OPERATOR'S MANUAL

Read the instructions carefully and follow the rules for safe

operation.

Failure to do so could result in serious injury.

CSG CART

CWT-7410

WARNING

ENGLISH

ESPAÑOL

FRANÇAIS

Table of Contents

Need help?

Do you have a question about the CWT-7410 and is the answer not in the manual?

Questions and answers

Summary of Contents for Echo CWT-7410

Page 1 ENGLISH ESPAÑOL FRANÇAIS OPERATOR'S MANUAL CSG CART CWT-7410 WARNING Read the instructions carefully and follow the rules for safe operation. Failure to do so could result in serious injury.
Page 2: Important Information
IMPORTANT INFORMATION Please ensure that you read the opera- ○ Loaning or assigning your product tor's manual before using your product. When loaning the product described in ・ ○ Intended use of this product this manual to another party, ensure that the person borrowing and working ・...
Page 3: Table Of Contents
CONTENTS IMPORTANT INFORMATION ................... SYMBOLS AND SIGNS.................... PACKING LIST ......................NOMENCLATURE OF PARTS ................. OPERATOR SAFETY PRECAUTIONS ..............OPERATOR SAFETY ....................BEFORE YOU START ....................OPERATION ......................14 MAINTENANCE AND CARE ..................16 STORAGE AFTER USE ................... 18 TECHNICAL DATA ....................18 NOTES ........................
Page 4: Symbols And Signs
“NOMENCLATURE OF PARTS” section will help you locate them. Make sure the decal is legible and that you understand and follow the instructions on it. If a decal cannot be read, a new one can be ordered from your ECHO dealer.
Page 5: Packing List
The ECHO product you purchased has been After opening the carton, check for damage. factory pre-assembled for your convenience. Immediately notify your retailer or ECHO dealer of Due to packaging restrictions, guide bar and saw damaged or missing parts. chain installation and other assembly may be Use the packing list to check for missing parts.
Page 6: Nomenclature Of Parts
NOMENCLATURE OF PARTS Part number X505-011460 1. Throttle lever 14. Handle lock knob 2. Cart handle 15. Coupler 3. Operation label - X532-005990 16. Wheel brake 4. Depth adjustment lever 17. Operation label - X532-006000 5. Water tank cap 18. Front handle receiver plate 6.
Page 7: Operator Safety Precautions
OPERATOR SAFETY PRECAUTIONS HANDLING THE PRODUCT OPERATOR'S MANUAL LOANING OR ASSIGNING YOUR PRODUCT ○ Be careful to read the ○ When loaning your product to another party, operator's manual properly ensure that the person borrowing the product before using your product in receives the operator's manual along with it.
Page 8: Operator Safety
OPERATOR SAFETY WEAR PROTECTIVE GEAR WEAR PROPER CLOTHING 〇 Always wear the following protective gear 〇 Secure hair so it is above shoulder length. 〇 Do not wear ties, jewellery, or loose, dan- when working with the cut-off saw. Above all, make sure to wear safety goggles, a dust gling clothing which could be caught in the mask, and ear muffs at all times while work-...
Page 9: Before You Start
BEFORE YOU START ASSEMBLY WARNING CAUTION ○ Hold the water tank platform firmly when If used while the throttle cable is caught on removing the bolts on the water tank plat- other parts, neither the throttle nor the depth form. adjustment will work properly.
Page 10 PROCEDURE FOR MOUNTING THE ENGINE CUT-OFF SAW WARNING CAUTION 〇 Tighten the cutter lock knob all the way 〇 Use the wet cutting wheel recommended for our engine cut-off saw. ◆ If not tightened sufficiently, the engine cut-off 〇 Do not use the abrasive wheel. ◆...
Page 11 7. Fit the bottom rear of the handle of the engine cut-off saw between the guide pins Rear handle Guide pins Rear handle 8. While holding the rear handle of the engine cut- Cutter lock knob off saw down with the rear handle plate, tighten the cutter lock knob until it seats.
Page 12 PROCEDURE FOR REMOVING THE ENGINE CUT-OFF SAW 1. Set the depth adjustment indicator to parking po- Depth adjustment lever sition on the depth adjustment plate. (See page Depth Free side 10.) indicator Locked side 2. Apply the wheel brake on flat ground. 3.
Page 13 FUEL SUPPLY CAUTION • When laying the cart on its side, do so slowly and carefully to avoid any shocks to the cart. • Fuelling the cut-off saw with the cart on its side on a slope or uneven ground may result in spilling fuel if the cart shifts during refuelling.
Page 14: Operation
OPERATION CUTTING GUIDE WARNING CAUTION • Before use, make sure functions such as • Always use the water-flushing function of the throttle lever, depth adjustment and when using the cart for cutting. wheel break are working correctly. • Use clean water for flushing the cut. If dirty •...
Page 15 7. Release the wheel brake. Turn depth adjustment Wheel brake Free side lever to free side while lifting the cut-off saw with the cart-handle. Ground wheel to the floor and Locked gradually raise the engine speed. Use the cart side handle to adjust the load on the cutting edge so a load is not put on it suddenly, and start cutting Depth adjustment lever...
Page 16: Maintenance And Care
MOVING THE CART WARNING CAUTION • Remove the engine cut-off saw from the cart • If the throttle cable is not in the correct before loading it onto the bed of a vehicle. position, the depth adjustment lock may • If lifting the cart with the engine cut-off saw come unlocked.
Page 17 CART * When the cart pulls to one side. Front and rear 1. Loosen the front and rear bolts on the rear han- bolts dle mount of the engine cut-off saw and move the mount left or right to correct the pulling. Rear handle 2.
Page 18: Storage After Use
Lubricate parts • Lubricate moving parts before long-term storage. Lubricate parts TECHNICAL DATA 　 Model CWT-7410 Mountable products CSG-7410 Dimension L x W x H 1162 x 442 x 1069 (45.7 in. x 17.4 in. x 42.1 in.) Mass Unit Weight (Without engine cutter, 29.5 (65 lb.)
Page 19: Notes
NOTES...
