTION 532 42 45-43 21547744 WHEEL.STEERING.HARD RIM.BLACK 532 41 81-68 21546681 AXLE ASM.WELDED 532 40 30-87 21546582 SPINDLE.WELDED.LH.15"TEX 532 40 30-88 21546583 SPINDLE.WELDED.RH.15"TEX...

  • Page 14: Mower Deck

    TRACTOR - - MODEL NUMBER 936063 (96046003301), PRODUCT NO. 960 46 00-33 MOWER DECK 69 69 46_tex_lt_pred_26_r1...
  • Page 15 TRACTOR - - MODEL NUMBER 936063 (96046003301), PRODUCT NO. 960 46 00-33 MOWER DECK ITEM MFG. ARIENS PART NO. DESCRIPTION 532 44 26-93 21547946 DECK.WELDMENT.46"4GA WHL. 532 40 55-07 21546618 COVER.MANDREL.LH.46" 532 40 55-06 21546617 COVER.MANDREL.RH.46" 532 19 51-86 21546347 ARM.SUSPENSION.MOWER.REAR.LD...

  • Page 16: Mower Lift

    TRACTOR - - MODEL NUMBER 936063 (96046003301), PRODUCT NO. 960 46 00-33 MOWER LIFT 101* lift-tex_17_r3 *Key 91 may be substituted for Key 101...
  • Page 17 TRACTOR - - MODEL NUMBER 936063 (96046003301), PRODUCT NO. 960 46 00-33 MOWER LIFT ITEM MFG. ARIENS PART NO. DESCRIPTION 532 42 20-27 21547240 SHAFT ASM.LIFT.CROSS.HD. 532 19 52-31 21546358 LEVER.LIFT.HANDLE.LT 532 41 15-55 21547565 GRIP .LEVER..5625 ID.BLACK 428 532 19 63-14 21546397 SPRING.TORSION.HANDLE.LIFT...

  • Page 18: Seat

    TRACTOR - - MODEL NUMBER 936063 (96046003301), PRODUCT NO. 960 46 00-33 SEAT seat-tex_6.5SL_1_r1...
  • Page 19 TRACTOR - - MODEL NUMBER 936063 (96046003301), PRODUCT NO. 960 46 00-33 SEAT ITEM MFG. ARIENS PART NO. DESCRIPTION 532 42 30-10 21546703 SEAT.TA150.KB/SLD.BLK.ARIENS 532 18 01-66 21546216 BRACKET.PIVOT.FENDER.2002 532 14 06-75 21546101 STRAP ASM.FENDER.94 873 80 06-00 21546787 LOCKNUT, WASHER INSERT 3/8-16...

  • Page 20: Decals

    TRACTOR - - MODEL NUMBER 936063 (96046003301), PRODUCT NO. 960 46 00-33 DECALS WHEELS AND TIRES wheel_art_1-tex...
  • Page 21 TRACTOR - - MODEL NUMBER 936063 (96046003301), PRODUCT NO. 960 46 00-33 DECALS ITEM MFG. ARIENS PART NO. DESCRIPTION 532 42 95-51 21547594 DECAL ENGINE H.P . 532 44 15-86 21547752 DECAL.HOOD.LH/RH. 532 43 91-26 21547732 DECAL.SDPNL.PWRDBY ARIENS 532 42 28-11 21546691 DECAL.DASH.LWOWER.20HP .ARIENS...

  • Page 22: Parts And Service

    For parts and service, contact your local Ariens dealer. To find a dealer in your area, call 1-877-257-6920, or use the Dealer Locator on our web site, www.ariens.com.
