- Page 1 All manuals and user guides at all-guides.com...
- Page 2 All manuals and user guides at all-guides.com Contents Nova Quick Installation Guide Accessory: 10x Mainboard screws (6-32) 3x Mainboard standoffs (6 standoffs are embedded on the Mainboard tray) 16x 3.5” HDD screws 4x 2.5” HDD/SSD screws 3x Front-Panel screws 1x Speaker...
- Page 3 All manuals and user guides at all-guides.com Front Panel Dust Filter Fan (120mm) ODD clip Side Panel Windos Panel...
-
Page 4: Left Side
All manuals and user guides at all-guides.com Front Left Side Back Basic Installation How to remove the side panels a. Remove thumbscrews b. Slide the side panels towards the back of the case... - Page 5 All manuals and user guides at all-guides.com How to remove/clean the PSU dust filters FRONT Remove front panel BOTTOM Pull the PSU dust filter away from the case to remove it...
- Page 6 All manuals and user guides at all-guides.com Installing 3.5” Drives a. Slide drive into drive bay b. Secure with screws (for extra support, remove right sidepanel and install screws on the right side as well) Installing 2.5” Drives a. Slide drive into drive bay b.
- Page 7 All manuals and user guides at all-guides.com Front Fan Installation Remove the front panel and Install up to two 120mm fan(s). Back Fan Installation Install up to two 120mm fan.
- Page 8 All manuals and user guides at all-guides.com PSU/PSU Cover Installation a. Push the PSU cover up and slide it to b. Insert your PSU and secure it with the the right. PSU screws(6.32-Hex). " Installing 5.25 drives a. Remove drive cover b.
- Page 9 All manuals and user guides at all-guides.com A. HDD LED(red) B. Power LED(white) C. USB 2.0x1 / USB 3.0x1 D. Power Button E. Headphone jack F. Microphone jack G. Reset Button...
- Page 10 All manuals and user guides at all-guides.com Contents and Specification are subject to change without notice...
- Page 11 All manuals and user guides at all-guides.com...
