PRESS
PWT3000
INDUSTRAIL GASOLINE PRESSURE WASHER
OPERATOR'S MANUAL
IT IS EXTREMELY IMPORTANT TO READ AND UNDERSTAND THE
ENTIRE CONTENTS OF THIS OPERATOR'S MANUAL BEFORE
ATTEMPTING TO OPERATE THE PRODUCT. THIS EQUIPMENT IS
POTENTIALLY HAZARDOUS AND COULD CAUSE PHYSICAL
INJURY OR EVEN DEATH IF IMPROPERLY USED.
Advertisement
Related Manuals for Kohler PWT3000
Summary of Contents for Kohler PWT3000
- Page 1 PRESS PWT3000 INDUSTRAIL GASOLINE PRESSURE WASHER OPERATOR’S MANUAL IT IS EXTREMELY IMPORTANT TO READ AND UNDERSTAND THE ENTIRE CONTENTS OF THIS OPERATOR’S MANUAL BEFORE ATTEMPTING TO OPERATE THE PRODUCT. THIS EQUIPMENT IS POTENTIALLY HAZARDOUS AND COULD CAUSE PHYSICAL INJURY OR EVEN DEATH IF IMPROPERLY USED.
- Page 2 UNTIL READING WARNING DO NOT OPERATE THIS EQUIPMENT UNTIL READING AND UNDERSTANDING OPERATOR’S MANUAL TABLE OF CONTENTS Safety ........................................2 Specifications ....................................12 Operation ......................................5 Maintenance and Troubleshooting ..............................11 The following signal words and meanings are intended to explain the level of risk associated with this product Indicates a hazard which, if not avoided WILL result in death or serious injury.
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS • User accepts responsibility for injuries and/o r d a m a g e resulting fr om o t he r • Manufacturer shall not be responsible for any applications. consequences resulting from improper use of this equipment. - Page 4 EQUIPMENT SPECIFIC WARNINGS Read the entire important safety information section at the beginning of this manual including all text under subheadings therein therefore set up or use of this product. Your Pressure Washer, Model PWT-3000 is a gasoline operated device that converts a water source flow into extremely high pressure.
- Page 5 To disassemble the hose and nozzle, pull collar back and remove hose or nozzle. Figure 1 A- Quick Connect (QC) Nozzle B- Spray wand with QC coupling. 1. Pull the collar back on the QC 2. Push nozzle into place 3.
- Page 6 INSPECTION AND START UP INSPECT YOUR PRESSURE WASHER CAREFULLY FOR ANY DAMAGE THAT MAY HAVE OCCURRED DURING TRANSIT. BE SURE TO INSPECT AND TIGHTEN ALL BOLTS, SCREWS, AND FITTINGS BEFORE ATTEMPTING TO START THE UNIT. DO NOT ATTEMPT TO OPERATE A DAMAGED UNIT. IT MAY CAUSE SERIOUS INJURY OR PROPERTY DAMAGE! START-UP LUBRICATION...
- Page 7 Frequently Asked Questions The unit will not START. How can I safely fill the fuel tank? Check gasoline supply. Check spark plug. Check Only add gasoline to a cool engine. If the unit has been in engine oil. See engine Manual operation, it should be allowed to sufficiently cool and assure the unit is outdoors with adequate ventilation.
- Page 8 Stored batteries give off explosive hydrogen gas Avoid smoking, open flames, sparks or any other while recharging. An explosive mixture will source of heat around a battery. Wear protective remain around the battery for a period of time goggles, rubber apron and rubber gloves when after it has completed recharging.
- Page 9 Nozzle Maintenance: If the spray pattern of the washer becomes distorted or uneven, it may require you to remove debris within the nozzle. Before performing any maintenance, stopping or storing the machine the residual pressure MUST be released from the trigger gun. The trigger gun traps high pressure even when the engine is stopped.
- Page 10 Table 1 Nozzle Application 0º Red • Spot cleaning of high, hard-to-reach areas NEVER change nozzles without turning off the • Removing heavy mud from heavy con- pressure washer, relieving all system pressure and struction, farm, or lawn equipment locking the lock out on the trigger handle. •...
- Page 11 To increase pressure: rotate knob clockwise. To decrease pressure: rotate knob counterclockwise. Your pressure washer comes preset with the pressure at its maximum. If you require less pressure, you can adjust the pressure down by adjusting the pressure as shown above. Pressure Adjustment Soap injector Pressure Gage...
-
Page 12: Troubleshooting
TROUBLESHOOTING Problem Cause Solution 1. Turn supply water “on”. 1. Water is turned off. Engine is running but no water is 2. Unwind hose and remove kinks. 2. Hose is kinked flowing. 3. Remove garden hose from pump; 3. Inlet filter is stopped up. clean the stainless steel mesh screen. - Page 13 FEATURES Kohler CH270 Gasoline Engine Suction Side Soap Pickup Rugged Aluminum Construction Low Oil Shutdown Quick Connect for Nozzles 2 Year Engine Warranty 1 Year Pump & Accessories Warranty SPECIFICATIONS SI – 3000 GPM – 2.5 Engine HP – 7.0Hp CC’s –...
- Page 14 Notes Manufactured by: AMERICAN FAB of SC, LLC PO Box 879 Travelers Rest, SC 29690 Customer Service: 1-800-845-4141...
- Page 15 Notes AMERICAN FAB of SC, LLC...
